2016 TOYOTA LAND CRUISER ECO mode

470
LC200_OM_OM60M88U_(U)
6-3. Do-it-yourself maintenance
■Tire pressure warning system certification
WARNING
■Tire pressure warning system operation
The tire pressure warning system may not provide warning immediately
if a tire bursts or if sudden air leakage occurs.
■When inspecting or replacing tires
Observe the following precautions to prevent accidents.
Failure to do so may cause damage to parts of the drive train as well as
dangerous handling characteristics, which may lead to an accident
resulting in death or serious injury.
●Do not mix tires of different makes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.
●Do not use tire sizes other than those recommended by Toyota.
●Do not mix differently constructed ti res (radial, bias-belted or bias-ply
tires).
●Do not mix summer, all season and snow tires.
●Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously.
■When initializing the tire pressure warning system
Do not operate the tire pressure warning reset switch without first
adjusting the tire inflation pressure to the specified level. Otherwise, the
tire pressure warning light may not come on even if the tire inflation
pressure is low, or it may come on when the tire inflation pressure is
actually normal.

5137-2. Steps to take in an emergency
LC200_OM_OM60M88U_(U)
7
When trouble arises
*1: Brake system warning buzzer:The buzzer sounds to indicate that the brake fluid level is low (with the
vehicle reached a speed of 3 mph [5 km/h]).
*2: Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is
not fully closed (with the vehicle having reached a speed of 5 km/h
[3 mph]).
*3: Driver’s seat belt buzzer: The driver’s seat belt buzzer sounds to alert the driver that his or her seat
belt is not fastened. Once the engine switch is turned to IGNITION ON
mode, the buzzer sounds for 6 seconds. If the vehicle reaches a speed of
12 mph (20 km/h), the buzzer sounds once. If the seat belt is still unfas-
tened after 30 seconds, the buzzer will sound intermittently for 10 seconds.
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 20 more seconds.
Front passenger’s seat belt buzzer:
he front passenger’s seat belt buzzer sounds to alert the front passenger
that his or her seat belt is not fastened. The buzzer sounds once if the\
vehicle reaches a speed of 12 mph (20 km/h). If the seat belt is still unfas-
tened after 30 seconds, the buzzer will sound intermittently for 10 seconds.
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 20 more seconds.

5387-2. Steps to take in an emergency
LC200_OM_OM60M88U_(U)
One of the following may be the cause of the problem:
●One or both of the battery terminals may be disconnected.
● The battery may be discharged. ( P. 543)
● There may be a malfunction in the steering lock system.
Contact your Toyota dealer if the problem cannot be repaired, or if repair
procedures are unknown.
When the engine does not start, the following steps can be used as an
interim measure to start the engine if the engine switch is functioning
normally.
Set the parking brake.
Put the shift lever in P.
Set the engine switch to the ACCESSORY mode.
Push and hold the engine switch for about 15 seconds while
depressing the brake pedal firmly.
Even if the engine can be started using the above steps, the system
may be malfunctioning. Have the v ehicle inspected by your Toyota
dealer.
The starter motor does not turn ov er, the interior lights and head-
lights do not turn on, or the horn does not sound.
Emergency start function
1
2
3
4

5417-2. Steps to take in an emergency
LC200_OM_OM60M88U_(U)
7
When trouble arises
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Toyota emblem side
of the electronic key to the
engine switch.
When the electronic key is
detected, a buzzer sounds and the
engine switch will turn to IGNITION
ON mode.
When the smart key system is
deactivated in customization set-
ting, the engine switch will turn to
ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on
the multi-information display.
Press the engine switch.
In the event that the engine still cannot be started, contact your Toyota
dealer.
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when
stopping the engine.
■ Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
( P. 479)
■ Alarm
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,
the alarm may be triggered. ( P. 76)
■ Changing engine switch modes
Release the brake pedal and press the engine switch in step above. The
engine does not start and modes will be changed each time the switch is
pressed. ( P. 194)
■ When the electronic key does not work properly
●Make sure that the smart key system has not been deactivated in the cus-
tomization setting. If it is off, turn the function on.
(Customizable features: P. 574)
● Check if battery-saving mode is set. If it is set, cancel the function.
(P. 122)
Starting the engine
1
2
3
4
3

597Alphabetical index
LC200_OM_OM60M88U_(U)
Emergency flashers ................ 500
EngineAccessory mode ................... 194
Air cleaner............................. 448
Compartment ........................ 450
Engine switch........................ 193
Exhaust gas precautions ........ 73
Hood ..................................... 449
How to start the engine ......... 193
Identification number ............ 553
If the engine will not start ...... 537
If your vehicle has to be stopped in an
emergency.......................... 501
Ignition switch (engine switch) ................... 193
Overheating .......................... 546
Engine compartment cover .... 451
Engine coolant ......................... 455 Capacity ................................ 556
Checking ............................... 455
Preparing and checking before winter....................... 369
Engine coolant temperature gauge........................................ 85
Engine immobilizer system ...... 74
Engine oil ................................. 452 Capacity ................................ 554
Checking ............................... 452
Preparing and checking before winter....................... 369
Engine switch (ignition switch)..................... 193
Engine switch light (ignition switch light) ............ 393
Event data recorder (EDR) ........ 10
Exhaust gas precautions .......... 73 First-aid kit holder ................... 405
Flat tire ..................................... 524
Floor mats .................................. 26
Fluid
Automatic transmission ........ 557
Brake .................................... 558
Steering ................................ 558
Washer ................................. 462
Fog lights ................................. 214 Replacing light bulbs ............ 497
Switch ................................... 214
Four-wheel drive system Center differential lock/unlock ......................... 281
Four-wheel drive control switch ................................. 280
Warning light......................... 514
Front automatic air conditioning system ............. 374
Front doors .............................. 106F

602Alphabetical index
LC200_OM_OM60M88U_(U)
Panic mode .............................. 103
Parking assist sensors (intuitive parking assist) ....... 272
Parking brake ........................... 204 Operation .............................. 204
Parking brake engaged
warning buzzer ................... 204
Parking lights ........................... 205
Light switch ........................... 205
Replacing light bulbs............. 497
PCS (Pre-Collision system) .... 233
Enabling/disabling the system ......... ....................... 237
Function ................................ 233
Warning light ......................... 511
Personal lights ......................... 393 Switch ................................... 395
Power outlets ........................... 410
Power steering Fluid ...................................... 558
Power windows........................ 150 Jam protection function......... 151
Operation .............................. 150
Window lock switch............... 150
Pre-Collision system (PCS) ...................................... 233Enabling/disabling the
system ......... ....................... 237
Function ................................ 233
Warning light ......................... 511 Radar cruise control
(dynamic radar cruise
control)................................... 257
Radiator .................................... 456
Radio
*
Rear air conditioning system.................................... 385
Rear seat .................................. 129
Adjustment............................ 129
Folding up the third seats................................... 132
Tumbling the second seats................................... 130
Rear side marker lights........... 205
Light switch ........................... 205
Replacing light bulbs ............ 497
Rear step bumper .................... 116
Rear turn signal lights ............ 203
Replacing light bulbs ............ 494
Turn signal lever ................... 203
Wattage ................................ 559
Rear view mirror Inside rear view mirror .......... 145
Outside rear view mirrors ..... 147
Rear view monitor system
*
Rear window defogger ............ 380
Rear window wiper .................. 219
Refueling .................................. 222 Capacity................................ 554
Fuel types ............................. 554
Opening the fuel tank cap..... 222
Replacing Electronic key battery ........... 479
Fuses .................................... 481
Light bulbs ............................ 487
Tires...................................... 524
Reporting safety defects for U.S. owners...................... 586
Resetting the message
indicating maintenance is
required.................................. 441
Roof luggage carrier ............... 169
PR

606Alphabetical index
LC200_OM_OM60M88U_(U)
Tires .......................................... 463Chains................................... 370
Checking ............................... 463
If you have a flat tire ............. 524
Inflation pressure .................. 472
Information ............................ 563
Replacing .............................. 524
Rotating tires......................... 463
Size ....................................... 558
Snow tires ............................. 369
Spare tire .............................. 524
Tire pressure warning
system ......... ....................... 464
Warning light ......................... 512
Tools ......................................... 525
Top tether strap ......................... 63
Total load capacity .................. 552
Towing Dinghy towing ....................... 192
Emergency towing ................ 502
Towing eyelet........................ 504
Trailer Sway Control ............. 358
Trailer towing ........................ 176
Toyota Safety Sense P ............ 226
TRAC (Traction Control) ......... 357
Trailer Sway Control................ 358
Trailer towing ........................... 176
Transmission Automatic transmission......... 199
Downshift restriction warning buzzer................................. 202
If the shift lever cannot be shifted from P ..................... 539
Selecting a driving mode ...... 200
S mode ................................. 201
Trip information ......................... 98
Trip meters ................................. 85
Troubleshooting ...................... 588 Turn signal lights .................... 203
Replacing light
bulbs................... 490, 494, 497
Turn signal lever ................... 203
Wattage ................................ 559
USB port
*
Utility vehicle precautions ...... 364
Vanity lights ............................. 408 Vanity lights .......................... 408
Wattage ................................ 559
Vanity mirrors .......................... 408
Vehicle data recordings .............. 9
Vehicle identification number ................................... 553
Vehicle Stability Control (VSC) ...................................... 357
Ventilators (seat ventilators) ................... 390
VSC (Vehicle Stability
Control) .................................. 357
U
V
