TOYOTA SAFETY SENSE
The AHB uses an in-vehicle camera sensor to assess the brightness of streetlights,
the lights of oncoming and preceding vehicles, etc., and automatically turns high
beam on or off as necessary.
Auto High Beams (AHB)
(1)(2)
Activating the Automatic High Beam (AHB) system
(1) With the engine switch in IGNITION ON mode and headlight switch turned to
“ON” position, push lever away from you.
(2) Depress the Automatic High Beam “AUTO” switch.
The AHB indicator will come on when the headlights are turned on
automatically to indicate that the system is active.
Note: Pull the lever back toward you to turn the AHB system off.
The AHB indicator will turn off and the high beam indicator turns on.
Conditions where Automatic High Beams will turn ON/OFF automatically
When all of these conditions are met, high beams will be automatically turned on
(after approximately 1 second):
= 9 H K L F O H V S H H G L V D E R Y H D S S U R [ L P D W H O \ P S K N P K
= 7 K H D U H D D K H D G R I W K H Y H K L F O H L V G D U N
= 7 K H U H D U H Q R R Q F R P L Q J R U S U H F H G L Q J Y H K L F O H V Z L W K K H D G O L J K W V R U W D L O O L J K W V
turned on.
If any of these conditions occur, high beams will be automatically turned off:
= 9 H K L F O H V S H H G G U R S V E H O R Z D S S U R [ L P D W H O \ P S K N P K
= 7 K H D U H D D K H D G R I W K H Y H K L F O H L V Q R W G D U N
= 2 Q F R P L Q J R U S U H F H G L Q J Y H K L F O H V K D Y H K H D G O L J K W V R U W D L O O L J K W V
turned on.
= 7 K H U H D U H P D Q \ V W U H H W O L J K W V R Q W K H U R D G D K H D G
32
Door locks
Spare tire & tools
Tool location
Removing the spare tire
Refer to the Owner’s Manual for tire changing and jack positioning procedures.
Spare tireTool bag2
Moving the lever to the lock position will allow the door to be opened only from
the outside.
Rear door
Jack1Spare wheel
cushions
Doors-Child safety locks
Lock
Unlock
Luggage
floor cover
1 For detailed directions on removing the jack from under the driver’s seat, refer to the Owner’s Manual.2 Jack handle, wheel nut wrench and towing eyelet
Lock
SAFETY AND EMERGENCY FEATURES
