LC200_OM_OM60M88U_(U)
9
6-1. Maintenance and careCleaning and protecting the vehicle exterior .......... 434
Cleaning and protecting the vehicle interior ........... 437
6-2. Maintenance Maintenance requirements ................... 440
General maintenance ........ 443
Emission inspection and maintenance (I/M)
programs ......................... 446
6-3. Do-it-yourself maintenance Do-it-yourself service precautions ..................... 447
Hood.................................. 449
Engine compartment ......... 450
Tires .................................. 463
Tire inflation pressure........ 472
Wheels .............................. 475
Air conditioning filter .......... 477
Electronic key battery ........ 479
Checking and replacing fuses ............................... 481
Headlight aim .................... 485
Light bulbs ......................... 487 7-1. Essential information
Emergency flashers ........... 500
If your vehicle has to be stopped in
an emergency.................. 501
7-2. Steps to take in an emergency
If your vehicle needs to be towed ...................... 502
If you think something is wrong............................... 508
Fuel pump shut off system ............................. 509
If a warning light turns on or a warning buzzer
sounds ............................. 510
If a warning message is displayed ......................... 519
If you have a flat tire .......... 524
If the engine will not start ... 537
If the shift lever cannot be shifted from P .................. 539
If the electronic key does not operate properly ........ 540
If the vehicle battery is discharged ....................... 543
If your vehicle overheats.... 546
If the vehicle becomes stuck ................................ 549
6Maintenance and care7When trouble arises

433
LC200_OM_OM60M88U_(U)
6Maintenance and care
6-1. Maintenance and careCleaning and protecting the vehicle exterior .......... 434
Cleaning and protecting the vehicle interior ........... 437
6-2. Maintenance Maintenance requirements ................... 440
General maintenance........ 443
Emission inspection and maintenance (I/M)
programs ......................... 446
6-3. Do-it-yourself maintenance Do-it-yourself service precautions ..................... 447
Hood ................................. 449
Engine compartment ......... 450
Tires .................................. 463
Tire inflation pressure ....... 472
Wheels .............................. 475
Air conditioning filter.......... 477
Electronic key battery........ 479
Checking and replacing fuses ............................... 481
Headlight aim .................... 485
Light bulbs......................... 487

447
LC200_OM_OM60M88U_(U)
6-3. Do-it-yourself maintenance
6
Maintenance and care
Do-it-yourself ser vice precautions
If you perform maintenance yourself, be sure to follow the cor-
rect procedures as given in these sections.
ItemsParts and tools
Battery condition
(P. 459)• Warm water• Baking soda• Grease
• Conventional wrench (for terminal clamp bolts)
Brake fluid level
(P. 456)• FMVSS No.116 DOT 3 or SAE J1703 brake fluid
• Rag or paper towel
• Funnel (used only for adding brake fluid)
Engine coolant
level ( P. 455)
• “Toyota Super Long Life Coolant” or similar high
quality ethylene glycol-based non-silicate, non-
amine, non-nitrite and non-borate coolant with long-
life hybrid organic acid technology.
“Toyota Super Long Life Coolant” is pre-mixed with
50 % coolant and 50 % deionized water.
• Funnel (used only for adding coolant)
Engine oil level
(P. 452)• “Toyota Genuine Motor Oil” or equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)
Fuses
(P. 481)• Fuse with same amperage rating as original
Headlight aim
(P. 485)• Phillips-head screwdriver
Light bulbs
(P. 487)
• Bulb with same number and wattage rating as origi-
nal
• Phillips-head screwdriver• Flathead screwdriver
• Wrench
Power steering
fluid level
(P. 458)• Automatic transmission fluid DEXRON® II or III
• Rag or paper towel
• Funnel (used only for adding power steering fluid)
Radiator and con-
denser ( P. 456)
Tire inflation
pressure
( P. 472)
• Tire pressure gauge• Compressed air source

481
LC200_OM_OM60M88U_(U)
6-3. Do-it-yourself maintenance
6
Maintenance and care
Checking and replacing fuses
Turn the engine switch off.
Open the fuse box cover.
Engine compartment
Push the tab in and lift the lid off.
Driver’s side instrument panel
Remove the lid.
If any of the electrical components do not operate, a fuse may
have blown. If this happens, check and replace the fuses as nec-
essary.
1
2

484
LC200_OM_OM60M88U_(U)
6-3. Do-it-yourself maintenance
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may
need replacement. ( P. 487)
● If the replaced fuse blows again, have the vehicle inspected by your Toyota
dealer.
■ If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
■ When replacing light bulbs
Toyota recommends that you use genuine Toyota products designed for this
vehicle. Because certain bulbs are connected to circuits designed to prevent
overload, non-genuine parts or parts not designed for this vehicle may be
unusable.
WARNING
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.
●Never use a fuse of a higher amperage rating than indicated, or use any
other object in place of a fuse.
● Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
● Do not modify the fuses or the fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your
Toyota dealer, as soon as possible.

598Alphabetical index
LC200_OM_OM60M88U_(U)
Front passenger occupant classification system .............. 51
Front passenger’s seat belt reminder light ................. 512
Front seats ............................... 127
Adjustment ............................ 127
Cleaning................................ 437
Correct driving posture ........... 28
Driving position memory ....... 136
Head restraints ..................... 140
Seat heaters ......................... 390
Seat position memory ........... 136
Seat ventilators ..................... 390
Front side marker lights.......... 205
Light switch ........................... 205
Replacing light bulbs............. 489
Wattage ................................ 559
Front turn signal lights Replacing light bulbs............. 490
Turn signal lever ................... 203
Wattage ................................ 559
Fuel Capacity ................................ 554
Fuel gauge .............................. 85
Fuel pump shut off
system ......... ....................... 509
Gas station information ......... 608
Information ............................ 560
Refueling............................... 222
Type ...................................... 554
Warning light ......................... 512 Fuel consumption
information .............................. 98
Fuel filler door ......................... 222 Opener.................................. 224
Refueling .............................. 222
Fuel pump shut off system..... 509
Fuses ........................................ 481
Gas station information .......... 608
Garage door opener ................ 422
Gauges ....................................... 85
Glove box ................................. 397
Hands-free system (for cellular phone)
*
Head restraints ........................ 140
Headlight cleaner .................... 221
Headlights ................................ 205
Automatic headlight leveling ............................... 207
Automatic High Beam
system .......... ...................... 209
Headlight aim........................ 485
Light switch ........................... 205
Replacing light bulbs ............ 497
Heated steering wheel ............ 389
G
H

602Alphabetical index
LC200_OM_OM60M88U_(U)
Panic mode .............................. 103
Parking assist sensors (intuitive parking assist) ....... 272
Parking brake ........................... 204 Operation .............................. 204
Parking brake engaged
warning buzzer ................... 204
Parking lights ........................... 205
Light switch ........................... 205
Replacing light bulbs............. 497
PCS (Pre-Collision system) .... 233
Enabling/disabling the system ......... ....................... 237
Function ................................ 233
Warning light ......................... 511
Personal lights ......................... 393 Switch ................................... 395
Power outlets ........................... 410
Power steering Fluid ...................................... 558
Power windows........................ 150 Jam protection function......... 151
Operation .............................. 150
Window lock switch............... 150
Pre-Collision system (PCS) ...................................... 233Enabling/disabling the
system ......... ....................... 237
Function ................................ 233
Warning light ......................... 511 Radar cruise control
(dynamic radar cruise
control)................................... 257
Radiator .................................... 456
Radio
*
Rear air conditioning system.................................... 385
Rear seat .................................. 129
Adjustment............................ 129
Folding up the third seats................................... 132
Tumbling the second seats................................... 130
Rear side marker lights........... 205
Light switch ........................... 205
Replacing light bulbs ............ 497
Rear step bumper .................... 116
Rear turn signal lights ............ 203
Replacing light bulbs ............ 494
Turn signal lever ................... 203
Wattage ................................ 559
Rear view mirror Inside rear view mirror .......... 145
Outside rear view mirrors ..... 147
Rear view monitor system
*
Rear window defogger ............ 380
Rear window wiper .................. 219
Refueling .................................. 222 Capacity................................ 554
Fuel types ............................. 554
Opening the fuel tank cap..... 222
Replacing Electronic key battery ........... 479
Fuses .................................... 481
Light bulbs ............................ 487
Tires...................................... 524
Reporting safety defects for U.S. owners...................... 586
Resetting the message
indicating maintenance is
required.................................. 441
Roof luggage carrier ............... 169
