551-1. For safe use
1
For safety and security
CAMRY_HV_U (OM33C35U)
lIt is recommended that children sit in the rear seats to avoid acci-
dental contact with the shift lever, wiper switch etc.
l Use the rear door child-protector lock or the window lock switch to
avoid children opening the door while driving or operating the
power window accidentally.
l Do not let small children operate equipment which may catch or
pinch body parts, such as the powe r window, hood, trunk, seats etc.
Safety information for children
Observe the following precautions when children are in the vehi-
cle.
Use a child restraint system appropriate for the child, until the
child becomes large enough to pr operly wear the vehicle’s seat
belt.
WARNING
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows or other features of the vehicle. In addition, heat build-up or
extremely cold temperatures inside the vehicle can be fatal to children.

681-1. For safe use
CAMRY_HV_U (OM33C35U)
Exhaust gas precautions
Harmful substance to the human body is included in exhaust
gases if inhaled.
WARNING
Exhaust gases include harmful carbon monoxide (CO), which is colorless and
odorless. Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to
an accident caused by light-headedness, or may lead to death or a serious
health hazard.
nImportant points while driving
lKeep the trunk lid closed.
l If you smell exhaust gases in the vehicle even when the trunk lid is closed,
open the windows and have the vehicle inspected at your Toyota dealer as
soon as possible.
n When parking
lIf the vehicle is in a poorly ventilated area or a closed area, such as a
garage, stop the hybrid system.
l Do not leave the vehicle with the hybrid system on for a long time.
If such a situation cannot be avoided, park the vehicle in an open space
and ensure that exhaust fumes do not enter the vehicle interior.
l Do not leave the hybrid system running in an area with snow build-up, or
where it is snowing. If snowbanks build up around the vehicle while the
hybrid system is running, exhaust gases may collect and enter the vehicle.
n Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or
crack caused by corrosion, damage to a joint or abnormal exhaust noise, be
sure to have the vehicle inspected and repaired by your Toyota dealer.

801-3. Theft deterrent system
CAMRY_HV_U (OM33C35U)
The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the alarm is
set:
lA locked door or trunk is unlocked or opened in any way other than
using the entry function, wireless remote control or mechanical key.
(The doors will lock again automatically.)
l The hood is opened.
l Some models: The window is tapped or broken.
Close the doors, trunk and hood,
and lock all the doors. The system
will be set automatically after 30
seconds.
The indicator light changes from
being on to flashing when the sys-
tem is set.
Do one of the following to deactivate or stop the alarm:
l Unlock the doors or trunk. If the alarm does not stop even when the
wireless remote control is operated, repeat the operation until the
alarm stops.
l Turn the power switch to ACCESSORY or ON mode, or start the
hybrid system. (The alarm will be de activated or stopped after a few
seconds.)
Alar m
: If equipped
The alarm
Setting the alarm system
Deactivating or stopping the alarm

811-3. Theft deterrent system
1
For safety and security
CAMRY_HV_U (OM33C35U)
nSystem maintenance
The vehicle has a maintenance-free type alarm system.
n Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of
the following:
lNobody is in the vehicle.
l The windows and moon roof are closed before the alarm is set.
l No valuables or other personal items are left in the vehicle.
n Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
n Alarm-operated door lock
In the following cases, depending on the situation, the door may automatically
lock to prevent improper entry into the vehicle:
lWhen a person remaining in the vehicle locks the door and the alarm is acti-
vated.
l While the alarm is activated, a person remaining in the vehicle unlocks the
door.
l When recharging or replacing the 12-volt battery.
l
A person inside the vehicle opens a
door, the trunk or hood.
l The 12-volt battery is recharged or
replaced when the vehicle is locked.
(P. 493)
NOTICE
n To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

105
3
Operation of
each component
CAMRY_HV_U (OM33C35U) 3-1. Key information
Keys .................................. 106
3-2. Opening, closing and locking the doors
Doors ................................ 110
Trunk ................................. 117
Smart key system ............. 121
3-3. Adjusting the seats Front seats ........................ 128
Rear seats......................... 130
Head restraints.................. 132
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 134
Inside rear view mirror ...... 136
Outside rear view mirrors ............................. 138
3-5. Opening and closing the windows
Power windows ................. 140
Moon roof .......................... 143

106
CAMRY_HV_U (OM33C35U)
3-1. Key information
The following keys are provided with the vehicle.Electronic keys
• Operating the smart key system( P. 121)
• Operating the wireless remote control function
Mechanical keys
Key number plate
Locks all the doors ( P. 1 1 0 )
Unlocks all the doors ( P. 1 1 0 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 5 seconds unlocks the
other doors.
Opens the driver’s window and
moon roof (if equipped)
( P. 110)
*
Opens the trunk ( P. 1 1 7 )
Sounds the alarm ( P. 107)
*: This setting must be customized at your Toyota dealer.
Keys
The keys
1
2
3
Wireless remote control
1
2
3
4
5

110
CAMRY_HV_U (OM33C35U)
3-2. Opening, closing and locking the doors
uSmart key system
Carry the electronic key to enable this function.Grip the driver’s door handle
to unlock the door. Grip the
front passenger’s door han-
dle to unlock all the doors.*
Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
*: The door unlock settings can be changed. ( P. 115)
Touch the lock sensor (the indentation on the side of the door
handle) to lock the doors.
Check that the door is securely locked.
uWireless remote control
Locks all the doors
Check that the door is securely
locked.
Unlocks all the doors
Pressing the button unlocks the
driver’s door. Pressing the but-
ton again within 5 seconds
unlocks the other doors.
Press and hold to open the
driver’s window and moon roof
(if equipped).
* (P. 140, 144)
*: This setting must be customized at your Toyota dealer.
Doors
Unlocking and locking the doors from the outside
1
2
1
2

1113-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
nOperation signals
Doors:
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Driver’s window and moon roof:
A buzzer sounds to indicate that the driver’s window and moon roof are open-
ing.
n Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
n When the door cannot be locked by the lock sensor on the side of the
door handle
n Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds for 5 seconds. Fully close the door to stop the buzzer, and
lock the doors again.
n Alarm (if equipped)
Locking the doors will set the alarm system. ( P. 80)
n If the smart key system or the wireless remote control does not operate
properly
Use the mechanical key to lock and unlock the doors. ( P. 487)
Replace the battery with a new one if it is depleted. ( P. 425)
If the door will not lock even when the
side sensor area is touched, try using
your palm to touch the lock sensor.
