2016 LEXUS LX570 display

393
LX570_OM_OM60N01U_(U)
5Interior features
5-1. Remote Touch screenRemote Touch/12.3-inch display ..........................................394
5-2. Lexus Climate Concierge Lexus Climate Concierge ..... 400
5-3. Using the air conditioning system and defogger
Front automatic air conditioning system ................ 401
Rear air conditioning system ........................................... 412
Heated steering wheel/seat heaters/seat ventilators.......... 415 5-4. Using the interior lights
Interior lights list .......................... 419• Interior lights .......................... 420
• Personal lights .........................421
5-5. Using the storage features List of storage features ............ 422• Glove box ............................... 423
• Console box........................... 423
• Overhead console .............. 424
• Cup holders ........................... 425
• Bottle holders ........................ 426
• Card holder............................ 426
• Auxiliary boxes ......................427
Luggage compartment features........................................ 429
5-6. Using the other interior features
Other interior features ............. 431 • Cool box ................................... 431
• Sun visors ................................ 432
• Vanity mirrors ........................ 432
• Clock ........................................ 433
• Power outlets ......................... 434
• Wireless charger.................. 436
• Armrest .................................... 443
• Rear door sunshades ......... 444
• Coat hooks ............................. 444
• Assist grips.............................. 445
Garage door opener................ 446
LEXUS Enform Safety Connect ........................................451

394
LX570_OM_OM60N01U_(U)5-1. Remote Touch screen
Remote Touch/12.3-inch display
“MAP” button
Press this button to display the vehicle’s current position.
“
 • ” button
Press this button to change map scale and scroll through lists.
Back button
Press this button to display the previous screen.
“MENU” button
Press this button to display the “Menu” screen.
Remote Touch knob
Move in the desired direction to select a function, letter and screen button.
Press the knob to enter the selected function, letter or screen button.
“ENTER” button
Press this button to enter the selected function, letter or screen button.
The Remote Touch can be used to operate the Remote Touch screens.
Owners of models equipped with a navi gation system should refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.
Remote Touch operation
1
2
3
4
5
6

LX570_OM_OM60N01U_(U)
3955-1. Remote Touch screen
5
Interior features
Select: Move the Remote Touch
knob in the desired direction.
Enter: Press the Remote Touch knob
or “ENTER” button.
■Screen display during low temperatures
When the ambient temperature is extremely low, screen response may be delayed even
if the Remote Touch is operated.
Remote Touch operation
1
2
WA R N I N G
■When using the Remote Touch
●Do not allow fingers, fingernails or hair to become caught in the Remote Touch as this
may cause an injury.
●Be careful when selecting the Remote To uch in extreme temperatures as it may
become very hot or cold due to the temperature inside the vehicle.
NOTICE
■To prevent damage to the Remote Touch
●Do not allow the Remote Touch to come into contact with food, liquid, stickers or lit
cigarettes as doing so may cause it to change color, emit a strange odor or stop func-
tioning.
●Do not subject the Remote Touch to excessive pressure or strong impact as the knob
may bend or break off.
●Do not allow coins, contact lenses or other such items to become caught in the
Remote Touch as this may cause it to stop functioning.
●Items of clothing may rip if they become caught on the Remote Touch knob.
●If your hand or any object is on the Remote Touch knob when the engine switch is in
ACCESSORY mode, the Remote Touch knob may not operate properly.

3965-1. Remote Touch screen
LX570_OM_OM60N01U_(U)
Press the “MENU” button on the Remote Touch to display the “Menu” screen.
The display may differ depending on the type of the system.
When the split-screen display is selected , the “Menu” screen will be displayed on
the main display. ( P. 3 9 7 )
“Menu” screen
SwitchFunction
Select to display the “Destination” screen.*
Select to display the radio control screen.*
Select to display the media control screen.*
Select to display the hands-free operation screen.*
Select to display the “LEXUS App Suite” screen.*
Select to display the “Information” screen.*
Select to display the air conditioning control screen. ( P. 4 0 1 )
Select to display the “Setup” screen.*

LX570_OM_OM60N01U_(U)
3975-1. Remote Touch screen
5
Interior features
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
■Full screen display
The following functions can be displayed full screen:
●Initial screen
●“Menu” screen (P. 3 9 6 )
●Map screen*
*
: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
“Display”Select to adjust the contrast and br ightness of the screens, turn the
screen off, etc.*
12.3-inch display operation
SwitchFunction

3985-1. Remote Touch screen
LX570_OM_OM60N01U_(U)
■Split-screen display
Different information can be displayed on the left and right of the screen. For
example, air conditioning system or audio screens can be displayed and oper-
ated while the fuel consumption inform ation screen is being displayed. The
large screen on the left of the display is called the main display, and the small
screen to the right is called the side display.

LX570_OM_OM60N01U_(U)
3995-1. Remote Touch screen
5
Interior features
■Main Display
For details about the functions and operation of the main display, refer to the
respective section and “NAVIGATION SYSTEM OWNER’S MANUAL”.
■Side Display
Basic screens
To change the screen displayed on the side display, use the screen buttons on
the right side of the display.
Navigation system
*
Audio*
Phone*
Vehicle information ( P. 1 0 5 )
Air conditioning system
( P. 4 0 1 )
Interruption screens
Each of the following screens is displayed automatically in accordance with
conditions. • Intuitive parking assist
* (  P. 2 8 9 )
•Phone
*
• Destination Assist
•Driving mode ( P. 2 8 6 )
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
Split-screen display operation
1
2
3
4
5

401
LX570_OM_OM60N01U_(U)5-3. Using the air conditio
ning system and defogger
5
Interior features
Front automatic air conditioning system
■Adjusting the temperature setting
Press to increase the temperature and to decrease the tem-
perature.
■Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan
speed.
Press to turn the fan off.
Air outlets and fan speed are automatica lly adjusted according to the temper-
ature setting.
Select the “MENU” button on the Remote Touch, then select to display
the air conditioning control screen. ( P. 3 9 6 )
The air conditioning system can be disp layed and operated on the “Side Dis-
play”. ( P. 3 9 8 )
Control panel
