Periodic maintenance an d a djustment
6-13
6
8. Install the engine oil drain bolt and
its new gasket, and then tighten
the bolt to the specified torque.
9. Refill with the specified amount of the recommended engine oil, and
then install and tighten the oil filler
cap.
TIP
Be sure to wipe off spilled oil on any
parts after the engine and exhaust sys-
tem have cooled down.
NOTICE
ECA11621
In or der to prevent clutch slip-
pa ge (since the en gine oil also
lu bricates the clutch), do not
mix any chemical additives. Do
not use oils with a diesel speci-
fication of “CD” or oils of a hi gh-
er quality than specified . In
a dd ition, do not use oils la bele d
“ENERGY CONSERVING II” or
hi gher.
 Make sure that no forei gn mate-
rial enters the crankcase.
10. Start the engine, and then let it idle for several minutes while checking
it for oil leakage. If oil is leaking,
immediately turn the engine off
and check for the cause.
TIP
After the engine is started, the engine
oil level warning light should go off if
the oil level is sufficient.
NOTICE
ECA10402
If the oil level warnin g li ght flickers
or remains on even if the oil level is
correct, imme diately turn the en gine
off an d have a Yamaha d ealer check
the vehicle.
11. Turn the engine off, and then check the oil level and correct it if
necessary.
1. Torque wrench
Tightening torque:
Oil filter cartridge: 17 Nm (1.7 m·kgf, 12 ft·lbf)
Ti ghtening torque:
Engine oil drain bolt:
43 Nm (4.3 m·kgf, 31 ft·lbf)
Recommen ded en gine oil:
See page 8-1.
Oil quantity: Oil change:
3.80 L (4.02 US qt, 3.34 Imp.qt)
With oil filter removal: 4.00 L (4.23 US qt, 3.52 Imp.qt)
1
UB95E0E0.book Page 13 Friday, February 19, 2016 2:15 PM

Periodic maintenance an d a djustment
6-14
6
EAU20017
Final g ear oil
The final gear case must be checked
for oil leakage before each ride. If any
leakage is found, have a Yamaha deal-
er check and repair the vehicle. In ad-
dition, the final gear oil level must be
checked and the oil changed as fol-
lows at the intervals specified in the
periodic maintenance and lubrication
chart.
WARNING
EWA10371
Make sure that no forei gn mate-
rial enters the final g ear case.
 Make sure that no oil g ets on
the tire or wheel.
To check the final gear oil level
1. Place the vehicle on the center- stand.
TIP
Make sure that the vehicle is posi-
tioned straight up when checking the
oil level. A slight tilt to the side can re-
sult in a false reading.
2. Remove the final gear oil filler boltand its gasket, and then check the
oil level in the final gear case.
TIP
The oil level should be at the brim of
the filler hole.
3. If the oil is below the brim of thefiller hole, add sufficient oil of the
recommended type to raise it to
the correct level.
4. Check the gasket for damage, and replace it if necessary.
5. Install the final gear oil filler bolt and its gasket, and then tighten
the bolt to the specified torque.
To chan ge the final gear oil
1. Place the vehicle on a level sur- face.
2. Place an oil pan under the final gear case to collect the used oil.
3. Remove the final gear oil filler bolt, the final gear oil drain bolt and
their gasket to drain the oil from
the final gear case.
1. Final gear oil filler bolt
2. Gasket
3. Correct oil level
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
3
2
1
UB95E0E0.book Page 14 Friday, February 19, 2016 2:15 PM

Periodic maintenance an d a djustment
6-33
6
EAU54515
Replacin g the fuses
The fuse boxes and individual fuses
are located under panel A. (See page
6-7.)
If a fuse is blown, replace it as follows.1. Turn the key to “OFF” and turn off the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a hi gher ampera ge
ratin g than recommen ded to
avoi d causin g extensive dam-
a g e to the electrical system an d
possi bly a fire.
[EWA15132]
1. Main fuse
2. Spare fuse
3. Cruise control fuse
4. Brake light fuse
5. Fuse box
6. Main fuse 2
5
1
3
4
2
5 26
1. ABS motor fuse
2. ABS solenoid fuse
3. Fuel injection system fuse
4. Backup fuse (for clock and immobilizer sys-
tem)
5. Electronic throttle valve fuse
6. Headlight fuse
7. Spare fuse
8. YCC-S motor control fuse
9. Suspension fuse
10.Signaling system fuse
11.Terminal fuse 1 (for auxiliary DC jack)
12.ABS control unit fuse
13.Ignition fuse
14.Right radiator fan motor fuse
15.Left radiator fan motor fuse
16.Hazard fuse
17.Windshield motor fuse
15 7
11
10121314
71716
8
1
9
234
5
67
7
UB95E0E0.book Page 33 Friday, February 19, 2016 2:15 PM

Motorcycle care and stora ge
7-3
7 2. After drying the motorcycle, apply
a corrosion protection spray on all
metal, including chrome- and
nickel-plated, surfaces to prevent
corrosion.
Windshield cleaning
Avoid using any alkaline or strong acid
cleaner, gasoline, brake fluid, or any
other solvent. Clean the windshield
with a cloth or sponge dampened with
a neutral detergent, and after cleaning,
thoroughly wash it off with water. For
additional cleaning, use Yamaha Wind-
shield Cleaner or other quality cleaner.
Some cleaning compounds for plastics
may leave scratches on surfaces of the
windshield. Before using them, make a
test by polishing an area which does
not affect your visibility.
After cleanin g
1. Dry the motorcycle with a chamois or an absorbing cloth.
2. Use a chrome polish to shine chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally in-
duced discoloring of stainless-
steel exhaust systems can be re-
moved through polishing.)
3. To prevent corrosion, it is recom- mended to apply a corrosion pro-
tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
4. Use spray oil as a universal clean- er to remove any remaining dirt.
5. Touch up minor paint damage caused by stones, etc.
6. Wax all painted surfaces. 7. Let the motorcycle dry completely
before storing or covering it.
WARNING
EWA11132
Contaminants on the brakes or tires
can cause loss of control.  Make sure that there is no oil or
wax on the brakes or tires.
 If necessary, clean the b rake
d iscs an d b rake linin gs with a
re gular brake disc cleaner or
acetone, an d wash the tires with
warm water an d a mil d d eter-
g ent. Before ri din g at hi gher
speed s, test the motorcycle’s
b rakin g performance an d cor-
nering b ehavior.
NOTICE
ECA10801
 Apply spray oil an d wax spar-
in gly an d make sure to wipe off
any excess.
 Never apply oil or wax to any
rubber an d plastic parts, but
treat them with a suitab le care
prod uct.
 Avoi d using abrasive polishin g
compoun ds as they will wear
away the paint.
TIP
 Consult a Yamaha dealer for ad-
vice on what products to use.
 Washing, rainy weather or humid
climates can cause the headlight
lens to fog. Turning the headlight
on for a short period of time will
help remove the moisture from the
lens.
UB95E0E0.book Page 3 Friday, February 19, 2016 2:15 PM

Specifications
8-3
8
Battery:
Model:GT14B-4
Voltage, capacity:
12 V, 12.0 Ah (10 HR)
Bul b watta ge × quantity:
Headlight:
LED
Brake/tail light:
LED
Front turn signal light: LED
Rear turn signal light: LED
Auxiliary light: LED
License plate light:
LED
Meter lighting: LED
Neutral indicator light: LED
High beam indicator light:
LED
Oil level warning light: LED
Turn signal indicator light: LED
Engine trouble warning light:
LED
ABS warning light: LED
Cruise control “SET” indicator light: LED
Cruise control “ON” indicator light:
LED
Immobilizer system indicator light: LED
Traction control system indicator/warning
light: LED
Shift down indicator light: LED
YCC-S system warning light:
LED
Suspension warning light: LED
Fuse(s):
Main fuse:
50.0 A Main fuse 2:
30.0 A
Terminal fuse 1: 3.0 A
Headlight fuse:
7.5 A
Brake light fuse: 1.0 A
Signaling system fuse: 7.5 A
Ignition fuse:
20.0 A
Radiator fan motor fuse: 10.0 A × 2
Hazard fuse: 7.5 A
Fuel injection system fuse: 15.0 A
ABS control unit fuse:
7.5 A
ABS motor fuse: 30.0 A
ABS solenoid fuse: 20.0 A
Suspension fuse:
15.0 A
Cruise control fuse: 1.0 A
YCC-S motor control fuse: 30.0 A
Backup fuse:
7.5 A
Windshield motor fuse: 20.0 A
Electronic throttle valve fuse: 7.5 A
UB95E0E0.book Page 3 Friday, February 19, 2016 2:15 PM

10-1
10
Index
A
ABS ....................................................... 3-29
ABS warning light ................................... 3-5
Accessory box ...................................... 3-39
Air filter element .................................... 6-17
Auxiliary DC jack ................................... 3-50
B
Battery .................................................. 6-31
Brake and shift pedals, checking and
lubricating ........................................... 6-27
Brake and YCC-S clutch fluid levels, checking ............................................. 6-24
Brake and YCC-S clutch fluids, changing ............................................. 6-26
Brake lever ............................................ 3-28
Brake lever, checking and lubricating ........................................... 6-28
Brake lever free play, checking............. 6-22
Brake light switches.............................. 6-23
Brake pedal........................................... 3-28
C
Cables, checking and lubricating ......... 6-26
Canister................................................. 6-11
Care ........................................................ 7-1
Catalytic converters .............................. 3-34
Centerstand and sidestand, checking and lubricating .................................... 6-28
Coolant ................................................. 6-15
Cornering lights .................................... 3-51
Cowling vents, opening and closing ..... 3-41
Cruise control indicator lights ................. 3-4
Cruise control switches ........................ 3-25
Cruise control system ............................. 3-8
D
Diagnostic connector.............................. 9-2
Dimmer/Pass switch ............................. 3-24
D-mode (drive mode) ............................ 3-23
E
Electronically adjustable suspension system warning light............................. 3-6
Engine break-in....................................... 5-6
Engine idling speed, checking .............. 6-17
Engine oil and oil filter cartridge ........... 6-11
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-5
F
Final gear oil.......................................... 6-14
Front and rear brake pads, checking.... 6-23
Front fork, checking .............................. 6-30
Fuel ....................................................... 3-32 Fuel consumption, tips for reducing ...... 5-5
Fuel tank cap ........................................ 3-31
Fuel tank overflow hose ....................... 3-33
Fuses, replacing ................................... 6-33
H
Handlebar position, adjusting .............. 3-40
Handlebar switches .............................. 3-24
Hand shift lever .................................... 3-27
Hazard switch....................................... 3-24
Headlight beams, adjusting.................. 3-40
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-24
I
Identification numbers ............................ 9-1
Ignition circuit cut-off system............... 3-48
Immobilizer system ................................ 3-1
Immobilizer system indicator light.......... 3-7
Indicator lights and warning lights ......... 3-4
M
Main switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system.................................................. 6-3
Matte color, caution ............................... 7-1
Menu switch ......................................... 3-25
Model label ............................................. 9-1
Multi-function meter unit ...................... 3-11
N
Neutral indicator light ............................. 3-4
O
Oil level warning light ............................. 3-4
P
Panels, removing and installing.............. 6-7
Parking ................................................... 5-7
Part locations ......................................... 2-1
R
Rear suspension, lubricating ................ 6-29
Rear view mirrors ................................. 3-42
Rider seat height, adjusting.................. 3-36
S
Safety information .................................. 1-1
Seats .................................................... 3-34
Select switch ........................................ 3-25
Shift down indicator light ....................... 3-6
Shifting ................................................... 5-3
Shift pedal ............................................ 3-26
Sidestand ............................................. 3-47
Spark plugs, checking .......................... 6-10
Specifications ......................................... 8-1
Starting the engine ................................. 5-2
UB95E0E0.book Page 1 Friday, February 19, 2016 2:15 PM

Index
10-2
10
Steering, checking ............................... 6-30
Stop mode function indicator light ......... 3-6
Stop mode function switch .................. 3-25
Stop/Run/Start switch .......................... 3-24
Storage ................................................... 7-4
Storage compartment .......................... 3-38
Suspension, adjusting the front and
rear ..................................................... 3-43
Swingarm pivots, lubricating ................ 6-29
T
Throttle grip and cable, checking and lubricating .......................................... 6-27
Throttle grip free play, checking........... 6-18
Tires...................................................... 6-19
Tool kit.................................................... 6-2
Traction control system........................ 3-30
Traction control system indicator/warning light ......................... 3-5
Troubleshooting ................................... 6-35
Troubleshooting charts ........................ 6-36
Turn signal indicator lights ..................... 3-4
Turn signal switch ................................ 3-24
V
Valve clearance .................................... 6-18
Vehicle identification number ................. 9-1
Vehicle lights ........................................ 6-34
W
Wheel bearings, checking .................... 6-31
Wheels.................................................. 6-21
Y
YCC-S clutch ....................................... 6-22
YCC-S system...................................... 3-26
YCC-S system warning light .................. 3-6
UB95E0E0.book Page 2 Friday, February 19, 2016 2:15 PM
