2016 NISSAN Towing Guide 6
5th Wheel or Gooseneck Hitch –
A 5th wheel or gooseneck hitch mounts
in the bed of a pick-up and is designed for
heavy-duty applications. A gooseneck
hitch is available from NISSAN for the
Titan. At this time, Titan and Titan XD are
the only NISSAN vehicles approved for
5th wheel and gooseneck trailer towing
.
A 5th wheel or gooseneck hitch is
usually installed and adjusted to meet the
requirements of a particular trailer, but two
basic rules hold true in every case. First,
the hitch should be mounted a minimum
2 inches forward of the rear axle
centerline. Second, it should be securely
attached directly to the truck frame. Only,
professionals should do this installation.
WARNING- It is very important to
mount the hitch correctly to distribute the
king pin load for the proper load carrying
and to control sway. If the trailer sway is
not controlled, it could result in unsafe
vehicle handling which could cause an
accident, property damage, personal injury,
or death.
BALL MOUNT
A ball mount (also known as a drawbar) is a bar that holds a hitch ball, which inserts into a
receiver-type hitch. Ball mounts come in a number of weight capacities (3,500 lbs., 5,000
lbs., etc.) and sizes (1
1/4”, 2”, etc.), and can be
weight distributing or non-weight-distributing.
Choose a proper class ball mount based on
the trailer weight.
HITCH BALL
A hitch ball is bolted through a ball mount or
hitch hole in the tow vehicle’s rear bumper.
The coupler on the trailer tongue attaches
over the hitch ball. Like ball mounts, hitch
5th Wheel Hitch
Gooseneck Hitch
Hitch
Mount BallBall
2016 NISSAN Towing Guide 22 NOTES – All NISSAN vehicles have an engine protection mode, which helps reduce the
chance of engine damage if the engine coolant reaches a specified temperature. See your
vehicle owner’s manual for details.
1 Maximum Trailer Weight values are calculated assuming a base vehicle with driver and any
options to achieve the rating. Additional passengers, cargo and/or additional optional
equipment will add weight to the vehicle and reduce your vehicle’s maximum towing
capacity and trailer tongue load.
2 Use of a weight-distributing hitch system is required when towing over 5,000 lbs.
3 The Maximum Trailer Weight and Gross Combined Weight ratings for 5th wheel and
gooseneck trailer towing are the same as specified for conventional trailer towing.
4 Most states require a separate braking system on trailers with a loaded weight above a
specific amount. Check local regulations where you plan to tow. A 4 or 7-pin type
connector trailer wire harnesses may be required for use with trailer brakes (available
separately).
Other Recommendations and Information – Towing performance and speed are affected by
vehicle payload, tow weight, road grades, and weather conditions, including high
temperatures. See your vehicle owner’s manual for details.
TOWING GLOSSARY
5TH WHEEL
HITCH Located just forward of the rear axle centerline, this hitch uses a king pin to
serve as the pivot point for the trailer.
BALL MOUNT A bar that holds the hitch ball and is inserted into the hitch receiver. Also
commonly called a drawbar.
BREAKAWAY SWITCH A safety device using a trailer battery that automatically applies the trailer’s
brakes if the trailer accidentally becomes separated from the tow vehicle.
A breakaway switch may be used with both electric or surge trailer brake
systems.
BUMPER HITCH A reinforced bumper designed to accommodate a hitch ball.
ELECTRIC TRAILER
BRAKES When the brakes on a tow vehicle are applied, an electric current is sent to
an actuator, which applies the trailer’s brakes.
ELECTRIC TRAILER
BRAKE CONTROLLER A device that controls the electric trailer brakes.
GOOSENECK HITCH Located just forward of the rear axle centerline, this hitch uses a ball to serve
as the pivot point for the trailer.
GROSS AXLE
WEIGHT RATING (GAWR) The maximum amount of weight each vehicle axle (front and rear) is
designed to safely carry.
