4. Press downward to remove the bulb holder ⇒ fig. 201 (5) with
the bulb and pull it toward the rear out of the headlight hous-
ing.
5. Pull the bulb straight out of the bulb holder.
6. Replace burned out bulbs with new bulbs that are identical to
the ones being replaced.
7. Insert the bulb holder with the new bulb in the original position
in the headlight housing (5) and press upward.
8. Install the rubber cover ⇒ fig. 200 (1).
Replacing the HID bulb
See your authorized Volkswagen dealer or authorized Volkswagen
Service Facility for assistance in replacing the HID bulb (2).
The illustrations show the right headlight from behind. The left
headlight is arranged as a mirror image of the right.
Failure of a single LED within a headlight is not indicated. How-
ever, the indicator light will appear if all LEDs fail.
Different models may have different lights, and the location and
design of covers, bulb holders, and bulbs may be in a different loca-
tion than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Con-
tact your authorized Volkswagen dealer or an authorized Volkswagen
Service Facility for assistance.
Please carry out each step only in the order specified:
3.
Insert the wire bracket into the opening ⇒ fig. 204 (1) on the
cover and pull it forward in the direction of the arrow with the
cover and remove.
4. Remove the screws (2) with the screwdriver.
6. Pull the light out slightly.
7. Release the connector ⇒ fig. 205 (1) and disconnect it.
8. Turn the bulb holder (2) counterclockwise until it stops and
then it remove it toward the rear with the bulb.
9. Replace burned out bulbs with new bulbs that are identical to
the ones being replaced.
10. Insert the bulb holder in the headlight and turn it clockwise
until it stops.
11. Check if the bulb is installed securely.
12. Connect the connector (1) on the bulb so that it clicks into
place.
13. Insert the light into the bumper.
14. Install the screws ⇒ fig. 204 (2).
15.
Insert the cover in the bumper opposite the direction indicated
by the arrow ⇒ fig. 204. The cover must click into place
securely.
16. Make sure the cover is installed securely.
The illustrations show the right fog light. The left fog light is ar-
ranged as a mirror image of the right.
