2016 Ram 1500 flat tire

WARNING!(Continued)
•If working on or near a roadway, be extremely
careful of motor traffic.
•To assure that spare tires, flat or inflated, are
securely stowed, spares must be stowed with the
valve stem facing the ground.
Jack Warning Label
Lug Wrench Adaptor Shown In Jack And Tools
Assembly
758 WHAT TO DO IN EMERGENCIES

5. Remove the wheel nuts and pull the wheel off. On
single rear-wheel (SRW) trucks, install the spare wheel
and wheel nuts with the cone shaped end of the wheel
nuts toward the wheel. On 3500 dual rear-wheel
models (DRW) trucks, if the outer tire is being re-
placed then leave the inner wheel on the vehicle. If the
inner wheel is being replaced remove the outer wheel
and replace the inner wheel. The wheel nuts are a
two-piece assembly with a flat face. Lightly tighten the
wheel nuts. To avoid the risk of forcing the vehicle off
the jack, do not fully tighten the wheel nuts until the
vehicle has been lowered.
Rear Inner Wheel Proper Placement (Dual Rear Wheel
Equipped)
762 WHAT TO DO IN EMERGENCIES

9. Adjust the tire pressure when possible.
NOTE:Do not oil wheel studs. For chrome wheels, do
not substitute with chrome plated wheel nuts.
To Stow The Flat Or Spare
NOTE: Have the flat tire repaired or replaced immedi-
ately.
WARNING!
A loose tire thrown forward in a collision or hard
stop could injure the occupants in the vehicle. Have
the deflated (flat) tire repaired or replaced immedi-
ately.1. Turn the wheel so that the valve stem is facing the
ground and toward the rear of the vehicle for conve-
nience in checking the spare tire inflation. Slide the
wheel retainer through the center of the wheel.
Reinstalling The Retainer
764 WHAT TO DO IN EMERGENCIES

flat blade on the end of the lug wrench to pull the caps
off. The wheel skin can now be removed.
CAUTION!
•Use a pulling motion to remove the hub cap. Do not
use a twisting motion when removing the hub cap,
damage to the hub cap; finish may occur.
•The rear hub caps on the dual rear wheel has two
pull off notches. Make sure that the hook of the
jack handle driver is located squarely in the cap
notch before attempting to pull off.
You must use the flat end of the lug wrench to pull off the
wheel skins. Locate the hub cap pull notches (2 notches
on each cap). Insert the flat tip completely and using a
back and forth motion, loosen the wheel skin. Repeat this
procedure around the tire until the skin pops off.Replace the wheel skins first using a rubber mallet. When
replacing the hub caps, tilt the cap retainer over the lug
nut bolt circle and strike the high side down with a
rubber mallet. Be sure that the hub caps and wheel skins
are firmly seated around the wheel.
HOISTING
A conventional floor jack may be used at the jacking
locations. Refer to the graphics that show jacking loca-
tions. However, a floor jack or frame hoist must never be
used on any other parts of the underbody.
CAUTION!
Never use a floor jack directly under the differential
housing of a loaded truck or damage to your vehicle
may result.
6
WHAT TO DO IN EMERGENCIES 769

WARNING!
The temperature grade for this tire is established for
a tire that is properly inflated and not overloaded.
Excessive speed, under-inflation, or excessive load-
ing, either separately or in combination, can cause
heat buildup and possible tire failure.
9
IF YOU NEED CONSUMER ASSISTANCE 889

Flashers
Turn Signal.....................121, 183, 329
Flat Tire Stowage......................743, 764
Flexible Fuel Vehicles
Cruising Range.........................682
Engine Oil............................681
Fuel Requirements...................680, 681
Maintenance...........................683
Replacement Parts.......................682
Starting..............................682
Flooded Engine Starting....................480
Fluid, Brake.............................867
Fluid Capacities..........................861
Fluid Leaks.............................121
Fluid Level Checks
Brake................................823
Power Steering.........................615
Fluids, Lubricants And Genuine Parts...........863
Fog Lights........................178, 320, 853Fold Flat Load Floor.......................251
Four-Way Hazard Flasher...................725
Four Wheel Drive.........................522
Freeing A Stuck Vehicle.....................775
Front Axle (Differential).....................825
Fuel...................................674
Adding..............................683
Additives.............................678
Clean Air.............................676
Ethanol...........................676, 680
Filler Cap (Gas Cap).....................685
Gasoline..............................674
Light................................317
Materials Added........................678
Methanol.............................676
Octane Rating......................674, 863
Requirements......................
.674, 861
Tank Capacity..........................861
Fuel, Flexible............................680
898 INDEX

Hitches
Trailer Towing.........................696
Hoisting................................769
HomeLink (Garage Door Opener)..............219
Hood Release............................170
Hub Caps...............................768
Ignition.................................16
Key ...............................12, 16
Ignition Key Removal.......................16
Illuminated Entry..........................24
Immobilizer (Sentry Key)....................19
Inflation Pressure Tires.....................659
Information Center, Vehicle...............334, 355
Inside Rearview Mirror..............130, 131, 138
Instrument Cluster..................291, 303, 329
Instrument Panel And Controls...............290
Instrument Panel Lens Cleaning...............836
Integrated Trailer Brake Controls..............702Interior Appearance Care....................834
Interior Lights...........................179
Intermittent Wipers (Delay Wipers).............185
Introduction..............................4
Inverter Outlet (115V)......................237
Jack Location.........................729, 749
Jump Starting............................770
Key Fob
Programming Additional Key Fobs...........21
Programming Additional Transmitters.........21
Key-In Reminder..........................18
Keyless Enter-N-Go.....................43, 478
Lock The Vehicle’s Doors..............388, 408
Passive Entry...........................43
Passive Entry Programming..........43, 388, 408
Keyless Entry System.......................25
Key, Replacement..........................20
900 INDEX

Dual.............................663, 726
General Information..................647, 653
High Speed...........................650
Inflation Pressures.......................648
Life Of Tires...........................657
Load Capacity......................642, 643
Pressure Monitor System (TPMS)............665
Pressure Warning Light...................314
Quality Grading........................887
Radial...............................650
Replacement...........................657
Rotation..............................662
Safety............................636, 647
Sizes................................637
Snow Tires............................652
Spare Tire.........................653, 655
Spinning.............................656
Tread Wear Indicators....................656
Tire Safety Information.....................636Tongue Weight/Trailer Weight................697
Tonneau Cover...........................837
Tonneau Cover Cleaning....................837
Torque Converter Clutch.................510, 521
Tow Hooks, Emergency.....................776
Towing.............................688, 781
Disabled Vehicle........................781
Guide...............................697
Recreational...........................714
Weight...............................697
Towing Vehicle Behind A Motorhome...........714
Traction................................588
Traction Control..........................625
Trailer Sway Control (TSC)..................632
Trailer Towing..........................
.688
Cooling System Tips.....................709
Hitches..............................696
Minimum Requirements..................698
Mirrors..............................144
10
INDEX 909
