2016 NISSAN LEAF change time

18
LANE CHANGE SIGNAL

Move the lever up or down until the turn signal begins to flash but th\
e lever does not
latch to signal a lane change. Hold the lever until the lane change is completed.

Move the lever up or down until the turn signal begins to flash but th\
e lever does not
latch and release the lever. The turn signal will automatically flash three times.
Choose the appropriate method to signal a lane change based on road and
traffic conditions.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
WIPER AND WASHER SWITCH
Move the lever to one of the following positions
to operate the windshield wipers:

1 Mist (MIST) – This is a one-sweep
operation of the front wipers.

2 Intermittent (INT) – Front wipers
operate intermittently by moving the lever
down to the INT position and then rotating
the control ring
3 to increase or decrease
INT wiper speed.

4 Low (LO) – Front wipers operate at a
continuous low-speed.

5 High (HI) – Front wipers operate at a
continuous high-speed.

6 Pull the lever toward you to activate the
front washer. The front wipers will operate several times.
DRIP WIPE

Once the wiper spray cycle is finished, there will be a short delay. Then the wipers will
sweep one more time to clear off any remaining drips from the windshield\
.
REAR WIPER AND WASHER SWITCH

7 Intermittent (INT) – Rear wiper
operates intermittently.

8 Low (ON) – Rear wiper operates at a
continuous low-speed.

9 Push the lever forward to activate the
rear washer. The rear wiper will operate
several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
31
2
4
5
MIST
OFF
INT
LO
HI
69
INT
ON7
8
FIRST DRIVE FEATURES
1996737_16a_Leaf_QRG_071015.indd 187/10/15 11:28 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

20
FM/AM/SiriusXM®* SATELLITE RADIO
WITH CD PLAYER (if so equipped)
Touch the Audio key on the Launch Bar to display the current audio source. Touch the
Audio key a second time to access the source selection screen.
1 (ON•OFF) BUTTON

Press the (on•off) button to turn the audio system on or off.
2 VOL(volume) CONTROL BUTTONS
Press the VOL (volume) / buttons to to increase or decrease the volume.
3 / (TUNE/SEEK/CH) BUTTONS

To scan quickly through each broadcasting station, press the button or the
button to move to the next or previous broadcast station.

To seek through stations, press and hold the button or the button.

For satellite radio to switch to the first channel of the next or previous category,
press the
button or the button.

To change tracks on a CD, press the button or the button.
2
1
3
8
6
7
4
12
Press the air recirculation button again to turn air recirculation off. This allows
outside air to be drawn into the passenger compartment to prevent foggin\
g in the
front defroster, floor vent or defroster/floor vent mode.

The air recirculation mode cannot be activated when the climate control s\
ystem is
in the front defroster mode
or the front defroster and foot vent mode .
10 REAR WINDOW AND OUTSIDE MIRROR (if so equipped)
DEFROSTER SWITCH

Push the rear window defroster switch to turn the system on or off.

The rear window defroster automatically turns off after approximately 15 minutes.
11 CLIMATE CONTROL TIMER INDICATOR

The climate control timer indicator light will illuminate when the timer \
has been set
to operate. The climate control timer may be set to a specific date and time.
For more information, refer to the “Display screen, heater, air conditioner, audio and phone systems (section 4)”
of your Owner’s Manual.
13
16
9
1514
1110
FIRST DRIVE FEATURES
1996737_16a_Leaf_QRG_071015.indd 207/10/15 11:28 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Nissan, the Nissan Brand Symbol, Z and
Nissan model names are Nissan trademarks.
© 2015 Nissan Nor th America, Inc.
QR
16E A 0ZE0U0Printing: July 2015 (10)
To view detailed instructional videos,
go to www.nissanownersinfo.mobi/2016/leaf
or snap this barcode with an appropriate barcode reader.
This Quick Reference Guide is intended to provide an overview of some of the uniq\
ue features of your new vehicle. Please see
your Owner’s Manual for important safety information and system operation limitations. Features and equipment in your vehicle
may vary depending on model, trim level, options selected, order, date of production, region or availability. Therefore, you may
find information about features or equipment that are not included or \
installed on your vehicle.
All information, specifications and illustrations in this Quick Reference Guide are those in effect at the time of printing. NISSAN
reserves the right to change specifications, performance, design or component suppliers witho\
ut notice and without obligation.
From time to time, NISSAN may update or revise this Quick Reference Guide to provide owners with the most accurate
information currently available. Please carefully read and retain, with this Quick Reference Guide, all revision updates sent to
you by NISSAN to ensure you have access to accurate and up-to-date information reg\
arding your vehicle. Current versions of
vehicle Quick Reference Guides, Owner’s Manuals and any updates can also be found in the Owner section of the \
NISSAN
website at https://owners.nissanusa.com/nowners/navigation/manualsGuide. If you have questions concerning any
information in your Owner’s Manual, contact NISSAN Consumer Affairs. See the NISSAN CUSTOMER CARE PROGRAM
page in the Owner’s Manual for contact information.

Helpful Resources
Below is a list of helpful resources that can be used to learn
more about the vehicle’s systems and feature operations.

Vehicle Owner’s Manual

Navigation System Owner’s Manual (if so equipped)

Printed Quick Reference Guide (this document)

www.NissanUSA.com/bluetooth

www.NissanUSA.com/connect

www.youtube.com/user/NissanUSA

Nissan Consumer Affairs: 1-800-647-7261

Electronic Quick Reference Guide
(Use Quick Response (QR) code or URL below.)

Nissan Quick Guide (available in the iPhone App
Store or Android Google Play Store for download to
your smartphone)
