1042. Instrument cluster
HIGHLANDER_HV_U (OM48F12U)
Hybrid System Indicator
Displays hybrid system output or regeneration level.
Multi-information display
Presents the driver with a variety of driving-related data.
Speedometer
Fuel gauge
Trip meter reset knob
Switches the trip information.
Outside temperature
Odometer and trip meter display
Shift position and shift range
Displays the selected shift position or selected shift range. (P. 237)
Meter panel lights control button
Engine coolant temperature gauge
Displays the engine coolant temperature.
Switches between the trip meter
“A” and “B” displays. When the trip
meter is displayed, pressing and
holding the knob will reset the trip
meter.
The brightness of the meter panel lights can be adjusted.
Pressing the button will adjust the
brightness of the meter panel
lights.
The brightness level of the meters
when the surroundings are bright
(day mode) and dark (night mode)
can be adjusted individually. How-
ever, when in day mode, adjusting
the brightness level will also
change the brightness level of
night mode.
Changing the trip meter display
1
2
3
4
5
6
7
8
9
10
Instrument panel light control
601Alphabetical index
HIGHLANDER_HV_U (OM48F12U)
Multi-information display (with color display) ............... 111
Audio system-linked.............. 111
Driving information ................ 113
Dynamic radar cruise control................................. 271
Energy monitor ..................... 117
LDA (Lane Departure Alert)........ 287
Navigation system-linked ...... 111
Settings display..................... 114
Switching the display ............ 112
Warning message ................. 470
Multi-information display
(with monochrome display)Driving information ................ 107
Settings display..................... 109
Warning message ................. 470
Navigation system
*
Noise from under vehicle............ 8
Odometer.................................. 103
Oil Engine oil .............................. 536
Opener Back door.............................. 135
Fuel filler door ....................... 263
Glass hatch ........................... 144
Hood ..................................... 399
Outer foot lights....................... 341
Outside rear view mirrors ....... 177
Adjusting and folding ............ 177
BSM (Blind spot monitor) ...... 307
Mirror position memory ......... 165
Outside rear view mirror defoggers ........................... 330 Outside temperature
display.................................... 355
Overheating, Hybrid system... 525
Panoramic moon roof ............. 187 Jam protection function ........ 189
Operation .............................. 187
Parking assist sensors (intuitive parking assist)
*
Parking brake........................... 243 Operation .............................. 243
Parking brake engaged warning buzzer ................... 476
Parking brake engaged warning message ............... 476
Parking lights........................... 244
Light switch ........................... 244
Replacing light bulbs ............ 438
Wattage ................................ 543
PCS (Pre-Collision System).......... 300Function ................................ 300
PCS OFF switch ................... 301
Warning light......................... 462
Personal lights......................... 342 Wattage ................................ 543
Power back door ..................... 134
Power control unit ..................... 85
Power control unit coolant ..... 406 Capacity................................ 538
Checking............................... 406
Preparing and checking before winter ...................... 319
Power outlets ........................... 356
Power steering (Electric power steering) ...... 295Warning light......................... 462
Power switch ........................... 229
N
O
P
*: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”
