2016 SUBARU BRZ checking oil

299 4-3. Do-it-yourself maintenance
4
Maintenance and care
Engine oil
With the engine at operating temperature and turned off, check the oil
level on the dipstick.
■Checking the engine oil
Park the vehicle on level ground. After warming up the engine
and turning it off, wait more than five minutes for the oil to
drain back into the bottom of the engine.
Hold a rag under the end and
pull the dipstick out.
Wipe the dipstick clean.
Reinsert the dipstick fully.
Holding a rag under the end, pull the dipstick out and check
the oil level.
When checking the oil, look at both sides of the dipstick and use the
lower measurement to determine the level of oil.
Wipe the dipstick and reinsert it fully.
Low
Full
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6

300 4-3. Do-it-yourself maintenance
■Adding engine oil
If the oil level is below or near
the low level mark, add engine
oil of the same type as already in
the engine.
Make sure to check the oil type and prepare the items needed before
adding oil.
Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.
Engine oil
selectionoP. 418
Oil quantity
(Low o Full)1.1 qt. (1.0 L, 0.9 Imp. qt.)
Items
Clean funnel
■Engine oil consumption
Some engine oil will be consumed while driving. Under the following condi-
tions, oil consumption can be increased and thus require refilling between
maintenance intervals:
●When the engine is new and within the break-in period
●When the engine oil is of lower quality
●When the incorrect oil viscosity is used
●When engine braking is employed
STEP 1
STEP 2
STEP 3

478 Alphabetical index
Engine
Compartment ........................ 298
Engine hood .......................... 296
Engine switch ................162, 171
How to start the
engine .........................162, 171
Identification number............. 415
If the engine will not start ...... 393
Ignition switch................162, 171
Overheating........................... 407
Engine coolant
Capacity ................................ 420
Checking ............................... 302
Engine coolant temperature
gauge ...................................... 187
Engine hood ............................. 296
Engine immobilizer system....... 78
Engine oil
Capacity ................................ 418
Checking ............................... 299
Preparing and checking
before winter ....................... 229
Engine switch ...................162, 171
Engine switch light .................. 258
Event data recorder ...................16Floor mat .................................. 273
Fluid
Brake..................................... 304
Washer.................................. 310
Fog lights
Replacing light bulbs ............. 342
Switch ................................... 208
Wattage................................. 425
Front fog lights
Replacing light bulbs ............. 342
Switch ................................... 208
Wattage................................. 425
Front passenger occupant
detection system ................... 124
Front passenger's seatbelt
reminder light ........................ 371
Front seats
Adjustment .............................. 51
Front side marker light
Replacing light bulbs ............. 342
Wattage................................. 425
Front turn signal lights
Replacing light bulbs ............. 342
Switch ................................... 184
Wattage................................. 425
Fuel
Capacity ................................ 417
Fuel gauge ............................ 187
Fuel pump shut off system .... 367
Gas station information ......... 488
Information ............................ 426
Refueling................................. 74
Fuel door .................................... 74
Fuel filler lid................................ 74
Fuel pump shut off system ..... 367
Fuses ........................................ 334F

484 Alphabetical index
Warning buzzers
Electric power steering .......... 369
Seatbelt reminder.................. 371
Warning lights
Automatic transmission
fluid temperature
warning light........................ 371
Anti-lock brake
system ................................ 369
Brake assist system ..............369
Brake system ........................ 368
Charging system ................... 368
Cruise control
indicator light....................... 369
Electric power steering
system warning light ........... 369
Electronic engine control
system ................................ 369
Engine oil pressure ............... 368
Keyless access with
push button start
system ........................369, 378
Low fuel level ........................ 371
Low tire pressure................... 371
Malfunction indicator
lamp .................................... 369
Open door ............................. 371
Pretensioners ........................ 369
Seatbelt reminder
light ..................................... 371
Slip indicator light .................. 369
SRS airbags .......................... 369
Tire pressure monitoring
system ................................ 371Washer
Checking ............................... 310
Preparing and checking
before winter ....................... 229
Switch ................................... 209
Washing and waxing ............... 276
Weight
Cargo capacity ...................... 224
Load limits............................. 228
Weight ................................... 414
Wheels ...................................... 323
Window glasses ........................ 70
Window lock switch................... 70
Windows
Power windows ....................... 70
Rear window defogger .......... 254
Washer.................................. 209
Windshield wipers ................... 209W
