2016 Seat Alhambra sensor

Care and maintenance
●
All
repairs and modifications to the vehicle
should only be performed by a specialised
workshop. Repairs and malfunctions in the air-
bag sy
s

tem When performing repairs and technical mod-
ification
s,

SEAT's directives must be ob-
served! ››› Modifications and repairs to the front bump-
er
, door
s, fr

ont seats, and repairs to the roof
or chassis should only be carried out in a
specialised workshop. These components
may contain parts or sensors belonging to
the airbag system.
If work is carried out on the airbag system or
parts have to be removed and fitted on the
system when performing other repair work,
parts of the airbag system may be damaged.
The consequence may be that, in the event of
an accident, the airbag inflates incorrectly or
does not inflate at all.
So that the effectiveness of the airbag is not
reduced and that removed parts do not cause
any injuries or environmental pollution, regu-
lations must be observed. These require-
ments are known to specialised workshops.
Modifications to the vehicle suspension may
affect the operation of the airbag system in
the event of collision. For example, if wheel and tyre combinations not approved by SEAT
are used, or if

the vehicle height is lowered,
the suspension is stiffened or the suspension
springs, telescopic arms, dampers, etc., are
modified, the results received by the airbag
sensors and sent to the control unit may not
be accurate. For example, some modifica-
tions to the suspension could increase the
force measured by the sensors and result in
the triggering of the airbag systems in colli-
sions. Under normal conditions, the meas-
ured values would be lower and the airbag
would not have been triggered. Other modifi-
cations may reduce the forces measured by
the sensors and prevent the airbags from be-
ing triggered when they should. WARNING
Repairs or modifications which are not per-
formed c orr

ectly may result in damage or er-
rors in the vehicle operation, affecting the ef-
fectiveness of the airbag systems. This could
result in serious or fatal accidents.
● All repairs and modifications to the vehicle
should on
ly be performed by a specialised
workshop.
● Airbag modules must never be repaired: if
damag
ed, they must be replaced.
● Never fit recycled or reused airbag compo-
nents in
your vehicle. WARNING
Modifications to the vehicle suspension, in-
cludin g the u

se of unauthorised wheel and
tyre combinations, may affect the perform-
ance of the airbags and increase the risk of
serious or fatal injury in the event of acci-
dent.
● Never fit suspension components which are
not identica
l to the original parts in the vehi-
cle.
● Never use wheel and tyre combinations not
appro
ved by SEAT. Retrofitting of mobile phones
An exterior aerial is required for the use of
tw
o-w
a

y radios in the vehicle.
The retro-fitting of electrical or electronic ap-
pliances in the vehicle is subject to their ap-
proval for use in your vehicle. Under certain
circumstances, this could mean that your ve-
hicle registration documents are no longer
valid.
SEAT has approved your vehicle for use with
two-way radios providing the following condi-
tions are observed:
● The exterior aerial must be mounted pro-
fes
sionally.
● The maximum transmitting power is 10
watts. »
249
Technical data
Advice
Operation
Emergencies
Safety

Advice
Automatic car washes
A lw
a
ys observe the instructions provided at
the automatic car wash. The standard pre-
cautionary measures prior to entering the car
wash should be taken to avoid damage to
the vehicle (close all windows, fold in exterior
mirrors). If the vehicle is fitted with additional
components (spoiler, roof-rack, aerial, etc.),
check with the car wash supervisor whether
these can enter the car wash ››› .
The v
ehic

le paintwork is so durable that the
vehicle can normally be washed without
problems in an automatic car wash tunnel.
However, wear and damage to the paintwork
will depend on the type of car wash used.
SEAT recommends the use of car washes
without brushes.
To remove traces of wax on windows and to
prevent wiper blades from scratching, please
observe the following ››› page 255, Cleaning
windows and exterior mirrors .
Washing the car by hand
When washing the car by hand, use plenty of
water to soften the dirt first, and rinse off as
well as possible.
Then clean the vehicle with a soft sponge,
glove or brush using only slight pressure.
Start at the roof and work downwards. Spe-
cial car shampoo should only be used for
very persistent dirt. Rinse the sponge or glove thoroughly and of-
ten.
Wheels, s

ills and similar should be cleaned
last. Use a second sponge for this. WARNING
Sharp components on the vehicle may cause
injury .
● Pr

otect arms and hands from sharp edges
when cle
aning the vehicle undercarriage or
the interior of the wheel hubs. WARNING
After the vehicle has been washed, the brak-
ing eff ect

will be reduced (and the braking
distance increased) due to moisture (and ice
in winter) on the brakes.
● “Dry the brakes and remove ice” by braking
caref
ully. Ensure that you are not endanger-
ing other road-users or breaking traffic regu-
lations in the process. CAUTION
● The temper at

ure of the water must not ex-
ceed +60°C (+140°F).
● To avoid damage to the paintwork, do not
wash the
vehicle in full sun.
● Do not use rough sponges or similar which
coul
d damage the surface to clean away the
traces of insects. ●
Never w ipe the he

adlights with a dry cloth
or sponge, always moisten first. It is best to
use soapy water.
● Washing the vehicle in low temperatures:
When washin
g the vehicle with a hose, do
not direct water into the lock cylinders or the
gaps around the doors or roof. Locks and
seals could freeze! CAUTION
To avoid any risk of damage to the vehicle,
p le

ase check the following points before us-
ing an automatic car wash:
● Compare the distance between the vehicle
wheels and the di
stance between the guide-
rails of the car wash to prevent damage to the
wheels and tyres!
● Switch off the rain sensor and the Au-
to Hol
d function before entering a car wash.
● Compare the height and width of your vehi-
cle w
ith the available height and width when
entering and driving through the car wash.
● Fold in exterior mirrors Electrically retracta-
ble e
xterior mirrors must not be folded in or
out by hand. Always use the electrical power
control.
● To avoid damaging the bonnet paintwork,
res
t the wipers on the windscreen after dry-
ing them. Do not let them fall!
● Lock the rear lid to prevent it from opening
unexpect
edly while inside the car wash.254

Care and maintenance
Washing the vehicle with a high pres-
s ur
e c
leaner When cleaning the vehicle with a high-pres-
sur
e c

leaner, always follow the operating in-
structions for the equipment. Pay special at-
tention to the required pressure of the jet
and the distance between the jet and the ve-
hicle ››› .
Keep a s uit

able distance from soft materials,
such as rubber hoses or insulating material,
and from the parking distance warning sys-
tem sensors. The parking distance sensors
are fitted in the rear bumpers and, where ap-
plicable, in the front bumpers ››› .
Do not u
se a no

zzle that sprays the water out
in a direct stream or one that has a rotating
jet for forcing off dirt ››› .
WARNING
The incorrect use of high pressure cleaning
equipment c ou

ld result in permanent dam-
age, visible or invisible, to the tyres or other
materials. This could result in a serious acci-
dent.
● Ensure there is a suitable distance between
the nozzl
e and the tyres.
● Never wash tyres with a concentrated jet or
so-cal
led “dirt blasters”. Even at large spray-
ing distances and short cleaning times, you
may damage the tyres. WARNING
After the vehicle has been washed, the brak-
ing eff ect

will be reduced (and the braking
distance increased) due to moisture (and ice
in winter) on the brakes.
● “Dry the brakes and remove ice” by braking
caref
ully. Ensure that you are not endanger-
ing other road-users or breaking traffic regu-
lations in the process. CAUTION
● The wat er t

emperature should not exceed
+60°C (+140°F).
● To avoid damage to the paintwork, do not
wash the
vehicle in full sun.
● The sensors on the bumpers should be kept
cle
an and free of ice at all times to ensure the
parking distance warning system and the
park assist system operate correctly. When
cleaning with pressure hoses and steam
cleaners, the sensors should be sprayed only
briefly. A distance of 10 cm between the sen-
sors and the steam / hose nozzle must be ob-
served.
● Do not use a high pressure cleaner to re-
move ic
e or snow from windows
● Washing the vehicle in low temperatures:
When washin
g the vehicle with a hose, do
not direct water into the lock cylinders or the
gaps around the doors or roof. Locks and
seals could freeze! Cleaning windows and exterior mir-
r
or
s Cleaning windows and exterior mirrors
Spr
a

y windows and exterior windows with a
standard window cleaner containing alcohol.
Dry the windows with a clean chamois leath-
er or a lint-free cloth. The chamois leathers
used on painted surfaces are not suitable for
cleaning windows because they are soiled
with wax deposits which could smear the
windows.
Use window cleaner or a silicone remover to
clean rubber, oil, grease and silicone depos-
its off ››› .
R emo
v

ing wax residue
Automatic car washes and certain car care
products may leave wax deposits on the win-
dows. These deposits can only be removed
with a special product or cleaning cloths.
Wax deposits on the windscreen could cause
the wiper blades to judder. SEAT recom-
mends you wipe the wax deposits off the
windscreen with a soft cloth each time after
you have washed the vehicle.
A window cleaning detergent which helps to
dissolve the wax may be added to the wind-
screen washer fluid to prevent the wiper
blades from scratching the windscreen.
Please ensure you add the cleaning product
in the correct proportions. Products for »
255
Technical data
Advice
Operation
Emergencies
Safety

Advice
The checking and refilling of service fluids
ar e c
arried out
on the components men-
tioned above. These operations are descri-
bed in ››› page 272.
Overview
Further explanations, instructions and restric-
tions on the technical data are contained as
of ››› page 298
Engine oil Introduction WARNING
Incorrectly handling engine oil can cause in-
jury and seriou

s burns.
● Always protect your eyes when handling
engine oil
.
● Oil is toxic and must be kept out of the
reac
h of children.
● Engine oil should only be kept in its origi-
nal
packaging; the same goes for used oil un-
til it is disposed of.
● Never store engine oil in empty food con-
tainers
or bottles as other people may acci-
dentally drink it.
● Regular contact with engine oil can be bad
for the skin. If
you come into contact with en-
gine oil, wash your skin with soap and water. ●
With the en gine ru

nning, the engine oil
gets extremely hot and can cause severe skin
burns. Always wait until the engine has fully
cooled. For the sake of the environment
Similar to the other service liquids, spilled
en gine oi l

can be bad for the environment.
Collect these liquids in suitable containers
and dispose of them while respecting the en-
vironment. Warning and indication lamps

It lights up
Insufficient en-
gine oil.Switch the ignition off. Check the en-
gine oil level
››› page 277. 
Flashes
Engine oil sen-
sor faulty.Contact a specialised workshop.
Have the engine oil sensor checked.
Meanwhile, check the oil level man-
ually. 
Flashes
Engine oil pres-
sure too low.

Stop the vehicle!
Switch off the engine. Check the en-
gine oil level.
- If the warning lamp flashes al-
though the oil level is correct, do not
continue driving or leave the engine
running. Otherwise, the engine
could be damaged. Seek specialist
assistance. WARNING
Observe the safety warnings ›››
in Warning
and indication l amp
s on page 105. Engine oil specifications
Replacement engine oil must strictly comply
w
ith the s
pec

ifications.
The correct oil must be used to ensure the
correct operation and long service life of the
engine. The engine comes with a high-quality
multigrade oil that can generally be used all
year round.
Only use an engine oil that complies to SEAT
standards whenever possible ››› . If you
w i
sh t

o maintain the long-life service dura-
tion, only engine oils approved for this serv-
ice according to the corresponding VW stand-
ard ( ›››
 table on page 40) may be used.
All oils indicated are synthetic multigrade
oils.
276

Index
Central locking system . . . . . . . . . . . . . . . . . . . . . 114 aft
er airb
ag deployment . . . . . . . . . . . . . . . . . 115
Anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . 119
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Emergency locking and unlocking . . . . . . . . . . . . 9
keyless Access . . . . . . . . . . . . . . . . . . . . . . . . . 117
opening doors individually . . . . . . . . . . . . . . . 115
remote control key . . . . . . . . . . . . . . . . . . . . . . 115
Centre armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . 45, 84 subsequent work . . . . . . . . . . . . . . . . . . . . . . . . 49
wheel bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Changing bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . 91 body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
front bumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
halogen headlights . . . . . . . . . . . . . . . . . . . . . . 92
number plate light . . . . . . . . . . . . . . . . . . . . . . . 97
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
rear lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
xenon headlights . . . . . . . . . . . . . . . . . . . . . . . . 93
Changing gear Control and warning lamps . . . . . . . . . . . . . . . 195
Changing gears automatically . . . . . . . . . . . . . . . 196
Changing the blades . . . . . . . . . . . . . . . . . . . . . . . 87
Changing windscreen wipers . . . . . . . . . . . . . . . . 54
Charging the battery . . . . . . . . . . . . . . . . . . . . . . . 51
Checking tyre pressures . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Checking fluid levels . . . . . . . . . . . . . . . . . . . . . . 275
Child safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Child seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 deactivating the passenger front airbag . . . . . . 18
disabling the front passenger front airbag . . . . 73
integrated child seat . . . . . . . . . . . . . . . . . . . . . 78
in the passenger seat . . . . . . . . . . . . . . . . . . . . . 76
ISOFIX system . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 mounting systems . . . . . . . . . . . . . . . . . . . . . . . 22
on rear se
ats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
safety instructions . . . . . . . . . . . . . . . . . . . . 20, 75
securing with seat belt . . . . . . . . . . . . . . . . . . . . 22
Top Tether system . . . . . . . . . . . . . . . . . . . . . . . . 23
transporting children in the vehicle . . . . . . . . . 75
weight categories . . . . . . . . . . . . . . . . . . . . . . . . 76
Child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Chrome parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Cigarette lighter . . . . . . . . . . . . . . . . . . . . . 172, 173
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253 compartments . . . . . . . . . . . . . . . . . . . . . . . . . 262
dash panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
engine compartment . . . . . . . . . . . . . . . . . . . . 258
fabrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
folding the rear view mirrors . . . . . . . . . . . . . . 142
natural leather . . . . . . . . . . . . . . . . . . . . . . . . . 261
seatbelts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
synthetic leather . . . . . . . . . . . . . . . . . . . . . . . . 261
textile covers . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
trims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
washing the vehicle . . . . . . . . . . . . . . . . . . . . . 253
Washing the vehicle with high pressure clean-ers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Cleaning the vehicle high pressure cleaners . . . . . . . . . . . . . . . . . . . 255
Climatronic . . . . . . . . . . . . . . . . . . . . . . . . . . 36, 176
Closing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112 bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
electric windows . . . . . . . . . . . . . . . . . . . . . . . . . 11
luggage compartment . . . . . . . . . . . . . . . 10, 125
panoramic sunroof . . . . . . . . . . . . . . . . . . . . . . . 12
Clothes hook . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Code number . . . . . . . . . . . . . . . . . . . . . . . . . . 45, 83
Combined weight rating . . . . . . . . . . . . . . . . . . . 245 Coming Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Compar
tments
centre console . . . . . . . . . . . . . . . . . . . . . . . . . 167
Front central armrest . . . . . . . . . . . . . . . . . . . . 168
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Connectors faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Consumption how it is determined . . . . . . . . . . . . . . . . . . . . 269
information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Control and warning lamps Changing gear . . . . . . . . . . . . . . . . . . . . . . . . . 195
for the seat belt . . . . . . . . . . . . . . . . . . . . . . . . . 62
fuel level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Lane Assist system . . . . . . . . . . . . . . . . . . . . . . 223
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Control of function rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Controls on the steering wheel operating the audio system . . . . . . . . . . . . . . . 107
operating the audio system and telephone . . 108
Control units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 reprogramming . . . . . . . . . . . . . . . . . . . . . . . . . 250
Convenience closing windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Convenience functions Reprogramming . . . . . . . . . . . . . . . . . . . . . . . . 250
Convenience opening windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Convenient entry function for the third row of seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Cooling system checking the coolant . . . . . . . . . . . . . . . . . . . . 279
topping up with coolant . . . . . . . . . . . . . . . . . . 279
309

Index
Parking assistant (RTA) . . . . . . . . . . . . . . . 225, 229 contr
o
l lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Parking brake Automatic release . . . . . . . . . . . . . . . . . . . . . . . 192
connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
disengaging . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
electronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
emergency braking function . . . . . . . . . . . . . . 192
Parking distance warning system . . . . . . . . . . . . 211 fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
optical parking system . . . . . . . . . . . . . . . . . . . 213
with towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Parking light . . . . . . . . . . . . . . . . . . . . . . . . 131, 212
Passenger front airbag disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58, 60
Petrol additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Polishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Portable waste bin . . . . . . . . . . . . . . . . . . . . . . . . 170
Power brake system Anti-lock system . . . . . . . . . . . . . . . . . . . . . . . . 206
Power socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 12 volts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Pre-heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Protection of vehicle undercarriage . . . . . . . . . . 258
Puncture action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Pushing the vehicle . . . . . . . . . . . . . . . . . . . . . . . 185
R Radio-operated remote control see Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112 Radio reception
antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263
operating faults . . . . . . . . . . . . . . . . . . . . . . . . 264
Rails and attachment element system baggage net . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Rails and attachment system . . . . . . . . . . . . . . . 160
Rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 Control of function . . . . . . . . . . . . . . . . . . . . . . 139
Raising the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 47 lift platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Rear assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217 fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
instructions for use . . . . . . . . . . . . . . . . . . . . . 218
mode 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
mode 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
things to note . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Rear door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Rear lid warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . 124
see also Luggage compartment . . . . . . . . . . . 124
Rear Traffic Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Rear view camera . . . . . . . . . . . . . . . . . . . . . . . . . 217
Rear view mirrors adjusting the exterior mirrors . . . . . . . . . . . . . 141
adjusting the interior mirror . . . . . . . . . . . . . . . 16
Recommended gear . . . . . . . . . . . . . . . . . . . . . . . 199
Recycled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Reflective vest . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Refuelling control and warning lamps . . . . . . . . . . . . . . . 266
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
mistakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
opening fuel tank flap . . . . . . . . . . . . . . . . . . . 266
Remote control key unlocking and locking . . . . . . . . . . . . . . . . . . . 115 Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248, 264
airbag sys tem . . . . . . . . . . . . . . . . . . . . . . . . . . 249
Repair work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
Replacement parts . . . . . . . . . . . . . . . . . . . . . . . . 247
Replacing bulbs see Changing bulbs . . . . . . . . . . . . . . . . . . . . . . 91
Reprogramming control units . . . . . . . . . . . . . . . 250
Retaining hooks . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Rev counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Rims changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . 45
Roll-back function windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Rollback anti-trap function electric sliding doors . . . . . . . . . . . . . . . . . . . . 123
Roof carrier system . . . . . . . . . . . . . . . . . . . . . . . . 164 fastening the supports . . . . . . . . . . . . . . . . . . . 164
Roof rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
RTA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229 see Parking assistant . . . . . . . . . . . . . . . . . . . . 225
Rubber seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Run-flat tyres codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
Run-in tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Running in brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
new engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
S
Safe driving safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
SAFE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119, 189
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 child safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
315

Index
Treadwear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
T urn s
ign
al convenience function . . . . . . . . . . . . 131
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Type of fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Tyre control systems tyre pressures . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Tyre load rating . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
Tyre mobility set . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
more than one damaged tyre . . . . . . . . . . . . . . 85
Tyre mobility system cases where it should not be used . . . . . . . . . . 85
check after 10 minutes . . . . . . . . . . . . . . . . . . . . 86
inflating a tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
sealing a tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Tyre Mobility System see Anti-puncture kit . . . . . . . . . . . . . . . . . . . . . 85
Tyre monitoring systems . . . . . . . . . . . . . . 234, 236 control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Tyre pressure . . . . . . . . . . . . . . . . . . . . . . . 292, 300
Tyre profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Tyre repair kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 see also Anti-puncture kit . . . . . . . . . . . . . . . . . 85
Tyres avoiding damage . . . . . . . . . . . . . . . . . . . . . . . 289
changing . . . . . . . . . . . . . . . . . . . . . . . . . . 45, 290
code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
deterioration . . . . . . . . . . . . . . . . . . . . . . . . . . . 294
errors in wheel alignment . . . . . . . . . . . . . . . . 294
foreign bodies in the tyres . . . . . . . . . . . . . . . . 294
handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
new . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
old . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
run-flat tyre codes . . . . . . . . . . . . . . . . . . . . . . . 295
run-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294 serial number . . . . . . . . . . . . . . . . . . . . . . . . . . 295
snow c
hains . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
speed rating . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
technical details . . . . . . . . . . . . . . . . . . . . . . . . 295
tyre code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
tyre identification number (TIN) . . . . . . . . . . . . 295
tyre load rating . . . . . . . . . . . . . . . . . . . . . . . . . 296
tyre pressure sensor . . . . . . . . . . . . . . . . . . . . . 293
tyres with directional tread pattern . . . . . . . . . 296
tyre wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294
valve caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
wear indicators . . . . . . . . . . . . . . . . . . . . . . . . . 293
wheel balancing . . . . . . . . . . . . . . . . . . . . . . . . 294
wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
winter tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
with directional tread pattern . . . . . . . . . . . . . . 49
Tyres with directional tread pattern . . . . . . . . . . 296
Tyre tread depth . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Tyre wear . . . . . . . . . . . . . . . . . . . . . . . . . . . 293, 294
U Unfastening the seat belt . . . . . . . . . . . . . . . . 15, 64
Unlocking and locking . . . . . . . . . . . . . . . . . . . . . . . 8 by remote control . . . . . . . . . . . . . . . . . . . . . . . 115
doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
from inside . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Upholstery cleaning textile covers . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
upholstery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
USB/AUX-IN input . . . . . . . . . . . . . . . . . . . 110, 166
V Valve caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Vanity mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136 Vehicle
cha ssis number . . . . . . . . . . . . . . . . . . . . . . . . 298
data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
identification data . . . . . . . . . . . . . . . . . . . . . . 298
identification number . . . . . . . . . . . . . . . . . . . . 298
loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Parking downhill . . . . . . . . . . . . . . . . . . . . . . . . 192
parking uphill . . . . . . . . . . . . . . . . . . . . . . . . . . 192
raising . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Vehicle battery . . . . . . . . . . . . . . . . . . . . . . . 41, 284 acid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
assisted starting . . . . . . . . . . . . . . . . . . . . . . . . . 51
automatically disconnecting devices . . . . . . . 287
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
checking the battery electrolyte level . . . . . . . 286
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
discharging . . . . . . . . . . . . . . . . . . . . . . . 183, 186
disconnecting . . . . . . . . . . . . . . . . . . . . . 105, 286
Positive terminal for starting assistance . . . . . . 52
preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
running flat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
starting assistance . . . . . . . . . . . . . . . . . . . . . . . 52
warning and indication lamps . . . . . . . . . . . . . 285
Vehicle care Airbag modules (dash panel) . . . . . . . . . . . . . 262
anodized surfaces . . . . . . . . . . . . . . . . . . . . . . 257
antenna incorporated in window . . . . . . . . . . . 263
chrome parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
cleaning wheels . . . . . . . . . . . . . . . . . . . . . . . . 257
Dash panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
De-icing the door lock cylinder . . . . . . . . . . . . 257
engine compartment . . . . . . . . . . . . . . . . . . . . 258
exterior mirrors . . . . . . . . . . . . . . . . . . . . . . . . . 255
interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Plastic parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
318

Index
protection of vehicle undercarriage . . . . . . . . 258
rubber se al
s
. . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Special features . . . . . . . . . . . . . . . . . . . . . . . . 254
vehicle paintwork . . . . . . . . . . . . . . . . . . . . . . . 256
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Wooden trim . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Vehicle care products . . . . . . . . . . . . . . . . . . . . . . 253
Vehicle code Vehicle data label . . . . . . . . . . . . . . . . . . . . . . . 298
Vehicle data label . . . . . . . . . . . . . . . . . . . . . . . . . 298
Vehicle key set . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . 45, 82 components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Vehicle undercarriage guard . . . . . . . . . . . . . . . . . 56
Vibrations steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294
Voice control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
W Warning and control lamp ABS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
adBlue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
blind spot detector (BSD) . . . . . . . . . . . . . . . . 225
brake system . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
catalytic converter . . . . . . . . . . . . . . . . . . . . . . 202
changing bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . 92
coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Cruise Control System (CCS) . . . . . . . . . . . . . . 221
door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
emission control system . . . . . . . . . . . . . . . . . 202
engine management . . . . . . . . . . . . . . . . . . . . 202
engine oil sensor . . . . . . . . . . . . . . . . . . . . . . . 276
ESC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 285 indication of break pad wear . . . . . . . . . . . . . . 190
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
lock
ing the steering column . . . . . . . . . . . . . . 184
overview . . . . . . . . . . . . . . . . . . . . . . . . . . 32, 105
parking assistance (RTA) . . . . . . . . . . . . . . . . . 225
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
remote control . . . . . . . . . . . . . . . . . . . . . . . . . 181
tyre monitoring indicator . . . . . . . . . . . . . . . . . 235
vehicle battery . . . . . . . . . . . . . . . . . . . . . . . . . 285
windscreen washer fluid level . . . . . . . . . . . . . 137
Warning lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Warning triangle . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Washing the vehicle . . . . . . . . . . . . . . . . . . . . . . . 253 sensors . . . . . . . . . . . . . . . . . . . . . . . . . . 211, 214
special features . . . . . . . . . . . . . . . . . . . . . . . . 254
things to note . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Wax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Wear indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
Wheel bolts . . . . . . . . . . . . . . . . . . . . . . . . . . 84, 300 anti-theft . . . . . . . . . . . . . . . . . . . . . . . . 45, 83, 84
caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
loosen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
tightening torque . . . . . . . . . . . . . . . . . . . . . . . . 47
Wheel load capacity . . . . . . . . . . . . . . . . . . . . . . . 295
Wheel rims beadlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
bolted trims . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Wheels . . . . . . . . . . . . . . . . . . . . . . . . 288, 290, 300 changing a wheel . . . . . . . . . . . . . . . . . 45, 48, 84
hubcaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Wheels and tyres speed rating . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
Wheel trim hubcaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
remove . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Windows
automatic operation . . . . . . . . . . . . . . . . . . . . . 127
automatic raising/lowering . . . . . . . . . . . . . . . 127
convenience closing . . . . . . . . . . . . . . . . . . . . . 127
convenience opening . . . . . . . . . . . . . . . . . . . . 127
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
removing ice . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
roll-back function . . . . . . . . . . . . . . . . . . . . . . . 128
Window wiper . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Window wiper blade . . . . . . . . . . . . . . . . . . . . . . . . 26
Windscreen and rear window wiper blades . . . . . 87
Windscreen washer . . . . . . . . . . . . . . . . . . . 41, 137
Windscreen washer fluid checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Topping up . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Windscreen wipers . . . . . . . . . . . . . . . . . . . . 26, 137 functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
headlight washer system . . . . . . . . . . . . . . . . . 138
heated windscreen washer jets . . . . . . . . . . . . 138
lifting the wiper blade . . . . . . . . . . . . . . . . . . . . 54
rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
replacing the wiper blade . . . . . . . . . . . . . . . . . 54
service position . . . . . . . . . . . . . . . . . . . . . . . . . 54
special features . . . . . . . . . . . . . . . . . . . . . . . . 138
window wiper lever . . . . . . . . . . . . . . . . . . . . . . 137
Windscreen wipers service position . . . . . . . . . . . 54
Wing mirrors driving with a trailer . . . . . . . . . . . . . . . . . . . . . 238
Winter additional heater . . . . . . . . . . . . . . . . . . . . . . . 180
menu configuration . . . . . . . . . . . . . . . . . . . . . . 30
Winter driving Driving with a trailer . . . . . . . . . . . . . . . . . . . . . 237
filter pre-heater . . . . . . . . . . . . . . . . . . . . . . . . . 268
winter-grade diesel . . . . . . . . . . . . . . . . . . . . . 268
winter tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
319
