2016 TOYOTA AVALON engine

2875-4. Other interior features
5
Interior features
AVALON (U)_(01999-07001)■
Rear armrest (if equipped)
■
The power outlets can be used when
The engine switch is in ACCESSORY or IGNITION ON mode.
NOTICE
●To avoid damaging the power outlets, close the power outlet lids when the
power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short
circuit.
● To prevent blown fuse, do not use an accessory that uses more than 12 V
10 A.
● To prevent battery discharge, do not use the power outlets longer than
necessary when the engine is off.

2895-4. Other interior features
5
Interior features
AVALON (U)_(01999-07001)
The rear sunshade can be raised and lowered by pressing the switch
shown below.
Extends/retracts the rear sun-
shade
■The rear sunshade can be used when
The engine switch is in IGNITION ON mode.
■ Reverse operation feature
To ensure adequate rear visibility, the rear sunshade automatically lowers
when the shift lever is shifted to R.
However, the rear sunshade is raised again if either of the following occurs:
●The button is pressed again.
● The shift lever is shifted out of R, and the vehicle reaches a speed of 9 mph
(15 km/h).
If the engine is turned off when the rear sunshade has been lowered due to
the reverse operation feature, it will not be raised even when the engine is
turned on again and the vehicle reaches a speed of 9 mph (15 km/h). To raise
the sunshade again, press the button.
■ Customization
Settings (e.g. time elapsed before the reverse operation feature activates)
can be changed.
(Customizable features: P. 449)
Rear sunshade (if equipped)
WARNING
When the rear sunshade is being raised or lowered, do not place fingers \
or
other objects in the fastener section or in the opening. They may get caught,
causing injury.

2905-4. Other interior features
AVALON (U)_(01999-07001)
Long objects can be loaded into the vehicle by utilizing the trunk
space and rear seat area.
Fold down the armrest.
Push down the handle and
open the armrest door.
The armrest door can be locked
and unlocked using the
mechanical key.Lock
Unlock
NOTICE
To prevent battery discharge, do not operate the rear sunshade when the
engine is not running.
To ensure normal operation of the sunshade, observe the following precau-
tions.
●Do not place excessive load on the motor or other components.
● Do not place objects where they may hinder opening and closing opera-
tions.
● Do not attach items to the rear sunshade.
● Keep the opening clean and clear of obstructions.
● Do not operate the rear sunshade continuously for long periods of time.
Trunk storage extension
1
2
1
2
WARNING
■When not in use
Ensure that the armrest door is closed.
In the event of sudden braking, items stored in the trunk may be thrown for-
ward into the cabin, resulting in injury.

3025-4. Other interior features
AVALON (U)_(01999-07001)
When the engine switch is turned to IGNITION ON mode, the red indi-
cator light comes on for 2 seconds then turns off. Afterward, the green
indicator light comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage
conditions:
● Green indicator light on = Active service
● Green indicator light flashing = Sa fety Connect call in process
● Red indicator light (except at vehi cle start-up) = System malfunction
(contact your Toyota dealer)
● No indicator light (off) = Safety Connect service not active
■Automatic Collision Notification
In case of either airbag deployment or severe rear-end collision, the
system is designed to automatical ly call the response center. The
responding agent receives the vehicle’s location and attempts to
speak with the vehicle occupants to assess the level of emergency.
If the occupants are unable to communicate, the agent automati-
cally treats the call as an emergency, contacts the nearest emer-
gency services provider to descri be the situation, and requests that
assistance be sent to the location.
Safety Connect LE D light Indicators
Safety Connect services

309
Maintenance and care6
AVALON (U)_(01999-07001)6-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 310
Cleaning and protecting the vehicle interior ........... 314
6-2. Maintenance Maintenance requirements ................... 317
General maintenance........ 319
Emission inspection and maintenance (I/M)
programs ......................... 323
6-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 324
Hood ................................. 326
Positioning a floor jack ...... 327
Engine compartment ......... 328
Tires .................................. 340
Tire inflation pressure ....... 350
Wheels .............................. 353
Air conditioning filter.......... 356
Electronic key battery........ 358
Checking and replacing fuses ............................... 360
Light bulbs......................... 363

3126-1. Maintenance and care
AVALON (U)_(01999-07001)
WARNING
■When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.
■ When cleaning the windshield (veh icles with rain-sensing windshield
wipers)
● When the upper part of the windshi eld where the raindrop sensor is
located is touched by hand
● When a wet rag or similar is held close to the raindrop sensor
● If something bumps against the windshield
● If you directly touch the raindrop sensor body or if something bumps into
the raindrop sensor
■ Precautions regarding the exhaust pipes
Exhaust gases cause the exhaust pipes to become quite hot.
When washing the vehicle, be careful not to touch the pipes until they have
cooled sufficiently, as touching hot exhaust pipes can cause burns.
■ Precaution regarding the Blind Spot Monitor (if equipped)
If the paint of the rear bumper is chipped or scratched, the system may mal-
function. If this occurs, consult your Toyota dealer.
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wip-
ers may operate unexpectedly in the fol-
lowing situations, and may result in
hands being caught or other serious inju-
ries and cause damage to the wiper
blades.
Off

3186-2. Maintenance
AVALON (U)_(01999-07001)
■Repair and replacement
It is recommended that genuine Toyota parts be used for repairs to ensure
performance of each system. If non-Toyota parts are used in replacement or if
a repair shop other than a Toyota dealer performs repairs, confirm the war-
ranty coverage.
■ Resetting the message indicating maintenance is required (U.S.A. only)
After the required maintenance is performed according to the maintenance
schedule, please reset the message.
To reset the message, follow the procedure described below:
Turn the engine switch off with the trip meter A reading shown. ( P. 80)
While pressing the trip meter reset knob ( P. 80), turn the engine switch to
IGNITION ON mode
Continue to press and hold the knob until the trip meter displays “000000”.
■ Allow inspection and repairs to be performed by a Toyota dealer
●Toyota technicians are well-trained specialists and are kept up to date with
the latest service information. They are well informed about the operations
of all systems on your vehicle.
● Keep a copy of the repair order. It proves that the maintenance that has
been performed is under warranty cove rage. If any problem should arise
while your vehicle is under warranty, your Toyota dealer will promptly take
care of it.
WARNING
■ If your vehicle is not properly maintained
Improper maintenance could result in serious damage to the vehicle and
possible death or serious injury.
■ Handling of the battery
●Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause cancer and birth defects and other reproductive harm. Work in a
well ventilated area.
● Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor-
nia to cause cancer and birth defects or other reproductive harm. Avoid
exposure and wash any affected area immediately.
● Battery posts, terminals and related accessories contain lead and lead
compounds which are known to cause brain damage. Wash your hands
after handling. ( P. 336)
1
2
3

3196-2. Maintenance
6
Maintenance and care
AVALON (U)_(01999-07001)
General maintenance
Listed below are the general maintenance items that should be
performed at the intervals specified in the “Owner’s Warranty
Information Booklet” or “Owner’s Manual Supplement/Sched-
uled Maintenance Guide”. It is recommended that any problem
you notice should be brought to the attention of your Toyota
dealer or qualified service shop for advice.
Engine compartment
ItemsCheck points
BatteryCheck the battery fluid level and
connections. ( P. 336)
Brake fluidIs the brake fluid at the correct
level? (P. 335)
Engine coolantIs the engine coolant at the correct
level? (P. 332)
Engine oilIs the engine oil at the correct level?
(P. 329)
Exhaust systemThere should not be any fumes or
strange sounds.
Radiator/condenser
The radiator and condenser should
be free from foreign objects.
(P. 334)
Washer fluidIs there sufficient washer fluid?
(P. 339)
