Trouble recovery
96
removable watertight storage compart-
ment.)
(2) While pushing the projection on each
lock, slide the locks outward.
(3) Remove the electrical box cover.
(4) While pushing both sides of the fuse box
cover inward, pull the cover toward the
bow and remove it.
(5) When replacing a fuse, remove the fuse
using the fuse puller. Install a spare fuse
of the proper amperage. WARNING! Do
not use fuses of a different amperage
than recommended. Substitution with
a fuse that has an improper rating cancause extensive electrical system
damage and possible fire.
[EWJ00803]
(6) Securely install the fuse box cover in its
original position.
(7) Securely install the electrical box cover in
its original position.
(8) Slide the locks to their original positions
to securely lock the electrical box cover
in place.
1Electrical box cover
2Lock
3Projection
1Fuse box cover
1
2
3
2
3
1
1Electronic throttle valve fuse
2Fuel pump fuse
3Main relay drive fuse
4Main fuse
5Fuse puller
6Battery fuse
7Bilge pump fuse
8Security system fuse
9Spare fuse
Fuse amperage:
Electronic throttle valve fuse:
10 A
Fuel pump fuse:
10 A
Main relay drive fuse:
10 A
Main fuse:
20 A
Battery fuse:
30 A
Bilge pump fuse:
3 A
Security system fuse:
3 A
1
9 23 4 5 6
8 7
