2016 NISSAN QUEST display


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
4-106Monitor, heater, air conditioner, audio, phone and voice recognition systems
SAA2496
Models with navigation system
JVH0185M
Models without navigation system
AUX MenuGUID-274E05F6-29D4-4ECA-8B6B-8FE4D6B88B40When the ªMenuº key on the display is selected
while in the AUX mode, the menu screen will be
displayed.
Display Mode:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Choose the display mode from the following
items.
.Normal
. Wide
. Cinema
Volume Settings (models with navigation
system):
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Choose the volume setting from the following
items.
. Low
. Medium
. High
Display (models with navigation system):
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Adjust the image quality of the screen, select the
preferred adjustment items.
SAA0451
CD/DVD/USB MEMORY CARE AND
CLEANING
GUID-6D5C9300-F67A-4A8C-B1DF-ABB942A49266
CD/DVDGUID-FBF4F030-8080-496A-BC07-79B1E7F73057. Handle a CD/DVD by its edges. Never touch
the surface of the disc. Do not bend the
disc.
. Always place the discs in the storage case
when they are not being used.
. To clean a disc, wipe the surface from the
center to the outer edge using a clean, soft
cloth. Do not wipe the disc using a circular
motion.
Do not use a conventional record cleaner or
alcohol intended for industrial use.
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
4-108Monitor, heater, air conditioner, audio, phone and voice recognition systems
STEERING-WHEEL-MOUNTED CON-
TROLS FOR AUDIO (if so equipped)
GUID-318C205C-ABED-4E18-84B5-C08D0B94B8BA
Menu control switch (models with navi-
gation system) or audio tuning switch
(models without navigation system)
GUID-5335E3A1-1B20-4E7C-81BF-2F67FAB5C480While the display is showing a MAP (navigation
systems only) , STATUS or Audio screen, tilt the
switch upward or downward to select a station,
track, CD or folder. For most audio sources,
tilting the switch up/down for more than 1.5
seconds provides a different function than tilting
up/down for less than 1.5 seconds.
AM and FM radio:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407.Tilting up/down for less than 1.5 seconds
will skip up/down to the next or previous
preset station.
. Tilting up/down for more than 1.5 seconds
will seek up or down to the next station.
. Pushing the menu control switch will show
the list of preset stations.
SiriusXM Satellite Radio (if so equipped):
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407. Tilting up/down for less than 1.5 seconds
will skip up/down to the next or previous
preset channel.
. Tilting up/down for more than 1.5 seconds
will go to the next or previous category. .
Pushing the menu control switch will show
the XM Menu.
iPod


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
SOURCE select switchGUID-23036168-ECD2-4CAA-9199-E2D306B05463Push the source select switch to change the
mode to available audio source.
ANTENNAGUID-17BC2CA9-3EA8-43FE-A450-C0DB7EC8EE63
Window antennaGUID-B71C87D5-396E-40B9-8137-095E92B6323AThe antenna pattern is printed inside the rear
side window.
CAUTION
.Do not place metalized film near the
rear side window glass or attach any
metal parts to it. This may cause
poor reception or noise.
. When cleaning the inside of the rear
side window, be careful not to
scratch or damage the rear side
window antenna. Lightly wipe along
the antenna with a dampened soft
cloth.SAA3602
Satellite antenna (if so equipped)GUID-94401A92-8316-4E58-B736-412213530D97There is a satellite antenna on the rear part of the
vehicle roof.
GUID-0F736F66-7DA7-4286-91A9-EA463D1F96C6This vehicle is equipped with the mobile
entertainment system, which enables you to
play a Digital Versatile Disc (DVD) or USB,
providing the images and sounds both in the
front and rear display screens.
WARNING
.The driver must not attempt to
operate or view the Mobile Enter-
tainment System (MES) while the
vehicle is in motion so that full
attention may be given to vehicle
operation.
. Do not attempt to modify the system
to display a movie on the front
screen while the vehicle is being
driven. Doing so may distract the
driver and may cause a collision and
serious personal injury or death.
CAUTION
.The glass screen on the liquid
crystal display may break if hit with
a hard or sharp object. If the glass
breaks, do not touch the liquid
crystalline material.
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-109
NISSAN MOBILE ENTERTAINMENT
SYSTEM (MES) (if so equipped)
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
components. Do not use solvents or
cleaning solutions.
. Be sure to stow the rear display
when it is not used.
SAA3655
Flip-down screen
Use the remote controller to operate the
motorized flip-down rear display screen.
1. Push the REAR DISPLAY OPEN/CLOSE
button on the remote controller to open or
close the display.
2. Adjust the display angle by pushing the DISPLAY TILT button
or.
The screen can also be opened using the multi-
function controller. (See ªHow to use SETTING
buttonº (P.4-15).)
Do not block the range of the wireless remote
controller receiver and wireless headphones
transmitter
*1.
CAUTION
Do not touch the display when it is
opening or closing.
HeadphonesGUID-C8155863-6400-425E-9F4D-1405C4FE58D9
CAUTION
Do not leave headphones on the seats.
Sitting on headphones left on a seat
could damage the headphones and may
result in personal injury due to shards
from the headphones.
Headphones are a wireless type and no cables
are necessary. You can use them in almost all
the ranges in the rear seat for listening to the
sound from DVD, AUX or USB. (It is not possible
to use the headphones in the front seat.)
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-111
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
4-112Monitor, heater, air conditioner, audio, phone and voice recognition systems
SAA3608
Power ON/OFF:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Push the POWER button to turn the head-
phones on or off.
SAA3609
Volume control:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Turn the volume control knob to adjust the
volume.
The headphones will automatically be turned off
within approximately 5 minutes if there is no
infrared signal input during that period. To
prevent the battery from being discharged, keep
the power turned off when not in use.
If the sound from the headphones is not clear it
may be because:
.of an infrared communication device or
cellular phone, turn down the headphone
volume or stop using the headphones, or .
the headphones maybe out of the range of
the transmitter installed in the rear flip-down
display screen. This is not a malfunction, or
. the sound may be interrupted temporarily
when there is an obstacle between the
headphones and the transmitter. Remove
the obstacle, such as opaque materials,
hands, hair, etc.
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
SAA3610
Models with navigation system
SAA3704
Models without navigation system
Remote controllerGUID-2588A2CA-F93C-4D91-A8CA-5D040A0DDECAThe remote controller has the following controls:
.Models with navigation system
1) REAR DISPLAY OPEN/CLOSE button
2) DVD button
3) Joystick
4) AUX button
5) ENTER button
6) DISP button
7) SPEAKER VOLUME CONTROL button
(
or)
8) TRACK/CHANNEL button
(
or)
9) DISPLAY TILT button
(
or)
10) USB button (if so equipped)
11) BACK button
12) SOUND button
13) Keypad (Some models do not have a Commercial Skip button.)
. Models without navigation system
1) REAR DISPLAY OPEN/CLOSE button
2) DVD button
3) Joystick
4) AUX button
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-113
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
4-114Monitor, heater, air conditioner, audio, phone and voice recognition systems
5) ENTER button
6) DISP button
7) SPEAKER VOLUME CONTROL button
(
or)
8) TRACK/CHANNEL button
(
or)
9) DISPLAY TILT button
(
or)
10) BACK button
11) SOUND button
12) Keypad
See ªRemote controller operationº (P.4-119) for
the function of each buttons.
SAA0978
Remote controller
SAA3611
Headphones
Remote controller and headphones bat-
tery replacement
GUID-8A1D3DE9-0E1F-4753-9D1D-E5F067E6239FReplace the battery as follows:
1. Open the lid.
The lid is easy to open if a flat head
screwdriver etc., is used.
2. Replace both batteries with new ones.
.Size AA (remote control).Size AAA (headphones)
Make sure that the +and 7ends on
the batteries match the markings in-
side the compartment.
3. Close the lid securely.
If the battery is removed for any reason
other than replacement, close the lid
securely.
.If you will not be using the remote controlfor long periods of time, remove the
batteries.
.Replacement of the batteries is neededwhen the remote control only functions at
extremely close distances to the MES or
not at all.
.Be careful not to touch the batteryterminal.
.An improperly disposed battery can harm the environment. Always confirm local
regulations for battery disposal.
&RQGLWLRQ


> (GLW    0RGHO 0< 1,66$1 48(67(20((8 @
.When changing batteries, do not let dustor oil get on the remote control and
headphones.
FCC Notice:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
Note: Changes or modifications not ex-
pressly approved by the party responsible
for compliance could void the user's
authority to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
BEFORE OPERATING THE DVD MO-
BILE ENTERTAINMENT SYSTEM
GUID-388A77D2-69A0-4B20-A0E4-DDCE2B1067DC
PrecautionsGUID-5D3D657D-6968-44A5-A144-3182D0634837Start the engine when using the DVD entertain-
ment system.
WARNING
The driver must not attempt to operate
the DVD system or wear the head-
phones while the vehicle is in motion
so that full attention may be given to
vehicle operation.
CAUTION
. Only operate the DVD while the
vehicle engine is running. Operating
the DVD for extended periods of
time with the engine OFF can dis-
charge the vehicle battery.
. Do not allow the system to get wet.
Excessive moisture such as spilled
liquids may cause the system to
malfunction. .
While playing VIDEO-CD media, this
DVD player does not guarantee
complete functionality of all VI-
DEO-CD formats.
Parental level (parental control)GUID-A58211E7-DD2A-4035-81DA-19A2C8A67243DVDs with the parental control setting can be
played with this system. Please use your own
judgement to set the parental control with the
system.
Disc selectionGUID-1F9B68E6-F4DF-443B-BE00-D8AD25A6E450The following disc formats can be played with
the DVD drive.
.DVD-VIDEO
. VIDEO-CD
. DTS-CD (models with navigation system)
Use DVDs with the region code ªALLº or the
code applicable to your country. (The region
code is displayed as a small symbol printed on
the top of the DVD.) This vehicle-installed DVD
player can only play DVDs with an applicable
region code.
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-115
