Vehicles Equipped With Passive Entry
1. Without pressing the brake pedal, press the ENGINESTART/STOP button and place the ignition in the
ON/RUN position (do not start the engine.)
2. Press and release the DOWNarrow button to scroll
downward through the main menu to “Vehicle Info”.
3. Press and release the RIGHTarrow button to access
the ”Fuel Filter Life” screen.
4. Press and hold the RIGHTarrow button for one
second to access the Reset Confirmation screen.
5. Press and release the UPorDOWN arrow button to
select “Yes” or “No” then press and hold the RIGHT
arrow button to reset the Fuel Filter Life.
6. Press and release the Uparrow button to exit the EVIC
screen once the Fuel Filter Life is 100% Vehicles Not Equipped With Passive Entry
1. Without pressing the brake pedal, cycle the ignition to
the ON/RUN position (do not start the engine.)
2. Press and release the DOWNarrow button to scroll
downward through the main menu to “Vehicle Info”.
3. Press and release the RIGHTarrow button to access
the ”Fuel Filter Life” screen.
4. Press and hold the RIGHTarrow button for one
second to access the ”Fuel Filter Life Reset” screen.
5. Press and hold the RIGHTarrow button for one
second to access the Reset Confirmation screen.
6. Press and release the UPorDOWN arrow button to
select “Yes” or “No” then press and hold the RIGHT
arrow button to reset the Fuel Filter Life.
7. Press and release the Uparrow button to exit the EVIC
screen once the Fuel Filter Life is 100%
4
UNDERSTANDING YOUR INSTRUMENT PANEL 253

NOTE:If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
Oil Life Reset
Your vehicle is equipped with an engine oil change
indicator system. The “Oil Change Required” message
will flash in the DID display for approximately 10
seconds after a single chime has sounded, to indicate the
next scheduled oil change interval. The engine oil change
indicator system is duty cycle based, which means the
engine oil change interval may fluctuate, dependent
upon your personal driving style.
NOTE: Use the steering wheel DID controls for the
following procedure(s) Vehicles Equipped With Passive Entry
1. Without Pushing the brake pedal, push the ENGINE
START/STOP button and cycle the ignition to the
ON/RUN position (do not start the engine.)
2. Push and release the DOWNarrow button to scroll
downward through the main menu to “Vehicle Info”.
3. Push and release the RIGHTarrow button to access
the ”Oil Life” screen.
4. Push and hold the RIGHTarrow button for one
second to access the ”Oil Life Reset” screen.
5. Push and release the DOWNarrow button to select
“Yes”, then push and release the Rightarrow button to
select reset of the Oil Life.
6. Push and release the Uparrow button to exit the DID
screen.
254 UNDERSTANDING YOUR INSTRUMENT PANEL

Vehicles Not Equipped With Passive Entry
1. Without pushing the brake pedal, cycle the ignition tothe ON/RUN position (do not start the engine.)
2. Push and release the DOWNarrow button to scroll
downward through the main menu to “ Vehicle Info”.
3. Push and release the RIGHTarrow button to access
the ” Oil Life” screen.
4. Push and hold the RIGHTarrow button for one
second to access the ” Oil Life Reset” screen. 5. Push and release the
DOWNarrow button to select
“Yes”, then push and release the Rightarrow button to
select reset of the Oil Life.
6. Push and release the Uparrow button to exit the DID
screen.
NOTE: If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 255

STARTING AND OPERATING
CONTENTS
STARTING PROCEDURES ................260
▫ Manual Transmission — If Equipped .......261
▫ Automatic Transmission — If Equipped .....261
▫ Keyless Enter-N-Go — If Equipped ........261
▫ Extreme Cold Weather ..................265
▫ Normal Starting Procedure — Engine Manifold
Air Temperature Above 66° F (19° C) ........266
▫ Starting Procedure — Engine Manifold Air
Temperature 0°F To 66°F (–18°C to 19°C) .....267
▫ Starting Procedure — Engine Manifold Air
Temperature Below 0°F (-18°C) ............269▫
Starting Fluids ....................... .271
 NORMAL OPERATION — DIESEL ENGINE . . .272
▫ Cold Weather Precautions ................273
▫ Engine Idling ....................... .275
▫ Stopping The Engine ...................277
▫ Idle Shutdown ....................... .278
▫ Programmable Maximum Vehicle Speed
(Chassis Cab Only) ....................278
▫ Operating Precautions ..................279
5

▫Cooling System Tips — Automatic
Transmission ........................ .279
 ENGINE BLOCK HEATER — IF EQUIPPED . . .280
▫ Block Heater Usage ....................281
 DIESEL EXHAUST BRAKE
(ENGINE BRAKING) ....................281
 AUTOMATIC TRANSMISSION — IF
EQUIPPED .......................... .284
▫ Key Ignition Park Interlock ...............286
▫ Brake/Transmission Shift Interlock System . . .286
▫ Six-Speed Automatic Transmission — If
Equipped .......................... .286
 MANUAL TRANSMISSION — IF EQUIPPED . .298
▫ Shifting ............................ .299▫
Downshifting ....................... .300
▫ Reverse Shifting ..................... .302
 AUXILIARY SWITCHES — IF EQUIPPED .....302
 POWER TAKE OFF OPERATION — IF EQUIPPED
(CHASSIS CAB ONLY) ..................303
▫ Stationary Mode ..................... .304
▫ Mobile Mode ........................ .305
 ENGINE RUNAWAY ....................306
 FUEL REQUIREMENTS ..................307
▫ Fuel Specifications ....................308
▫ Bio-Diesel Fuel Requirements .............309
 ADDING FUEL — 2500/3500 DIESEL
MODELS ........................... .312
 ADDING FUEL — CHASSIS CAB MODELS . . .315
258 STARTING AND OPERATING

Manual Transmission — If Equipped
Apply the parking brake, place the shift lever in NEU-
TRAL and press the clutch pedal to the floor before
starting the vehicle. This vehicle is equipped with a
clutch interlocking ignition system. It will not start unless
the clutch is fully pressed.
Automatic Transmission — If Equipped
Start the engine with the transmission in the NEUTRAL
or PARK position. Apply the brake before shifting to any
driving range.
Tip Start Feature
Do notpress the accelerator. Turn the ignition switch
briefly to the START position and release it. The starter
motor will continue to run but will automatically disen-
gage when the engine is running.
Keyless Enter-N-Go — If Equipped
This feature allows the driver to oper-
ate the ignition switch with the push
of a button, as long as the Remote
Start/Keyless Enter-N-Go Key Fob is
in the passenger compartment.
Normal Starting
Using The ENGINE START/STOP Button
1. The transmission must be in PARK or NEUTRAL.
2. Press and hold the brake pedal while pushing the ENGINE START/STOP button once.
3. The system takes over and attempts to start the vehicle. If the vehicle fails to start, the starter will
disengage automatically after 25 seconds.
5
STARTING AND OPERATING 261

4. If you wish to stop the cranking of the engine prior tothe engine starting, remove your foot from the brake
pedal and push the button again.
NOTE:
• Normal starting of either a cold or a warm engine is
obtained without pumping or pressing the accelerator
pedal.
• Under cold weather conditions, the engine may not
immediately crank if the Wait To Starttelltale is
illuminated. This is normal operation. For vehicles
equipped with Keyless Enter-N-Go, the vehicle will
automatically crank when the Wait To Starttime has
elapsed. See the section Starting Procedure Engine
Manifold Air Temperature 0°F to 66°F (18° C to 19°C)
for more information. To Turn Off The Engine Using ENGINE START/STOP
Button
1. Place the shift lever/gear selector in PARK, then push
and release the ENGINE START/STOP button.
2. The ignition switch will return to the OFF position.
3. If the shift lever/gear selector is not in PARK, the ENGINE START/STOP button must be held for two
seconds or three short pushes in a row with the vehicle
speed above 5 mph (8 km/h) before the engine will
shut off. The ignition switch position will remain in
the ACC position until the shift lever/gear selector is
in PARK and the button is pushed twice to the OFF
position. If the shift lever/gear selector is not in PARK
and the ENGINE START/STOP button is pushed
once, the EVIC/DID will display a “Vehicle Not In
Park” message and the engine will remain running.
Never leave a vehicle out of the PARK position, or it
could roll.
262 STARTING AND OPERATING

NOTE:If the ignition switch is left in the ACC or RUN
(engine not running) position and the transmission is in
PARK, the system will automatically time out after 30
minutes of inactivity and the ignition will switch to the
OFF position.
ENGINE START/STOP Button Functions — With
Driver ’s Foot OFF The Brake Pedal (In PARK Or
NEUTRAL Position)
The ENGINE START/STOP button operates similar to an
ignition switch. It has three positions, OFF, ACC, RUN.
To change the ignition switch positions without starting
the vehicle and use the accessories follow these steps:
1. Starting with the ignition in the OFF position:
2. Push the ENGINE START/STOP button once to change the ignition to the ACC position. 3. Push the ENGINE START/STOP button a second time
to change the ignition to the RUN position.
4. Push the ENGINE START/STOP button a third time to return the ignition to the OFF position.
Keyless Enter-N-Go Starting Procedure — Engine
Manifold Air Temperature 0° F To 66° F (–18° C to
19° C)
NOTE: The temperature displayed in the Electronic
Vehicle Information Center (EVIC) or Driver information
Display (DID) does not necessarily reflect the engine
manifold air temperature. Refer to “Electronic Vehicle
Information Center (EVIC)” or Driver Information Dis-
play (DID)” in “Understanding Your Instrument Panel”
for further information. When engine temperatures fall
below 66°F (19°C) the “Wait To Start Light” will remain
on indicating the intake manifold heater system is active.5
STARTING AND OPERATING 263
