2016 PORSCHE 718 engine

| 69
Safety and environment
Fuel.
All Porsche models – including the
718 models – are designed to operate on
fuels with an ethanol content of up to
10 %, e.g. ‘E10’. Ethanol has a positive
impact on the CO
2 balance because it is
derived from plants that absorb CO
2 from
the atmosphere.
Fuel economy and recycling.
Intelligent lightweight construction is
integral to the Porsche identit y. This

identity is expressed in the form of a high
proportion of aluminium, magnesium,
plastics and super-high-strength sheet

steels. All materials have been strategically
selected, and the paints used are
predominantly environmentally friendly
water-based paints. Each light weight

material is easily recyclable and all plastic
components are labelled to facilitate
future separation for recycling. In all, the
new 718 Boxster and the new 718 Cayman
are around 95 % recoverable.
comparison with the previous models,

fuel consumption and emissions have
been reduced by approximately 14 %. And
that’s despite a hefty increase in power.
Of course, the efficient use of fuel by means
of efficiency-enhancing technologies such
as auto start/stop, thermal management,
electrical system recuperation, VarioCam
Plus and, in conjunction with Porsche
Doppelkupplung (PDK), coasting mode,

has also played a part. Cataly tic converters
with stereo Lambda control circuits provide
efficient emission control.
In an era of intensifying debate about
global climate change and CO
2 emissions,
every automotive manufacturer is asking
what it has to offer right now. Our answer?
Excellent performance together with
excellent efficiency.
Emission control.
The new 718 models demonstrate
that even high-performance sports cars
can achieve moderate fuel consumption
and exhaust emission values in their
respective category. This is where the
new turbocharged engines have made
a not inconsiderable contribution. By
A sporting essential:
fair play.
Environment.
For fuel consumption, CO2 emissions and efficiency class, please refer to page 141.

2
1
74 |
Comfort
1 Sports steering wheel
2 Multifunction GT sports steering wheel and mode
switch (Sport Chrono Package)
Porsche Entry & Drive.
With the optional Porsche Entry & Drive,
you can leave your car key in your pocket.
As soon as you grab the door handle, or
your hand nears the Porsche Crest on the
front luggage compartment lid or the logos
on the rear, the system automatically
checks the encrypted access code on the
key. Once the key is validated, the door or
the luggage compartment lid unlocks. The
engine can then be started and switched
off using the electronic ignition switch.
Climate control.
An optional alternative to the air
conditioning
system, two-zone automatic
climate control has separate temperature
controls for the driver and front passenger
and offers a choice of three climate
setting profiles.
Light design package.
The optional light design package is both
practical and aesthetically appealing. It
comprises dimmable LEDs in various
parts of the interior.
GT sports steering wheel.
The new, optional GT sports steering
wheel has a smaller diameter. The spokes
are finished in black, while the spoke
trims are in Galvano Silver and are screw-
fastened. For a motorsport-derived look?
Definitely. Above all, though, to emulate a
motorsport driving feel.
Heating and multifunction controls are
optionally available for all steering wheels.
These give you fingertip access to the
4.6-inch colour display and therefore the
on-board computer as well as many audio,
telephone and navigation functions.
Sports steering wheel.
The sports steering wheel with three-
spoke design is lightweight and functional.
The small centre pad and the chrome ring
encircling the Porsche Crest – both
derived from the steering wheel of the
918 Spyder – reinforce its sport y
character.
In conjunction with PDK, the sports
steering wheel features two alloyed
gearshift paddles offering particularly
short shift throws.

78 |
Comfort
Example loading configuration with luggage items from
Porsche Driver’s Selection
under the armrest – when combined with
the optional Connect or Connect Plus
module and the included reception-
optimising smartphone storage tray –
becomes the ideal interface between
your smartphone and your 718 model.
Further convenience is provided, for
example, in the form of t wo compartments
in the doors, clothes hooks on the seat
backrests and two practical cupholders
above the glove compartment.
space for 130 litres – hood up or hood
down. The new 718 Cayman boasts a

rear luggage compartment capacity of
275 litres. Thanks to the shelf above the
engine cover, there is even enough room
to accommodate the longer items of your
belongings.
In the interior, too, clever storage solutions
offer plenty of space. The compartment
A lot can be expected of a genuine

sports car. The mid- engine concept of
the 718 models impresses not only by
delivering superbly agile driving dynamics,
but also by affording two luggage
compartments.
On both models, the front luggage
compartment holds 150 litres. At the
rear of the new 718 Boxster, there is
Just how much sport can you pack into a sports car?
Try it out.
Luggage compartments and storage solutions.

116 |
|
117
Personalisation Personalisation
Mode switch (Spor t Chrono Package)
Porsche Ceramic Composite Brake (PCCB)ExclusiveSpor ts tailpipes in black
ExclusiveSports tailpipes in silver colour
1)
Provisionally available from 07/2016.
–
not available I number/extra - cost option• standard■ available at no extra cost
For more information on the options featured in this catalogue, please refer to the separate price list.
Option718  B oxs ter
718 Boxster S
718  Cay man
718 Cayman SI no. Page
Chassis.
Porsche Active Suspension Management (PASM, 10 mm lower)••••47550
PASM spor ts suspension (20 mm lower) –
•–•030
58
Porsche Ceramic Composite Brake (PCCB)
••••450 6 3 , 117
Power steering Plus
••••658 54
Performance.
Sport Chrono Package including mode switch••••QR4/QR556, 58,
117
Option718  B oxs ter
718 Boxster S
718  Cay man
718 Cayman SI no.Page
Engine.
Sports exhaust system including sports tailpipes1)
Exclusive

– silver colour

– black•
•
•
•
•
•
•
•
XLF
XLX 43
4 3 , 114
Sports tailpipes
1)
Exclusive

– silver colour

– black•
•
•
•
•
•
•
•
XLS
XLW 116
116
Tank capacit y 64 litres
• •••085
Transmission.
Porsche Doppelkupplung (PDK, 7-speed)••••250
45
Porsche Torque Vectoring (PTV) including mechanically
locking rear differential
••••220 47

4 16
5 3
2
134 |
Personalisation · Porsche Tequipment
[1] Care kits
Interior and exterior care products
optimally selected and formulated for
your Porsche.
[2] Child seats
Distinctively designed, and specially
tested and approved for Porsche cars.
[3] All-weather floor mats
In an appealing design featuring the
silhouet te of your 718 model and the
‘PORSCHE’ logo.
[4] Cargo liners
Made-to -measure protective liners in
black plastic. Waterproof and easy to
clean.
[5] Winter wheel and tyre sets
For enhanced individuality, agility and
safet y. And even greater driving pleasure.
[6] Car cover
Tailored indoor or outdoor cover with
Porsche Crest.
With the Porsche Tequipment range of
accessories developed specifically for the
718 models, you can st yle your 718
entirely to your own preference. From the
start, the same rules that apply to our
vehicles also apply to the products of
Porsche Tequipment: developed, tested
and proven at the Development Centre in
Weissach. By the same Porsche engineers
and designers who made your car.
Designed with the complete vehicle in
mind and precisely tailored to your
Porsche.
And your original car warranty? It will
remain completely intact, whichever
Tequipment products you ask your
Porsche Centre to fit.
To discover more about Porsche
Tequipment, please consult your Porsche
Centre. Alternatively, all Tequipment
products can be found online at

www.porsche.com/tequipment using our
‘Tequipment accessories finder’.
Porsche Tequipment –
accessories developed for 365 days full of life.

140 |
|
141
Technical data Technical data
718  B oxs ter718 Boxster S718  Cay man718 Cayman S
Weights
Manual/PDK Manual/PDKManual/PDKManual/PDK
Unladen weight (DIN) 1,335 kg/1,365 kg1,355 kg/1,385 kg1,335 kg/1,365 kg1,355 kg/1,385 kg
Unladen weight (EC)
1)1,410 kg/1,440 kg 1,430 kg/1,460 kg1,410 kg/1,440 kg1,430 kg/1,460 kg
Permissible gross weight 1,655 kg/1,685 kg1,665 kg/1,695 kg1,655 kg/1,685 kg1,665 kg/1,695 kg
PerformanceManual/PDKManual/PDKManual/PDKManual/PDK
Top speed 275 km/h285 km/h275 km/h285 km/h
0 –10 0  k m / h 5.1 s/4.9 s4.6 s/4.4 s5.1 s/4.9 s4.6 s/4.4 s
Sport Chrono Package (in conjunction with PDK)
1) 0–100 km/h with Launch Control –/4.7 s –/4.2 s–/4.7 s–/4.2 s
0 –16 0   k m / h 11.3 s/11.1 s9.7 s/9.5 s11.3 s/11.1 s9.7 s/9.5 s
Sport Chrono Package (in conjunction with PDK)
1) 0 –160 km/ h with Launch Control –/10.8 s –/9.2 s–/10.8 s–/9.2 s
Flexibility (80–120 km/h), 5th gear 5.6 s/–5.0 s/–5.6 s/–5.0 s/–
Overtaking acceleration (80–120 km/h) –/3.2 s–/2.8 s–/3.2 s–/2.8 s
Fuel consumption/emissions2)Manual/PDKManual/PDKManual/PDKManual/PDK
Urban in l/100 km 9.9/9.010.7/9.59.9/9.010.7/9.5
Extra urban in l/100 km 6.0/5.76.5/6.06.0/5.76.5/6.0
Combined in l/100 km 7.4/6.98.1/7.37.4/6.98.1/7.3
CO
2 emissions in g/km 168/158184/167168/158184/167
Efficiency class3)Manual/PDKManual/PDKManual/PDKManual/PDK
Ef ficiency class (Germany) E/DF/EE/DF/E
Efficiency class (Switzerland) G/FG/FG/FG/F
Dimensions/aerodynamics
Length 4,379 mm4,379 mm4,379 mm4,379 mm
Width (including exterior mirrors) 1,801 mm (1,994 mm)1,801 mm (1,994 mm)1,801 mm (1,994 mm)1,801 mm (1,994 mm)
Height 1,281 mm1,280 mm1,295 mm1,295 mm
Wheelbase 2,475 mm2,475 mm2,475 mm2,475 mm
Luggage compartment volume (front/rear) (German Car Manufacturers’ Assoc.) 150 l/125 l150 l/125 l150 l/275 l150 l/275 l
Tank capacity (refill volume) ca. 54 lca. 64 lca. 54 lca. 64 l
Drag coefficient 0.310.320.300.31
718  B oxs ter/ 718  Cay man 718 Boxster S/718 Cayman S
Engine
Cylinders 4 4
Displacement 1,988 cm
32,497 cm3
Max. power (DIN)
at rpm220 kW (300 hp)

6,500  257 kW (350 hp)

6,500
Max. torque
at rpm 380 Nm

1,950–4,500  420 Nm

1,900–4,500
Compression ratio 9,5 : 1 9,5 : 1
Transmission
LayoutRear-wheel drive Rear-wheel drive
Manual transmission 6-speed 6-speed
Porsche Doppelkupplung (PDK), optional 7-speed 7-speed
Chassis
Front axleLightweight spring-strut suspension Lightweight spring-strut suspension
Rear axle Lightweight spring-strut suspension Lightweight spring-strut suspension
Steering Variable steering ratio, power-assisted (electromechanical) Variable steering ratio, power-assisted (electromechanical)
Turning circle 11. 0   m 11. 0   m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and cross-drilled Four-piston aluminium monobloc fixed calipers front and rear,

discs internally vented and cross-drilled
Vehicle stability system Porsche Stability Management (PSM) Porsche Stability Management (PSM)
Standard wheels Front: 8 J x 18 ET 57,
Rear: 9.5 J x 18 ET 49 Front: 8 J x 19 ET 57,

Rear: 10 J x 19 ET 49
Standard tyres Front: 235/45 ZR 18,
Rear: 265/45 ZR 18 Front: 235/40 ZR 19,

Rear: 265/40 ZR 19
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 75 kg for the driver.2) Data determined in accordance with the measurement method required by law (Regulation EC 715/2007 as amended). The figures do not refer to an individual vehicle nor do they constitute par t of the of fer. They are intended solely as
a means of comparing dif ferent t ypes of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and per formance may var y with items of optional equipment. A vehicle’s fuel consumption
and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to operate on fuels with an ethanol content of up to
10 %. You can obtain fur ther information about individual vehicles from your Porsche Centre.
3) Valid in the countries listed only.
Technical data.

| 147
Summary
We’ll let the 718 legend be just that for
now. And we’ll turn our attention instead
to what awaits us in the great outdoors.
To all the cities of this world, and to all
the world beyond those cities. To the
more than 35 million kilometres of road,
with their countless twists and turns. And
to being right in the centre of it all. In a
mid-engined sports car that conveys with
every fibre exactly what it is: insatiable.
The legend lives on. In the new
718 Boxster and 718 Cayman.
For the sport of it.
Life is now open 24 hours.
Sum mar y.

148 |
|
149
Index Index
T
Technical data 140
Telephone module 86
Transmission 45
Turbocharger 41
T V tuner 133
Tyre identification 142
Tyre Pressure Monitoring (TPM) 52
U
Universal audio interface 82
V
Variable turbine geometry 41
W
W h e e l s 118
Wind deflector 24, 120
Wireless Internet access 86
S
Safet y 60
Standard specification 24
Steering 54
Steering wheels Sports steering wheel 74
GT sports steering wheel 74
Steering wheel heating 74
Seats Adaptive Sports seats Plus 76
Child seat preparation 76
Sports bucket seats 76
Sports seats 76
Sports seats Plus 76
Fully electric Sports seats 76
Seat heating and ventilation 76
Sound Package Plus 88
Speed limit indicator 80
Sport Chrono Package 56
SPORT Response but ton 58
SPORT but ton 56
Sports exhaust system 43
Sports tailpipes 43, 116
Storage solutions 78
Porsche Entry & Drive 74
Porsche Exclusive 95
Porsche Side Impact Protection
System (POSIP) 65
Porsche Stabilit y Management (PSM) 50
Porsche Tequipment 104
Porsche Torque Vectoring (PT V) 47
Porsche Vehicle Tracking System
(PV TS) 84
Porsche Vehicle Tracking System Plus
(PV TS Plus) 123
PSM Sport 58
Power steering Plus 54
Electromechanical 54
R
Recycling 69
Real-time traffic information 84
Rear differential lock, mechanical 47
Reversing camera 80
Roll- over bars 65, 120
Roll- over protection 65
O
Online navigation 84
P
Panorama 138
ParkAssist 80
PASM sports suspension 58
Personalisation 93
Porsche Active Safe (PAS) 80
Porsche Active Suspension
Management (PASM) 50
Porsche Car Configurator 136
Porsche Car Connect (PCC) 84
Porsche Ceramic Composite
Brake (PCCB) 63
Porsche Communication
Management (PCM) 82
Porsche Connect app 86
Porsche Doppelkupplung (PDK) 45
Porsche Dynamic Light System
(PDLS) 67
Porsche Dynamic Light System Plus
(PDLS Plus) 67
I
Interior 34, 72, 102, 124–131
Interior packages 103, 109
Interior surveillance 123
iPod
® interface 82
ISOFIX child seat preparation 76
L
Lane Change Assist 80
LED main headlights 67
Leather and Sport-Tex interior 72, 110
Lights 67
Light design package 74
Light weight construction 17
Luggage compartments 78
M
Manual transmission 45
Mid-engine 15
Mobile phone preparation 82
Models 19, 23
N
Navigation module 82, 132
Net-t ype wind deflector 24, 120
Environment 69
Exhaust turbocharging 41
Exterior 28, 100, 120
Exterior mirrors 28, 122
F
Factory collection 137
Fuel 69
Fuel consumption 141
H
Highlights 20
Headlights Bi-Xenon main headlights including
Porsche Dynamic Light System
(PDLS) 67
LED main headlights including
Porsche Dynamic Light System Plus
(PDLS Plus) 67
HomeLink
® (programmable garage
door opener) 123
Hood 30, 78, 100
Connect module 84, 132
Connect Plus module 84, 132
Colours Exterior 100
Interior 102-106
Cruise control 123
D
Design 28
Digital radio 133
Direct fuel injection (DFI) 39
Direct steering 54
Drive 36
Dynamic transmission mounts 58
E
Efficiency-enhancing technology 43
Electronic logbook 133
Emissions 69, 141
Emission control 69
Engines 2.0-litre turbocharged
boxer engine 39
2.5-litre turbocharged
boxer engine 39
A
Adaptive cruise control including PAS 80
Airbags 65
Air conditioning system 74
Alarm system 123
Apple
® CarPlay 84
Assistance systems 80
Automatic climate control, two-zone 74
Auto start /stop function 43
B
Bi-Xenon headlights 67
Bi-Xenon main headlights 67
BOSE
® Surround Sound System 88
Boxer engines 23, 39
Brakes 63
Burmester
® High-End Surround
Sound System 88
C
Chassis 50
Child seats 76, 134
Coasting 43
Colour combinations 108
Comfor t 70
Index.
