2016 TOYOTA VENZA turn signal

1922-2. Instrument cluster
VENZA_OM_OM73030U_(U) ■ Indicators
The indicators inform the driver of the operating state of the
vehicle’s various systems. Turn signal indicator
(  P. 185) Cruise control “SET”
indicator (  P. 231)
Headlight high beam
indicator (  P. 213) Slip indicator (  P. 257)(U.S.A.)
Headlight indicator
(  P. 212) VSC OFF indicator
(  P. 258)(Canada)
Tail light indicator
(  P. 212) TRAC OFF indicator
(  P. 258)(if equipped)
Automatic High Beam
indicator (  P. 216) “AIR BAG ON/OFF”
indicator (  P. 134)
Fog light indicator
(  P. 223)
Shift position and shift
range indicators
(  P. 180)Security indicator
(  P. 109, 112)
Cruise control indicator
(  P. 231) * 1, 2
* 1
* 1

2192-3. Operating the lights and wipers
2
When driving
VENZA_OM_OM73030U_(U) ■ Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turning high beam on or off manually if nec-
essary.
■ Camera sensor detection information
● High beam may not be automatically turned off in the following situations:
• When oncoming vehicles suddenly appear from a curve.
• When the vehicle is cut in front of by another.
● High beam may be turned off if an oncoming vehicle that is using fog
lights without using the headlights is detected.
● Houselights, streetlights, red traffic signals, and illuminated billboards or
signs may cause the high beam to turn off.
● The following factors may affect the amount of time taken to turn high
beam on or off:
• The brightness of headlights, fog lights, and tail lights of oncoming and
preceding vehicles
• Road conditions (wetness, ice, snow etc.)
• The number of passengers and amount of baggage
● High beam may be turned on or off when unexpected by the driver.

3423-2. Using the audio system (Entune Audio)
VENZA_OM_OM73030U_(U) ■ Selecting a desired genre
Select “Station List”.
FM radio only: Select a desired genre of station and select a
desired station.
● The genre list is in the following order:
• Classical
• Country
• EasyLis (Easy Listening)
• Inform (Information)
•Jazz
•News
• Oldies
• Other
• Pop Music
• Religion
•Rock
• R&B (Rhythm and Blues)
•Sports
•Talk
• Alert (Emergency Alert)■ Reception sensitivity
● Maintaining perfect radio reception at all times is difficult due to the con-
tinually changing position of the antenna, differences in signal strength
and surrounding objects, such as trains, transmitters, etc.
● The radio antenna is mounted on the roof. The antenna can be removed
from the base by turning it. STEP 1
STEP 2

3723-2. Using the audio system (Entune Audio)
VENZA_OM_OM73030U_(U) ■ Reconnecting a Bluetooth ®
phone
If the system cannot connect due to poor signal strength with the engine
switch in the “ACC” or “ON” position (vehicles without a smart key system) or
ACCESSORY or IGNITION ON mode (vehicles with a smart key system),
the system will automatically attempt to reconnect.
If the phone is turned off, the system will not attempt to reconnect. In this
case, the connection must be made manually, or the phone must be rese-
lected.

4203-2. Using the audio system (Entune Audio)
VENZA_OM_OM73030U_(U) ■ Conditions under which th e system will not operate
● If using a cellular phone that does not support Bluetooth ®
● If the cellular phone is turned off
● If you are outside of cellular phone service coverage
● If the cellular phone is not connected
● If the cellular phone’s battery is low
● When outgoing calls are controlled, due to heavy traffic on telephone
lines, etc.
● When the cellular phone itself cannot be used
● When transferring contact data from the cellular phone
■ Bluetooth ®
antenna
The antenna is built into the display.
If the portable audio player is behind the seat or in the glove box or console
box, or is touching or covered by metal objects, the connection status may
deteriorate.
If the cellular phone is behind the seat or in the console box, or touching or
covered by metal objects, the connection status may deteriorate.
■ Battery charge/signal status
● This display may not correspond exactly with the portable audio player or
cellular phone itself.
● This system does not have a charging function.
● The portable audio player or cellular phone battery will be depleted
quickly when the device is connected to Bluetooth ®
.

5314-3. Do-it-yourself maintenance
4
Maintenance and care
VENZA_OM_OM73030U_(U) 24 EFI NO.1 10 A Smart key system, multiport fuel
injection system/sequential mul-
tiport fuel inje ction system, auto-
matic transmission
25 ETCS 10 A Multiport fuel injection system/
sequential multiport fuel injection
system, electronic throttle con-
trol system
26 TURN-HAZ 15 A Turn signal lights
27 IG2 25 A INJ NO.1, INJ NO.2, SRS airbag
system
28 AMP 20 A Audio system
29 A/F
* 1
20 A Air fuel ratio sensor
EFI MAIN
* 2
20 A EFI NO.2, EFI NO.3
30 HORN 10 A Horn
31 H-LP LO (LH) 15 A Left-hand headlight (low beam)
32 H-LP LO (RH) 15 A Right-hand headlight (low beam)
33 H-LP HI (LH) 15 A Left-hand headlight (high beam)
34 H-LP HI (RH) 15 A Right-hand headlight (high beam)
35 EFI MAIN
* 1
25 A
EFI NO.2, EFI NO.3
EFI NO.4
* 2
20 A
Air fuel ratio sensor
36 DOME 7.5 A Personal/interior lights, vanity
lights, engine switch light, door
courtesy lights, power back door,
gauges and metersFuse Ampere Circuit

5374-3. Do-it-yourself maintenance
4
Maintenance and care
VENZA_OM_OM73030U_(U) Light bulbs You may replace the following bulbs yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perfor m, contact your Toyota dealer.
For more information about replacing other light bulbs, contact your
Toyota dealer.
■ Prepare a replacement light bulb.
Check the wattage of the light bulb being replaced. (  P. 624)
■ Turn the power back door main switch off. (vehicles with
power back door)
 P. 5 9
■ Front bulb locations
Vehicles with halogen headlights Headlight low beam
Headlight high beam
Front turn signal/parking light Front fog light Front side marker lightDaytime running right

5384-3. Do-it-yourself maintenance
VENZA_OM_OM73030U_(U) Vehicles with discharge headlights
■ Rear bulb locations Front fog lightFront turn
signal light
Front side marker light
Stop/tail and rear side
marker lights
Back-up light Tail light
License plate lightRear turn signal light
