2016 SUBARU CROSSTREK display

NAVIGATION OPERATION
32
6.SelectGo! (Go!).

” Guidance to the destination is displayed on the
screen and can be heard via voice guidance.SETTING HOME AS THE
DESTINATION (WITH NAVIGATION
FUNCTION)
1.Select, or select and then select MAP
(MAP).
2.SelectMenu (Menu).

NAVIGATION OPERATION
33
1
QUICK GUIDE
3.SelectDestination (Destination).
4.SelectGo Home (Go Home).
5.SelectNext (Next).
6.SelectGo! (Go!).

” Guidance to the destination is displayed on the
screen and can be heard via voice guidance.

FUNCTION INDEX
34
FUNCTION INDEX
FUNCTION INDEX
XAudio
Function Page
Using the radio 60, 69
Playing an audio CD or MP3/WMA/AAC disc 78
Playing an SD*
1 card 87
Playing a USB memory 81
Playing an iPod
®84
Playing a Bluetooth device 91
Using the aha application 156
Using the AUX port 94
Using the MirrorLink
TM application 154
Using the Pandora
®*2 application 162
Using the steering wheel audio switches 96
Audio system settings 99
*1: With navigation function
*2: Pandora is available in the United States, Australia, and New Zealand.
X Map*
*: With navigation function
Displaying maps Page
Viewing the map screen 198
Displaying the current position 203
Changing the scale 204
Changing the map orientation 205
Displaying the estimated travel/arrival time to the
destination 222
'LVSOD\LQJWUDI¿FLQIRUPDWLRQ 206
Searching for destinationsPage
Searching for the destination 208

BASIC INFORMATION BEFORE OPERATION
38
BASIC INFORMATION BEFORE OPERATION
INITIAL SCREEN
INITIAL SCREEN
WARNING
OWhen the vehicle is stopped with the engine running, always
apply the parking brake for safety.
1.When the ignition switch is in the “ACC” or “ON”
position, the initial screen will be displayed and the
system will begin operating.

”After a few seconds, the “CAUTION (CAUTION)”
screen will be displayed.
2.SelectI Agree (I Agree).

”
After about 5 seconds, the “CAUTION (CAUTION)”
screen automatically switches to the next screen.

” With navigation function: Select
Language
(Language) to select a language.
X With navigation function
3.SelectAccept (Accept).

” &RQ¿UPWKHHQGXVHUOLFHQVHDJUHHPHQW

BASIC INFORMATION BEFORE OPERATION
47
BASIC FUNCTION
2
SPLIT SCREEN OPERATION
The split screen can display multiple information screens,
such as the audio system screen and hands-free screen,
simultaneously.
The following describes screen operation for the system
with navigation function.
1.Press and hold the “AUDIO/TUNE” knob.
2.Split screen is displayed.

”When a screen is selected, the selected screen will
change to a full-screen display.
CUSTOMIZING THE SPLIT SCREEN
The display items/area on the split screen can be changed.
XFrom the split screen
1.Select.
XFrom the “SETTINGS (SETTINGS)” screen
1.SelectSplit Screen (Split Screen) on the “SETTINGS
6(77,1*6

BASIC INFORMATION BEFORE OPERATION
49
BASIC FUNCTION
2
IconFunction
Select to skip to the next or previous page.
Select and hold or to scroll through the
displayed list.
If appears to the right of an item name, the
complete name is too long to display.
Select
to scroll to the end of the name.
Select
to move to the beginning of the name.
SELECTING ALL ITEMS
Some lists contain Select All (Select All). If Select All
(Select All) is selected, it is possible to select all items.
1.SelectSelect All (Select All).

”Unselect All (Unselect All): Unselect all items in the
list.
CHARACTER JUMP BUTTONS IN LISTS
Some lists contain character screen buttons, ABC (ABC),
DEF (DEF) etc., which allow a direct jump to list entries
that begin with the same letter as the character screen
button.
1.Select the desired character jump buttons.
NOTE
O Every time the same character screen button is selected, the list
starting with the subsequent character is displayed.

BASIC INFORMATION BEFORE OPERATION
50
SORTING (WITH NAVIGATION FUNCTION)
The order of a list displayed on the screen can be sorted in
the order of name, distance, detour, etc.
1.SelectMore (More).
2.Select the desired sorting criteria.
SCREEN ADJUSTMENT
The brightness, contrast, tone and color of the screen can
be adjusted.
1.Select.
2.SelectSETTINGS (SETTINGS).
3.SelectDisplay (Display).
4.Select the items to be set.

BASIC INFORMATION BEFORE OPERATION
51
BASIC FUNCTION
2
No.Function
Select to adjust the general screen display.
Select to adjust the camera display.
Select to adjust the video display.
5.Select the desired item to be adjusted.
X General
XCamera
XVideo (USB video/SD video*)
*: With navigation function
Screen button Function
“Brightness
(Brightness)”
Select to darken the screen.
Select to brighten the screen.
“Contrast
(Contrast)”
Select to weaken the contrast of
the screen.
Select to strengthen the contrast of
the screen.
“Tone (Tone)”
Select to weaken the tone of the
screen.
Select to strengthen the tone of the
screen.
“Color (Color)”
R (R) Select to strengthen the red color
of the screen.
G (G) Select to strengthen the green
color of the screen.
6.SelectOK
(OK).
