3-12Pre-driving checks and adjustments
The power sliding door system can be operated
when all of following conditions are satisfied.
.The vehicle is stopped.
. Battery voltage is normal.
. The sliding door is unlocked.
. The fuel-filler door is closed (for driver's side
only) .
When the ignition switch is in the "ON" position,
the system can be operated in the above and
following conditions.
. Shift lever is set in the ªPº (Park) position.
If the conditions are interrupted when the power
sliding door is being operated, the operation
could be stopped. In this case, meet the
conditions above and the power sliding door
operation will return to normal.
You can also switch the power lift gate between
power and manual operation using the power
door main switch. (See ªLift gateº (P.3-26) .)
SPA2846
Instrument panel
*ADriver's side sliding door switch
*BPassenger's side sliding door switch
OPERATING SLIDING DOOR SWITCHGUID-EE7E773F-5BC9-4FC4-BFE3-DDC092853705To operate the sliding doors with the sliding
door switches, turn on the power door main
switch.
. When the sliding door is fully closed, push
and hold the sliding door switch on the
instrument panel for about 1 second. The
sliding door will automatically open to the
fully opened position.
. When the sliding door is fully opened, push
and hold the sliding door switch on the
instrument panel for about 1 second. The sliding door will automatically close to the
fully closed position.
. If the sliding door switch is pushed while the
sliding door is being operated automatically,
the door will start moving in the reverse
direction and stop at the fully opened or
closed position.
. The sliding doors can be opened by the
instrument panel switch
*Aor*Beven if
the sliding door is locked or the power door
main switch is in the OFF position.
OPERATING THE POWER SLIDING
DOOR WITH THE INTELLIGENT KEY (if
so equipped)
GUID-89E54C18-A308-4127-853C-8487439FBBACThe sliding doors can also be opened and
closed by pushing the button on the Intelligent
Key. (See ªIntelligent Key systemº (P.3-13).)
Sliding door one-touch unlock/open
function (if so equipped)
GUID-0F5030A9-0AB2-4D70-A34F-9846AF95FC6FThe sliding doors can be unlocked and opened
with a one-touch unlock/open operation. When
closed, the sliding door will not lock automati-
cally. To lock the sliding doors, manually lock the
inside knob before closing the sliding door or
push the LOCK button on the Intelligent Key
after the door is closed. See ªRemote keyless
entry systemº (P.3-21) .
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
OPERATING SLIDING DOOR BY
POWER ASSIST
GUID-FD94DF64-8ED4-43CE-8353-FF9CDB47F70CTo operate, pull the inside or outside door
handle until you hear the buzzer, the door will
automatically open or close.
If the door handle is operated while the sliding
door is moving, the door will reverse directions
and stop at either the full open or closed
position.
SLIDING DOOR AUTO REVERSE
FUNCTION
GUID-3187603A-46AE-40CE-97BD-3601230ED6EBIf an obstacle is detected while the power
sliding door is being operated, the door will
reverse directions and return to the full open or
full closed position.
If you touch the sensor of the sliding door while
the sliding door is closing automatically, the door
will start moving in the reverse direction and
stop at the fully opened position.
GUID-7C39F98D-38C6-4523-BF51-8634B2D72D58
WARNING
.Radio waves could adversely affect
electric medical equipment. Those
who use a pacemaker should con-
tact the electric medical equipment
manufacturer for the possible influ-
ences before use.
. The Intelligent Key transmits radio
waves when the buttons are
pushed. The FAA advises that radio
waves may affect aircraft navigation
and communication systems. Do not
operate the Intelligent Key while on
an airplane. Make sure the buttons
are not operated unintentionally
when the unit is stored for a flight.
The Intelligent Key system can operate all the
door locks (including the lift gate) using the
remote keyless function or pushing the request
switch on the vehicle without taking the key out
from a pocket or purse. The operating environ-
ment and/or conditions may affect the Intelligent
Key system operation.
Be sure to read the following before using the
Intelligent Key system.
CAUTION
. Be sure to carry the Intelligent Key
with you when operating the vehi-
cle.
. Never leave the Intelligent Key in
the vehicle when you leave the
vehicle.
The Intelligent Key is always communicating with
the vehicle as it receives radio waves. The
Intelligent Key system transmits weak radio
signals. Environmental conditions may interfere
with the operation of the Intelligent Key system
under the following operating conditions.
. When operating near a location where
strong radio signals are transmitted, such
as a TV tower, power station and broad-
casting station.
. When in possession of wireless equipment,
such as a cellular telephone, transceiver,
and CB radio.
. When the Intelligent Key is in contact with or
covered by metallic materials.
. When any type of radio wave remote control
is used nearby.
. When the Intelligent Key is placed near an
electric appliance such as a personal
Pre-driving checks and adjustments3-13
INTELLIGENT KEY SYSTEM
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
.When changing batteries, do not let dustor oil get on the remote control and
headphones.
FCC Notice:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
Note: Changes or modifications not ex-
pressly approved by the party responsible
for compliance could void the user's
authority to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
BEFORE OPERATING THE DVD MO-
BILE ENTERTAINMENT SYSTEM
GUID-388A77D2-69A0-4B20-A0E4-DDCE2B1067DC
PrecautionsGUID-5D3D657D-6968-44A5-A144-3182D0634837Start the engine when using the DVD entertain-
ment system.
WARNING
The driver must not attempt to operate
the DVD system or wear the head-
phones while the vehicle is in motion
so that full attention may be given to
vehicle operation.
CAUTION
. Only operate the DVD while the
vehicle engine is running. Operating
the DVD for extended periods of
time with the engine OFF can dis-
charge the vehicle battery.
. Do not allow the system to get wet.
Excessive moisture such as spilled
liquids may cause the system to
malfunction. .
While playing VIDEO-CD media, this
DVD player does not guarantee
complete functionality of all VI-
DEO-CD formats.
Parental level (parental control)GUID-A58211E7-DD2A-4035-81DA-19A2C8A67243DVDs with the parental control setting can be
played with this system. Please use your own
judgement to set the parental control with the
system.
Disc selectionGUID-1F9B68E6-F4DF-443B-BE00-D8AD25A6E450The following disc formats can be played with
the DVD drive.
.DVD-VIDEO
. VIDEO-CD
. DTS-CD (models with navigation system)
Use DVDs with the region code ªALLº or the
code applicable to your country. (The region
code is displayed as a small symbol printed on
the top of the DVD.) This vehicle-installed DVD
player can only play DVDs with an applicable
region code.
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-115
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
return to the previous display.
DVD operation keysGUID-B86DB395-DEC5-4D6C-A71D-E9C3F49F2777To operate the DVD drive, select the desired key
displayed on the operation screen using the
multi-function controller.
PAUSE:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Select the ªº key to pause the DVD. To
resume playing the DVD, use the ªPLAYº key.
To pause the DVD, it is also possible to push the
ª
º button on the keypad of the remote
controller.
PLAY:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Select the ªº key to start playing the DVD,
for example, after pausing the DVD.
To start playing the DVD, it is also possible to
push the ª
º button on the keypad of the
remote controller.
STOP:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Select the ªº key to stop playing the DVD.
To stop playing the DVD, it is also possible to
push the ª
º button on the keypad of the
remote controller.
SKIP (FORWARD):GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Select the ªº key to skip the chapter(s) of
the disc forward. The chapters will advance the
number of times the ENTER button is pushed.
To skip the chapter(s) forward, it is also possible
to push the ª
º button on the keypad of the
remote controller.
SKIP (REWIND):GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Select the ªº key to skip the chapter(s) of
the disc backward. The chapters will go back
the number of times the ENTER button is
pushed.
To skip the chapter(s) backward, it is also
possible to push the ª
º button on the
keypad of the remote controller.
/Commercial Skip (if so
equipped):
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407This function is only for DVD-VIDEO and DVD-
VR.
Select the ª
º or ªº key to skip forward or
backwards by the set amount as defined in the
DVD settings menu.
To skip forward or backward, it is also possible
to push the ª
º or ªº button on the
keypad of the remote controller.
SAA2498
Front screen (models with navigation system)
SAA3656
Rear screen (models with navigation system)
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-117
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
5-34Starting and driving
ing lightmay illuminate.
. The VDC system is not a substitute
for winter tires or tire chains on a
snow covered road.
GUID-348F0E28-6B84-46C8-BB6D-AFE840F7A7C6FREEING A FROZEN DOOR LOCKGUID-BF844EE8-8879-4D9E-A0D8-6BDA69A4766DTo prevent a door lock from freezing, apply
deicer through the key hole. If the lock becomes
frozen, heat the key before inserting it into the
key hole or use the remote keyless entry key fob.
ANTI-FREEZEGUID-382CA52B-F6BA-4172-888D-0B88818F7A48In the winter when it is anticipated that the
outside temperature will drop below 328F (08C) ,
check the anti-freeze to assure proper winter
protection. For additional information, see ªEn-
gine cooling systemº (P.8-7) .
BATTERYGUID-7E1806A3-BEC0-4F76-AA10-15C013CA97DDIf the battery is not fully charged during
extremely cold weather conditions, the battery
fluid may freeze and damage the battery. To
maintain maximum efficiency, the battery should
be checked regularly. For additional information,
see ªBatteryº (P.8-13) .
DRAINING OF COOLANT WATERGUID-65229154-25AF-41A0-8FA9-2ECBCB7CFCDDIf the vehicle is to be left outside without anti-
freeze, drain the cooling system, including the
engine block. Refill before operating the vehicle.
For details, see ªEngine cooling systemº (P.8-7) .
TIRE EQUIPMENTGUID-CFE2B762-0CDA-4F82-B772-E8834079FBB4SUMMER tires have a tread designed to provide
superior performance on dry pavement. How-
ever, the performance of these tires will be
substantially reduced in snowy and icy condi-
tions. If you operate your vehicle on snowy or icy
roads, NISSAN recommends the use of MUD &
SNOW or ALL SEASON tires on all four wheels.
It is recommended you consult a NISSAN dealer
for the tire type, size, speed rating and
availability information.
For additional traction on icy roads, studded
tires may be used. However, some U.S. states
and Canadian provinces prohibit their use.
Check local, state and provincial laws before
installing studded tires.
Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow
tires.
Tire chains may be used. For details, see ªTire
chainsº (P.8-36) .
SPECIAL WINTER EQUIPMENTGUID-70D53D25-FE2C-49C0-A2CB-99E59866FD06It is recommended that the following items be
carried in the vehicle during winter:
.A scraper and stiff-bristled brush to remove
ice and snow from the windows and wiper
blades.
COLD WEATHER DRIVING
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
R
Radio...
............................................................................. 4-61
Car phone or CB radio ...
.................................... 4-121
FM-AM-SAT radio with Compact Disc
(CD) player ...
................................................. 4-77, 4-87
Rapid air pressure loss ...
............................................... 5-7
Readiness for inspection/maintenance
(I/M) test ...
....................................................................... 9-26
Rear personal lights ...
................................................... 2-57
Rear window and outside mirror
defroster switch ...
.......................................................... 2-33
Rear window wiper and washer switch ...
............... 2-32
RearView Monitor ...
....................................................... 4-25
Recorders, Event data ...
............................................... 9-27
Registering in another country ...
.................................. 9-8
Remote controller (DVD) ...
....................................... 4-119
Remote keyless entry system ...
.................................. 3-21
Reporting safety defects (US only) ...
....................... 9-25
Roadside assistance program ...
................................... 6-2
Rollover ...
........................................................................... 5-6
Roof, Roof rack ...
........................................................... 2-50
S
Safety
Child seat belts ...
.................................................... 1-24
Reporting safety defects (US only) ...
................ 9-25
Towing safety ...
........................................................ 9-20
Satellite radio operation ...
............................................ 4-87
Seat adjustment Front manual seat adjustment ...
............................. 1-3
Front power seat adjustment ...
.............................. 1-4
Front seats ...
............................................................... 1-3
Seat belt(s) Child safety ...
........................................................... 1-24
Infants ...
..................................................................... 1-25 Injured persons
...
.................................................... 1-17
Larger children ...
..................................................... 1-26
Precautions on seat belt usage ...
....................... 1-15
Pregnant women ...
.................................................. 1-17
Seat belt cleaning ...
.................................................. 7-6
Seat belt extenders ...
............................................. 1-23
Seat belt hooks ...
.................................................... 1-23
Seat belt maintenance ...
....................................... 1-24
Seat belt warning light and chime ...
.................. 2-15
Seat belts ...
.............................................................. 1-15
Seat belts with pretensioners ...
.......................... 1-63
Shoulder belt height adjustment ...
..................... 1-23
Small children ...
....................................................... 1-25
Three-point type ...
.................................................. 1-17
Seat(s) Driver-side memory ...
............................................. 3-36
Heated seats ...
........................................................ 2-39
Seats ...
.......................................................................... 1-2
Security system (NISSAN Vehicle Immobilizer
System) , Engine start ...
................................................ 2-30
Security system, Vehicle security system ...
............. 2-28
Servicing air conditioner ...
........................................... 4-60
SETTING button ...
......................................................... 4-15
Shift lever Shift lock release ...
................................................. 5-16
Shift lock release, Transmission ...
............................. 5-16
Shifting, CVT (Continuously
Variable Transmission) ...
.............................................. 5-13
Shoulder belt height adjustment ...
............................ 1-23
Sliding doors ...
................................................................. 3-7
SOURCE select switch ...
......................................... 4-109
Spare tire ...
............................................................. 8-41, 9-7
Spark plugs ...
.................................................................. 8-16
Speedometer ...
................................................................. 2-6
Starting Before starting the engine ...
................................ 5-11
Jump starting ...
........................................................ 6-10 Precautions when starting and driving
...
............. 5-2
Push starting ...
......................................................... 6-12
Starting the engine ...
............................................. 5-12
STATUS button ...
........................................................... 4-10
Status light, Front passenger air bag ...
.................... 1-56
Steering Power steering fluid ...
............................................ 8-11
Steering-wheel-mounted controls
for audio ...
............................................................... 4-108
Tilt/telescopic steering ...
....................................... 3-32
Storage ...
......................................................................... 2-44
Sun visors ...
..................................................................... 3-33
Sunglasses holder ...
...................................................... 2-46
Supplemental air bag warning labels ...
.................... 1-64
Supplemental air bag warning light ...
........... 1-65, 2-15
Supplemental restraint system ...
................................ 1-49
Precautions on supplemental
restraint system ...
.................................................... 1-49
Switch Autolight switch ...
................................................... 2-34
Fog light switch ...
................................................... 2-39
Hazard warning flasher switch ...
............................ 6-2
Headlight aiming control ...
.................................... 2-37
Headlight switch ...
.................................................. 2-34
Overdrive OFF switch ...
........................................ 5-15
Power door lock switch ...
........................................ 3-6
Rear window and outside mirror
defroster switch ...
................................................... 2-33
Turn signal switch ...
................................................ 2-38
Vehicle dynamic control (VDC) off switch ...
.... 2-41
T
Tachometer ...
..................................................................... 2-7
Temperature display ...
................................................... 2-26
Temperature gauge, Engine coolant
temperature gauge ...
....................................................... 2-7
10-5
&RQGLWLRQ
