2016 Seat Toledo service indicator

Instruments and warning lamps
CAUTION
● To pr ev
ent damage to the engine, the rev
counter needle should only remain in the red
zone for a short period of time.
● When the engine is cold, avoid high revs
and heavy ac
celeration and do not make the
engine work hard. For the sake of the environment
Changing up a gear in time reduces fuel con-
sumption and noi se.Rev counter
The rev counter indicates the number of en-
gine r
ev
o

lutions per minute ›››
Fig. 110 1 .
T og
ether w
ith the gear-change indicator, the
rev counter offers you the possibility of using
the engine of your vehicle at a suitable
speed.
The start of the red zone on the dial indicates
the maximum engine speed which may be
used briefly when the engine is warm and af-
ter it has been run in properly. Before reach-
ing this range, you should change to a higher
gear for vehicles with a manual gearbox or for
automatic gearboxes put the selector lever in
“D” or take your foot off the accelerator ped-
al. We recommend that you avoid high revs and
that

you follow the recommendations on the
gear-change indicator. Consult the additional
information in ›››
 page 25. CAUTION
Never allow the rev counter needle 1 ›››
Fig. 110 to g o int
o the red zone on the
scale for more than a very brief period, other-
wise there is a risk of engine damage. For the sake of the environment
Changing up a gear early will help you to save
fuel and minimi

se emissions and engine
noise. Indications on the display
A variety of information can be viewed on the
in
s
trument

panel display ›››
Fig. 110 3 de-
pendin g on the
v
ehicle equipment:
● Bonnet, rear lid and doors open
›››
 page 25.
● Information and warning texts.
● Mileage.
● Time.
● Navigation instructions.
● Outside temperature.
● Compass. ●
Shift l
ever position ››› page 158.
● Recommended gear (manual gearbox)
›››
 page 25.
● Multifunction display (MFD) and menus
with differ
ent setting options ›››
 page 23.
● Service interval display ›››

 page 30.
● Second speed display ›››

 page 26.
● Speed warning function ›››

 page 29.
● Start-Stop system status display
›››
page 181.
● Low consumption driving status (ECO)
›››
page 96
● Identifying letters on engine (MKB).
Dist
ance travelled
The odometer registers the total distance
travelled by the car.
The odometer (trip ) shows the distance
travelled since the last odometer reset. The
last digit of the trip recorder indicates distan-
ces of 100 metres or one tenths of a mile.
● Briefly press the button ›››
Fig. 110 4 to re-
set the trip r
ec
order to 0.
● Keep the button 4 pressed for about 3
sec ond
s

and the previous value will be dis-
played. »
95
Technical data
Advice
Operation
Emergencies
Safety

Advice
– Rep
l
ace the oil filler cap carefully and push
the dipstick all the way in.
Changing engine oil Engine oil must be changed with the frequen-
cy indic
at

ed in the Maintenance Programme
or according to the service interval indicator
›››  page 30. CAUTION
Do not mix engine oil with additives. Risk of
dam ag

e to the engine! Damage caused by
these products is not covered by the warran-
ty. Note
Wash your skin thoroughly if it comes into
cont act

with engine oil. Coolant
C ontr
o

l lamp If the warning lamp
 (b lue) i
s
lit up, the en-
gine has not yet reached its operating tem-
perature 1)
. Avoid high engine speeds, hard acceleration and subjecting the engine to
high load

s.
If the warning lamp  (red) is lit up or flash-
ing, the coolant temperature is too high or its
level is too low.
The informative display indicates:
Check coolant! Instruction Man-
ual!
Stop the vehicle, switch off the engine, check
the coolant level ››› page 208 and refill if
necessary ››› page 209.
If the coolant is situated in the prescribed
area, the high temperature may be due to a
fault in the cooling system fan. Check the ra-
diator fan fuse and replace it if necessary
›››  page 43.
If the warning lamp  (red) remains lit up,
despite both the coolant level and the radia-
tor fan fuse being in correct condition, 
stop the vehicle!
Go to a technical service. WARNING
● Tak e c

are when opening the coolant reser-
voir. When the engine is warm or hot, the
system is pressurised – Danger of burns! Wait for the engine to cool before opening
the co
v

er.
● Do not touch the fan. The fan can switch on
automatic
ally regardless of whether the igni-
tion is switched on. Checking coolant level
Fig. 208
Engine compartment: coolant fluid
t ank. Read the additional information carefully
› ›
›

 page 40
The coolant expansion tank is located in the
engine compartment of the vehicle. – Switch the ignition off.
– Open the bonnet ›››
page 202. 1)
This does not apply to vehicles equipped with an
inform ativ

e display.
208

Checking and refilling levels
– Open the b att
er
y cover in the direction indi-
cated by the arrow ››› Fig. 211.
– The positive terminal (+) of the battery is
connected in r

everse order.
Checking the battery electrolyte level Fig. 212
Battery: Electrolyte level indicator. We recommend you have the acid level regu-
l
arly
c

hecked at an official technical service,
particularly in the following cases.
● At high outside temperatures.
● On long daily trips.
● Whenever the vehicle is loaded
›››
page 213, Charging the battery.
In vehicles equipped with a battery with col-
our indicator, the so-called magic eye
››› Fig. 212 changes colour to indicate the
acid level. Air bubbles can influence the colour of the in-
dicator

. Therefore, carefully knock the indica-
tor before checking the acid level.
● Black – the acid level is correct.
● Colourless or light yellow – acid level too
low, b
attery must be changed. Note
● The batt er

y acid level is also regularly
checked during servicing at authorised SEAT
dealers.
● The electrolyte level on “AGM” batteries
cannot be c
hecked for technical reasons.
● Vehicles equipped with the “Start-Stop”
syst
em include a battery control unit to con-
trol the battery level for repeated engine
starting. Winter service
At low temperatures the battery provides only
a fr
action of
the s

tarting power it has at nor-
mal temperatures.
A flat battery can also freeze at temperatures
slightly below to 0°C (32°F).
We therefore recommend you have the bat-
tery checked and, if necessary, charged at an
official SEAT technical service before the start
of winter. Charging the battery A fully-charged battery is essential for relia-
bl
e s

tarting.
– Switch off the ignition and all electrical
equipment.
– For “f

ast-charging” only: disconnect both
batter
y connection cables (first the “nega-
tive” terminal and then the “positive”).
– Connect the charger cables to the battery
terminal

s (red = “positive”, black = “nega-
tive”).
– Plug in the battery charger and switch on.
– After charging the battery: Switch off the
batt er

y charger and disconnect the cable.
– Remove the charger cables.
– If necessary, reconnect both battery cables
to the batt

ery (first the “positive” cable,
then the “negative” cable).
When charging with a low current (e.g. with a
small battery charger ), the battery does not
normally have to be disconnected. The in-
structions of the battery charger manufactur-
er must be followed.
Use a current equivalent to or lower than
10% of the battery capacity to fully charge
the battery.
Before “fast-charging” the battery however,
both battery cables must be disconnected. »
213
Technical data
Advice
Operation
Emergencies
Safety

Advice
Useful life of tyres Fig. 213
Side view of tyres with tread wear in-
dic at
or
s. Fig. 214
Location of the tyre pressure sticker. Tread wear indicator
The b
ase of

the side of the original tyres on
your vehicle show 1.6 mm high tread wear in-
dicators ››› Fig. 213. The position of these in-
dicators is given on the tyre sidewalls by the
letters “TWI”, triangular symbols or other
symbols.
The useful life of the tyres depends primarily
on the following factors:
Tyre pressure values
Under-inflation or over-inflation will consider-
ably reduce the useful life of the tyres and
impair the vehicle's handling. Therefore,
check the tyre pressure, including the spare
wheel, at least once a month and before any
long journey.
Inflation pressures for summer tyres are lis-
ted on a sticker inside the fuel tank flap
››› Fig. 214. The pressures for winter tyres are
0.2 bar (2.9 psi/20 kPa) above the summer
values.
Always check the pressure when the tyre is
cold. Do not reduce over-pressure in warm
tyres. The tyre pressures must be altered to
suit notable changes in the load being car-
ried.
Depending on the vehicle, tyre pressure can
be adjusted to medium load to improve driv-
ing comfort (“comfort” tyre pressure). When driving with comfort tyre pressure fuel con-
sumption ma
y increase slightly.
Driving style
Fast cornering, heavy acceleration and hard
braking all increase tyre wear.
Wheel balancing
The wheels on new vehicles are balanced.
Various factors encountered when driving
can cause them to become unbalanced,
which results in vibration of the steering
wheel.
The wheel must be rebalanced if a new tyre is
fitted or if a tyre is repaired.
Incorrect wheel alignment
Incorrect front or rear wheel alignment cau-
ses excessive tyre wear, frequently on one
side, and also impairs vehicle safety. If tyre
wear is very irregular, contact an Official
Service.
Tyre damage
To avoid damage to tyres and wheels, only
drive over kerbs or similar obstacles slowly
and at a right angle if possible.
Check tyres and wheels regularly for damage
(punctures, cracks, blisters, deformities,
etc.). Remove any foreign objects embedded
in outside of the treads.
216

Index
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 identif y
in
g blown fuses . . . . . . . . . . . . . . . . . . . 43
identifying by colours . . . . . . . . . . . . . . . . . . . . . 43
in the dash panel . . . . . . . . . . . . . . . . . . . . . . . . 81
in the engine compartment . . . . . . . . . . . . . . . . 82
in the instrument panel . . . . . . . . . . . . . . . . . . . 43
preparation before replacing . . . . . . . . . . . . . . . 43
replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
G Gauge fuel level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Gear-change indicator . . . . . . . . . . . . . . . . . . . . . . 25
Gearbox lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Gear change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
engaging the gears (manual gearbox) . . . . . . 156
manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
manual gearbox . . . . . . . . . . . . . . . . . . . . . . . . 156
Gear engaged . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Gear recommendation . . . . . . . . . . . . . . . . . . . . . . 25
Gearshift paddles (automatic gearbox) . . . . . . . 159
General instrument panel control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
controls and displays . . . . . . . . . . . . . . . . . . . . . 93
warning lamps . . . . . . . . . . . . . . . . . . . . . . . . . . 32
GRA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174 see also Cruise control . . . . . . . . . . . . . . . . . . . 174
H
Handbrake . . . . . . . . . . . . . . . . . . . . . . . . . 152, 154
Hand brake control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Hazard warning lights . . . . . . . . . . . . . . . . . 19, 121
HBA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154 Head-protection airbags
desc ription . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
safety instructions . . . . . . . . . . . . . . . . . . . . . . . 70
Headlight range control . . . . . . . . . . . . . . . . . . . . 117
Headlights change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
driving abroad . . . . . . . . . . . . . . . . . . . . . . . . . 122
headlight washers . . . . . . . . . . . . . . . . . . . . . . 126
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
front head restraints . . . . . . . . . . . . . . . . . . . . . . 59
rear head restraints . . . . . . . . . . . . . . . . . . . . . . 59
Headrests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Heated rear window . . . . . . . . . . . . . . . . . . . . . . . 123
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144 air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . 144
introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
rear window . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Heating and fresh air . . . . . . . . . . . . . . . . . . . . . . . 38
HHC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Hill hold control . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
How to jump start . . . . . . . . . . . . . . . . . . . . . . . . . . 51 description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
I
Identifying letters on engine . . . . . . . . . . . . . . . . 221
Ignition . . . . . . . . . . . . . . . . . . . . . . . . . 18, 149, 151
Ignition lock . . . . . . . . . . . . . . . . . . . . . 18, 149, 151
Incorrect sitting position . . . . . . . . . . . . . . . . . . . . 58
Indications on the display . . . . . . . . . . . . . . . . . . . 95 assist systems submenu . . . . . . . . . . . . . . . . . . 26
compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
distance travelled . . . . . . . . . . . . . . . . . . . . . . . . 95 doors, bonnet and rear lid open . . . . . . . . . . . . 25
driver inform
ation system . . . . . . . . . . . . . . . . . 23
driving data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
ECO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
MKB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
outside temperature . . . . . . . . . . . . . . . . . . . . . . 24
recommended gear . . . . . . . . . . . . . . . . . . . . . . 96
second speed display . . . . . . . . . . . . . . . . . . . . 96
selector lever position . . . . . . . . . . . . . . . 96, 158
service intervals . . . . . . . . . . . . . . . . . . . . . . . . . 30
speed warning . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Start-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
warning and information messages . . . . . . . . . 26
Infotainment system . . . . . . . . . . . . . . . . . . . . . . . 21
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Inspection service . . . . . . . . . . . . . . . . . . . . . . . . 205
Instrument panel . . . . . . . . . . . . . . . . . . . . . . . . . . 94 display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94, 95
instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
service interval indication . . . . . . . . . . . . . . . . . 30
warning and control lamps . . . . . . . . . . . . . . . . 98
warning and indication lamps . . . . . . . . . . . . . . 98
Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Interior lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Interior view left guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
right-hand drive . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
ISOFIX system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
J Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46, 75 mounting points . . . . . . . . . . . . . . . . . . . . . . . . . 48
237

Index
Top Tether system . . . . . . . . . . . . . . . . . . . . . . . . . 17
T o
w-
starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Tow-starting the engine . . . . . . . . . . . . . . . . . . . . . 78
Tow-starting the vehicle . . . . . . . . . . . . . . . . . . . . . 78
Towing bracket device . . . . . . . . . . . . . . . . . . . . . 184
Towing the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 50
Towline anchorages . . . . . . . . . . . . . . . . . . . . . . . . 50 front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Traction control . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Traction control system . . . . . . . . . . . . . . . . . . . . 154
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184 ball coupling . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
correct placement . . . . . . . . . . . . . . . . . . . . . . . 189
driving with a trailer . . . . . . . . . . . . . . . . . . . . . 185
parking Aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
service position . . . . . . . . . . . . . . . . . . . . . . . . 187
towing bracket device . . . . . . . . . . . . . . . . . . . 186
trailer weights . . . . . . . . . . . . . . . . . . . . . . . . . . 184
use and maintenance . . . . . . . . . . . . . . . . . . . . 191
Trailer weights . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
Transporting children . . . . . . . . . . . . . . . . . . . . . . . 72
Transporting items carrier system . . . . . . . . . . . . . . . . . . . . . . . . . . 141
roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Trip recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Tyre mobility set . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
sealing a tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Tyre Mobility Set inflating a tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Tyre Mobility System see Anti-puncture kit . . . . . . . . . . . . . . . . . . . . . 76
Tyre monitoring system . . . . . . . . . . . . . . . . . . . . 219
Tyre pressure monitoring control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Tyre pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Tyre Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216 Tyre repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Tyr
e repair kit
see Anti-puncture kit . . . . . . . . . . . . . . . . . . . . . 76
Tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215 changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
new tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
useful life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
wear indicators . . . . . . . . . . . . . . . . . . . . . . . . . 216
with compulsory direction of rotation . . . . . . . . 49
with directional tread pattern . . . . . . . . . . . . . 218
Tyre tread depth . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Tyre wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
U Unfasten the seat belt . . . . . . . . . . . . . . . . . . . . . . 12
Unlocking central locking . . . . . . . . . . . . . . . . . . . . . . . . . 108
remote control . . . . . . . . . . . . . . . . . . . . . . . . . 104
Unlocking and locking . . . . . . . . . . . . . . . . . . . . . . . 9 with Keyless Access . . . . . . . . . . . . . . . . . . . . . 110
with the central locking button . . . . . . . . . . . . 109
USB/AUX-IN input . . . . . . . . . . . . . . . . . . . . . . . . 104
V Vehicle chassis number . . . . . . . . . . . . . . . . . . . . . . . . 221
data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
identification data . . . . . . . . . . . . . . . . . . . . . . 221
identification number . . . . . . . . . . . . . . . . . . . . 221
raising . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
unlocking and locking with Keyless Access . . 110
Vehicle battery . . . . . . . . . . . . . . . . . . . . . . . 41, 211 assisted starting . . . . . . . . . . . . . . . . . . . . . . . . . 51
automatic disconnection of electrical equip-ment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
checking electrolyte level . . . . . . . . . . . . . . . . . 213 connecting and disconnecting . . . . . . . . . . . . 211
disc
onnect and connect . . . . . . . . . . . . . . . . . . . 31
lifting the cover . . . . . . . . . . . . . . . . . . . . . . . . . 212
replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
winter conditions . . . . . . . . . . . . . . . . . . . . . . . 211
winter service . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Vehicle care car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
cleaning of chromed parts . . . . . . . . . . . . . . . . 195 headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
heated seats . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
high-pressure cleaners . . . . . . . . . . . . . . . . . . 194
paint polishing . . . . . . . . . . . . . . . . . . . . . . . . . 195
rubber seals . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
stickers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
waxing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
wheel cleaning . . . . . . . . . . . . . . . . . . . . . . . . . 197
windscreen wipers service position . . . . . . . . . 53
Vehicle interior monitoring and anti-tow system activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Vehicle seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . 46, 75
Vehicle underbody protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Vehicle washing . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Ventilation slits . . . . . . . . . . . . . . . . . . . . . . . . . . 137
W Warning and control lamps . . . . . . . . . . . . . . . 32, 98 ABS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
ASR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
audible warning signal . . . . . . . . . . . . . . . . . . . 98
coolant temperature . . . . . . . . . . . . . . . . . . . . . 208
engine management . . . . . . . . . . . . . . . . . . . . 165
engine pre-heating/fault system . . . . . . . . . . . 165
hand brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
241
