2016 VOLKSWAGEN CC ESP

Flashes Possible cause Proper response
D
Steering system stiff. Turn the steering wheel back
and forth.
Steering column not
locked/unlocked.
Switch the ignition off and
then switch it on again. Heed
any messages shown in the
instrument cluster display, if
applicable.
On vehicles with Keyless Ac-
cess ,press the starter button
briefly twice in a row without
depressing the brake or
clutch pedal.
Do not drive any farther if
the steering column remains
locked after you switch on the
ignition. Contact your author-
ized Volkswagen dealer or an
authorized Volkswagen Ser-
vice Facility for assistance.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.

Lights
up
Possible cause or
meaning ⇒  Proper response
Together with ABS indica-
tor light J or !"3: ABS fail-
ure.
See an authorized
Volkswagen dealer or an au-
thorized Volkswagen Service
Facility.
The vehicle brakes will work
without ABS.
"2!+%
7%!2
Brake pads worn.
If you believe that it is safe to
do so, immediately take the
vehicle to an authorized
Volkswagen dealer or author-
ized Volkswagen Service Fa-
cility. Check, and if necessary
replace, all brake pads.
I

Lights
up
Possible cause or
meaning ⇒  Proper response
Vehicle battery has been
reconnected.
Drive a short distance at a
speed of 10–12 mph (15–
20 km/h). If the indicator light
stays on, see an authorized
Volkswagen dealer or an au-
thorized Volkswagen Service
Facility
m
ASR manually deactivated.
Switch on ASR ASR automat-
ically turns on when you turn
the ignition off and back on
again.
%3# /&&
J

Flashes Possible cause Proper response
H

following other vehicles too closely) – especially during the break-in
period.
Brake pad wear depends mostly on operating conditions and the
way the vehicle is driven. If you do a lot of city and short-distance
driving and/or have a sporty driving style, you should have the brake
pads checked by an authorized Volkswagen dealer or authorized
Volkswagen Service Facility more often than the regular service inter-
vals.
Wet brakes (for example, after driving through water or washing the
vehicle or after heavy rainfall) will not brake as well. Stopping dis-
tances will be longer when brake discs are wet or, in winter, even icy.
Wet or icy brakes must be dried as soon as possible by carefully ap-
plying the brakes a couple of times while traveling at a relatively high
speed. Make sure nobody is behind you and that you do not endan-
ger yourself or others ⇒ .
Brakes coated with road salt also react slower and need longer
stopping distances. If there is salt on the roads and you are not brak-
ing regularly, brake carefully and gently from time to time to remove
any salt coating from the brake discs and pads ⇒ .
Brake disc corrosion (rust) and dirt buildup on the brake pads are
more likely to occur if the vehicle is not driven much or is driven only
for short distances with little braking. If the brakes have not been
used and there is some rust on the discs, clean the brake discs and
pads once in a while by carefully braking a couple of times while driv-
ing at relatively high speed to help clean the brake discs and pads.
Make sure nobody is behind you and that you do not endanger your-
self or others ⇒ .
Brake system malfunction
If you brake and find that the vehicle doesn't brake nearly as well as it
used to (sudden increase in stopping distance), a brake circuit may
have failed. The brake warning light H or "2!+% will come on and a
message may appear in the instrument cluster display. If you believe
the vehicle is safe to drive, immediately take it to the nearest author-
ized Volkswagen dealer or authorized Volkswagen Service Facility for
repair. Drive slowly and very carefully, allow for the longer stopping
distance, and be ready to push longer and harder on the brake pedal
to slow the vehicle down.

Brake booster
The brake booster works only when the engine is running. It increas-
es the force on the brakes above and beyond the pressure put on the
brake pedal by the driver.
If the brake booster is not working, or if the vehicle has to be towed,
you will have to push the brake pedal harder to make up for the lack
of booster assistance and the resulting longer stopping distance ⇒ .
WARNING
New brake pads do not provide maximum braking performance.
New brake pads do not have the best stopping power for the
first 200 miles (320 km) and must be “broken in.” You can com-
pensate for the slightly reduced braking force by putting more
pressure on the brake pedal.
Drive with extra care while the new brake pads are being bro-
ken in. This reduces the risk of collisions and serious personal
injuries due to a loss of control over the vehicle.
Never follow other vehicles too closely or put yourself into
other situations that might require sudden, hard braking, espe-
cially when the brake pads have not been broken in.
WARNING
Overheated brakes will reduce the vehicle's stopping power
and increase stopping distances considerably.
When driving downhill, the brakes have to work especially
hard and heat up quickly.
Before driving downhill, especially on hills that are long or
steep, always reduce speed and shift into lower gear (manual or
automatic transmission). This will let the vehicle use engine
braking and reduce the load on the brakes. Otherwise, the
brake system could overheat and possibly fail. Only use the
brakes when you need them to slow the vehicle down more or
to stop.
A damaged front spoiler or a non-standard spoiler can re-
duce airflow to the brakes and make them overheat.

WARNING
Wet brakes or brakes coated with ice or road salt react slower
and need longer stopping distances.
Carefully apply the brakes to test them.
Always dry brakes and clean off ice and salt coatings with a
few cautious brake applications when visibility, weather, road
and traffic conditions permit.
WARNING
Driving when the brake booster is not working increases stop-
ping distances and can cause accidents and serious personal
injuries.
Never let the vehicle coast when the engine is switched off.
If the brake booster is not working (such as when the vehicle
is being towed), a lot more pedal force is needed to slow down
and stop.
NOTICE
Never “ride” the brakes by keeping your foot on the brake pe-
dal when you do not want to brake. Constant pressure on the
brake pedal can make the brakes overheat. Riding the brakes
will substantially reduce braking performance, increase stopping
distance, and can cause complete brake system failure.
Before driving downhill, especially on hills that are long or
steep, always reduce speed and shift into lower gear (manual or
automatic transmission). This will let the vehicle use engine
braking and reduce the load on the brakes. Otherwise, the brake
system could overheat and possibly fail. Only use the brakes
when you need them to slow the vehicle down more or to stop.
When the front brakes are serviced, you should have the rear
brake pads inspected at the same time. The wear of all brake pads
should be visually checked regularly. The best way to check for brake
pad wear is to have your authorized Volkswagen dealer or authorized
Volkswagen Service Facility visually inspect the pads through the

WARNING
Driving with too little fuel in the fuel tank increases the risk of
stalling, especially when driving up and down hills.
If your vehicle stalls suddenly, this can cause an accident
and serious personal injuries.
Driver assistance and braking assistance systems can mal-
function when there is too little fuel in the tank and cause you
to lose control of the vehicle.
Never drive until the fuel tank is almost empty.
Hill Hold
