2016 SUBARU IMPREZA ECO mode

Pre-Collision Braking System
29
Continued on next page Ÿ
NOTE
•After the vehicle has come to a stop through secondary braking, release
brake control in the following manner.
- Depress the brake pedal.
- Depress the accelerator pedal (except when the select lever is in the
position).
- When the selector lever is in the position
• After stopping with secondary braking, in the following cases, operate
parking brake and release brake control.
- When any door (except the rear gate/trunk) was opened
- When EyeSight is temporarily stopped
- When there is a malfunction in the EyeSight system
& warning Secondary braking
& warning
First braking
Possible collision area Highly possible
collision areaExtremely highly possible
collision areaObstacle
First
braking
No brake controlRepeated
short beeps
Repeated
short beeps
Strong
Secondary
braking Operating
system
Indication on the multi
information display
Continuous
beep
Moderate
Strength of
Automatic Braking
Warning
buzzer type
Following distance
warning
Following
distance
warning
S01330
N
P

Conventional Cruise Control
67
NOTE
•When the (CRUISE) switch is first turned on, the Adaptive Cruise
Control is set.
• To change the Cruise Control mode, press and hold the (following
distance setting) switch for approximately 2 seconds or longer.
(This is effective only when the main Cruise Control is on and neither
Adaptive Cruise Control nor Conventional Cruise Control are set.)
• Conventional Cruise Control can be used even when EyeSight is tempo-
rarily turned off.

List of buzzer sounds
77
List of buzzer sounds
Buzzer soundStatusReference page
Single continuous beep Pre-Collision Braking System:
Secondary Braking is active.
ŸRefer to page 28.
Single long beep Adaptive Cruise Control or Conventional Cruise
Control is canceled.
ŸRefer to pages
48 and 74.
Repeated short beeps Pre-Collision Braking System:
First Braking is active.
ŸRefer to page 28.
Pre-Collision Braking System:
The following distance warning is active.
The “brake more” warning from Adaptive Cruise
Control is active.
Ÿ Refer to page 51.
Pre-Collision Throttle Management is active.
ŸRefer to page 53.
6 short beeps The Lane Departure Warning is active.
ŸRefer to page 59.
The Lane Sway Warning is active.
ŸRefer to page 62.
3 short beeps and 1 long beep Pre-Collision Braking System:
Automatic brake is slowly released by the sys-
tem after vehicle stopped by the pre-collision
braking.
ŸRefer to page 21.
Adaptive Cruise Control System:
Automatic brake is released by the system after
vehicle is stopped by the Adaptive Cruise Con-
trol System. (Adaptive Cruise Control System
will stop the vehicle according to the lead vehi-
cle stops.
ŸRefer to page 33.
1 short beep Either of the following occurred while Adaptive
Cruise Control was set.
- A vehicle in front is detected
*.
- A vehicle in front is no longer detected*.
ŸRefer to page 41.
The cruise control mode (Adaptive Cruise
Control Conventional Cruise Control) is
changed.
ŸRefer to page 69.
EyeSight is malfunctioning.
ŸRefer to pages
79 and 80.
EyeSight operation is temporarily stopped.
Pre-Collision Braking System and Pre-Collision
Throttle Management are turned on/off.
ŸRefer to pages
31 and 58.
The Lane Departure Warning and the Lane
Sway Warning are turned on/off.
ŸRefer to pages
61 and 64.
