2016 NISSAN JUKE window

14
HEATER AND AIR CONDITIONER (automatic)
(with Integrated Control System) (if so equipped)
1 CLIMATE BUTTON

Press the CLIMATE button to access the Climate Control Mode.

When in Climate Control Mode, the selected temperature, air flow and au\
tomatic
mode or manual mode are indicated on the display.
2 AUTO BUTTON/TEMPERATURE CONTROL DIAL

The automatic mode can be used year-round. Press the AUTO button to turn
the system on, and the fan speed, air flow distribution and temperatur\
e will be
automatically maintained.

Turn the temperature control dial left for cooler air or right for warmer\
air.
3 FAN SPEED CONTROL DIAL

Turn the fan speed control dial to the left to decrease fan speed or to the right to
increase fan speed.
4 AIR FLOW CONTROL BUTTONS

Press the preferred air flow control button to select one of the follo\
wing
air flow outlets:

Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the front defroster and foot vents.
5 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front defroster button to turn the system on. The A/C automatically
turns on when the front defroster mode is selected. This feature removes humidity
from the air.

Use the temperature control dial 2 to set the desired temperature.

To set the front defroster on high, turn the fan speed control dial 3 to increase the
fan speed to the maximum setting.
6 REAR WINDOW AND OUTSIDE MIRROR (if so equipped)
DEFROSTER SWITCH

Push the rear window and outside mirror defroster switch to turn the system
on or off.
32
1
8
9
756
4
FIRST DRIVE FEATURES
1905578_16a_Juke_US_pQRG_081915.indd 148/19/15 11:08 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

15
2
1
3
4
DRIVE MODE (with Integrated Control System) (if so equipped)
1 DRIVE MODE SELECT BUTTON

Press the D-MODE button 1 to switch the display to the Drive mode. While in
the Drive mode, set-up functions, drive information and ECO information can be
displayed and adjusted.

Your vehicle’s Integrated Control System allows vehicle performance to be adjusted
by selecting from three drive modes: NORMAL, SPORT or ECO.

NORMAL
2 drive mode is recommended for normal, everyday driving.

SPORT
3 drive mode is recommended for an enhanced performance feel. Fuel
economy may be reduced.

ECO
4 drive mode is recommended for maximum fuel economy. Performance
may be reduced.
For more information, refer to the “Instruments and controls (section 2)”, the “Heater, air conditioner, audio and
phone systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
The rear window and outside mirror defroster automatically turns off afte\
r
approximately 15 minutes.
7 AIR INTAKE BUTTON
Press the air intake button to change the air circulation from the air recirculation
mode to the outside air circulation mode.

When the air recirculation indicator light illuminates, the flowing air is
recirculated inside the vehicle. This system is used to avoid outside odors and to
help adjust the inside vehicle temperature more effectively.

The air recirculation mode cannot be activated when the climate control s\
ystem is
in the front defroster mode or the front defroster and foot outlet mode .

When the outside air circulation indicator light
illuminates, the flowing air is
drawn from outside the vehicle.
8 A/C BUTTON

Press the A/C button to manually turn the A/C on or off.
9 OFF BUTTON

Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)”, the “Heater, air conditioner, audio and
phone systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
1905578_16a_Juke_US_pQRG_081915.indd 158/19/15 11:08 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

20
BLUETOOTH® HANDS-FREE PHONE SYSTEM
A cellular telephone should not be used while driving so full attention \
may be given to
vehicle operation.*
SYSTEM OPERATING TIPS

Press the button on the steering wheel to
interrupt the voice prompts at any time and speak
a command after the tone.

To use the system faster, you may speak the
second level commands with the main menu
command on the main menu. For example, press
the
button on the steering wheel, and after
the tone, say “Call Redial”.

The “Help” command can be used to hear a list
of available commands at any time.

Reduce background noise as much as possible
by closing windows and pointing HVAC vents
away from the ceiling.

Speak naturally without long pauses and without
raising your voice.

When speaking phonebook names, please be
aware some cellular phones require the last name to be spoken before the\
first name.
For example, “Michael Smith” may be spoken as “Smith Michael”.

To cancel a Voice Recognition session, simply wait 5 seconds, say “Cancel” or “Quit”,
or press and hold the
button on the steering wheel for 5 seconds.

To increase or decrease the volume of the voice prompts, push the volume \
control
switches + or -
on the steering wheel or turn the control dial on the audio system
while the audio system is responding.
BLUETOOTH® SYSTEM WITHOUT NAVIGATION (if so equipped)
CONNECTING PROCEDURE
The vehicle must be stationary when connecting the cellular phone.
1. Press the
button on the steering wheel. The system announces the
available commands.
2. Say: “Connect Phone”. The system acknowledges the command and announces the
next set of available commands.
3. Say: “Add Phone”. The system acknowledges the command and asks you to initiate
connecting from the cellular phone handset.
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
