2016 TOYOTA COROLLA release handle

1083-2. Opening, closing and locking the doors
COROLLA_TMMMS_TMMC_U (OM12J84U)
nSwitching the door unlock functi on (vehicles with a smart key system)
It is possible to set which doors the entry function unlocks using the wireless
remote control.
Turn the engine switch off.
When the indicator light on the key surface is not on, press and hold ,
or for approximately 5 seconds while pressing and holding
.
The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat step .)
Vehicles with an alarm: To prevent un intended triggering of the alarm, unlock
the doors using the wireless remote control and open and close a door once
after the settings have been changed. (If a door is not opened within 60 sec-
onds after is pressed, the doors will be locked again and the alarm will
automatically be set.)
In case that the alarm is triggered, immediately stop the alarm. ( P. 6 8 )
1
2
2
Multi-information
display
(if equipped)
Unlocking functionBeep
Holding the driver’s door
handle unlocks only the
driver’s door.
Exterior: Beeps 3
times
Interior: Pings once
Holding the front passen-
ger’s door handle unlocks
all the doors.
Holding either front door
handle unlocks all the
doors.Exterior: Beeps
twice
Interior: Pings once

1163-2. Opening, closing and locking the doors
COROLLA_TMMMS_TMMC_U (OM12J84U)n
Effective range (areas within whic h the electronic key is detected)
n Alarms and warning indicators
Vehicles with a drive monitor display
A combination of exterior and interior alarms as well as warning lights are
used to prevent theft of the vehicle and unforeseeable accidents resulting
from erroneous operation. Take appropria te measures for the warning light
that comes on. ( P. 503)
Vehicles with a multi-information display
A combination of exterior and interior alarms as well as warning messages
shown on the multi-information display are used to prevent theft of the vehicle
and accidents resulting from erroneous operation. Take appropriate mea-
sures in response to any warning message on the multi-information display.
(  P. 510)
The following table describes circumstances and correction procedures when
only alarms are sounded.
When locking or unlocking the
doors
The system can be operated
when the electronic key is within
about 2.3 ft. (0.7 m) of either of
the outside front door handles.
(Only the doors detecting the key
can be operated.)
When starting the engine or changing engine switch modes
The system can be operated when the electronic key is inside the
vehicle.
When opening the trunk
The system can be operated when the electronic key is within
about 2.3 ft. (0.7 m) of the trunk release button.

612Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12J84U)
JackPositioning the jack ............... 439
Vehicle-equipped jack........... 521
Jack handle .............................. 521
Jam protection function Moon roof.............................. 142
Power window....................... 138
Keyless entry Smart key system ......... 101, 110
Wireless remote
control......................... 101, 111
Keys ............................................ 96
Battery-saving function ......... 118
Electronic key ......................... 96
Engine switch................ 165, 168
If the electronic key does not operate properly ........... 535
Key number plate.................... 96
Keyless entry .......................... 97
Mechanical key ....................... 97
Replacing the battery ............ 469
Warning buzzer..................... 116
Wireless remote control .......... 97
Knee airbags .............................. 34 LATCH anchors ......................... 58
Lever
Auxiliary catch lever.............. 437
Hood lock release lever....................... 437
Shift lever...... 176, 178, 180, 184
Turn signal lever ................... 186
Wiper lever ........................... 196
License plate lights ................. 188 Light switch ........................... 188
Replacing light bulbs ............ 484
Wattage ................................ 559
Light bulbs Replacing.............................. 475
Wattage ................................ 559
Lights Fog light switch ..................... 195
Front Interior light ................. 402
Headlight switch ................... 188
Illuminated entry system ....... 403
Interior lights list.................... 401
Personal lights ...................... 402
Rear interior light .................. 403
Replacing light bulbs ............ 475
Trunk light ............................. 112
Turn signal lever ................... 186
Wattage ................................ 559
Lock steering column ..... 166, 173
J
K
L
