2016 LEXUS IS250 brake sensor

157
2-3. Operating the lights and windshield wipers
2

When driving
AFS (vehicles with discharge headlights)
AFS (Adaptive Front-lighting System) improves visibility at intersections
and on curves by automatically adjusting the level of the headlights
according to vehicle speed and the degree of the tire angle that are con-
trolled by steering input.
Operates at speeds of 6 mph (10 km/h) or higher.
nDeactivating AFS
How to switch: →P. 2 6 0
“AFS OFF” turns on when the AFS is deactivated.
nDaytime running light system
To make your vehicle more visible to other drivers, the headlights turn on automati-
cally (at a reduced intensity) whenever the engine is started and the parking brake
is released. Daytime running lights are not designed for use at night.
nHeadlight control sensor
The sensor may not function properly if an
object is placed on the sensor, or anything
that blocks the sensor is affixed to the wind-
shield.
Doing so interferes with the sensor detecting
the level of ambient light and may cause the
automatic headlight system to malfunction.

174
2-4. Using other driving systems
Driving in vehicle-to-vehicle distance control mode
This mode employs a radar sensor to detect the presence of vehicles
within 328 ft. (100 m) ahead and to judge the distance between your
vehicle and those vehicles.
Note that vehicle-to-vehicle distance will close when traveling on long down-
hill slopes.
Example of constant speed cruising (when there are no vehicles
ahead): When set to 62 mph (100 km/h)
The vehicle travels at the speed set by the driver. The desired vehicle-to-vehi-
cle distance can also be set by operating the vehicle-to-vehicle distance
switch.
Example of deceleration cruising (when the vehicle ahead is driving
slower than the set speed): When fixed speed cruising is set at 62 mph
(100 km/h) and the vehicle ahead is driving at 50 mph (80 km/h)
When a vehicle is detected running ahead of you, in the same lane, the sys-
tem automatically decelerates your vehicle. When a greater reduction in
vehicle speed is necessary, the system applies the brakes. A warning tone
warns you when the system cannot decelerate sufficiently to prevent your
vehicle from closing on the vehicle ahead.
Example of follow-up cruising (when following a vehicle driving slower
than the set speed): When the speed is set to 62 mph (100 km/h) and
the vehicle ahead is driving at 50 mph (80 km/h)

178
2-4. Using other driving systems
CAUTION
nSituations unsuitable for dynamic radar cruise control
Do not use dynamic radar cruise control in any of the following situations.
Doing so may result in inappropriate control of speed and could cause serious or
fatal accident.
lIn heavy traffic
lOn roads with sharp bends
lOn winding roads
lOn slippery roads, such as those covered with rain, ice or snow
lOn steep downhills, or where there are sudden changes between sharp up and
down gradients
lAt entrances to expressways
lWhen weather conditions are bad enough that they may prevent the sensors
from functioning correctly (fog, snow, sandstorm, etc.)
lWhere buzzer can be heard often
nWhen the radar sensor may not be correctly detecting the vehicle ahead
Apply the brakes as necessary when any of the following types of vehicles are in
front of you.
As the sensor may not be able to correctly detect these types of vehicles, the prox-
imity alarm (→P. 392) will not be activated, and an accident may result.
lVehicles that cut in suddenly
lVehicles traveling at low speeds
lVehicles that are not moving
lVehicles with small rear ends (trailers with no load on board etc.)
lMotorcycles traveling in the same lane

179
2-4. Using other driving systems
2

When driving
CAUTION
nConditions under which the vehicle-to-vehicle distance control may not function
correctly
Apply the brakes as necessary in the following conditions as the radar sensor may
not be able to correctly detect vehicles ahead, and an accident may result.
lWhen water or snow thrown up by the surrounding vehicles hinders the function-
ing of the sensor
lWhen your vehicle is pointing upwards (caused by a heavy load in the trunk, etc.)
lWhen the road curves or when the lanes are narrow
lWhen steering wheel operation or your position in the lane is unstable
lWhen the vehicle ahead of you decelerates suddenly
nHandling the radar sensor
Observe the following to ensure the cruise control system can function effectively:
lKeep the sensor and front grille clean at all times.
Clean the sensor and front grille with a soft cloth so you do not mark or damage
them.
lDo not subject the sensor or surrounding area to a strong impact.
If the sensor moves even slightly off position, the system may malfunction. If the
sensor or surrounding area is subject to a strong impact, always have the area
inspected and adjusted by a Lexus dealer.
lDo not disassemble the sensor.
lDo not attach accessories or stickers to the sensor, grille or surrounding area.
lDo not modify or paint the sensor and grille.
nTo ensure the radar sensor functions correctly
Do not do the following to the sensor or grille cover as doing so may cause the sen-
sor not to function correctly and could result in an accident.
lStick or attach anything to them
lLeave them dirty
lDisassemble, subject them to strong shocks
lModify or paint them
lReplace them with non-genuine parts

192
2-4. Using other driving systems
PCS (Pre-Collision System)∗
Radar sensor
Detects vehicles or other obsta-
cles on or near the road ahead and
determines whether a collision is
imminent based on the position,
speed, and heading of the obsta-
cles.
Grille cover
Radar sensor
Safety systems such as the brakes and seat belts are automatically
engaged to lessen impact and injuries to occupants as well as vehicle dam-
age when the radar sensor detects an unavoidable frontal collision.
nPre-collision seat belts
The seat belts are immediately retracted to provide the driver and passen-
gers with enhanced pretensioner effectiveness in a collision. (→P. 5 7 ) I n
the event of sudden braking or skidding, the system will operate even if no
obstacle has been detected.
nPre-collision brake assist
Applies greater braking force in relation to how strongly the brake pedal is
depressed.
nObstacles not detected
The sensor cannot detect plastic obstacles such as pylons. There may also be occa-
sions when the sensor cannot detect pedestrians, animals, bicycles, motorcycles,
trees, or snowdrifts.
∗: If equipped

5

When trouble arises
381
5-1. Essential information
Event data recorder
In a crash or a near car crash event
The SRS airbag sensor assembly contains the EDR. In a crash or a near
car crash event, this device may record some or all of the following infor-
mation:
lEngine speed
lWhether the brake pedal was applied or not
lVehicle speed
lTo what extent the accelerator pedal was depressed
lPosition of the transmission shift lever
lWhether the driver and front passenger wore seat belts or not
lDriver's seat position
lSRS airbag deployment data
lSRS airbag system diagnostic data
lFront passenger’s occupant classification
The information above is intended to be used for the purpose of improv-
ing vehicle safety performance. Unlike general data recorders, the EDR
does not record sound data such as conversation between passengers.
Your vehicle has computers that monitor and control certain aspects of
your vehicle. These computers assist in driving and maintaining optimal
vehicle performance.
Besides storing data useful for troubleshooting, there is an event data
recorder (EDR) that records data in a crash or a near car crash event.

482
Alphabetical index
Parking assist sensors ..........................180
Parking brake .......................................... 140
Parking lights
Replacing light bulbs........................ 363
Switch ....................................................... 156
Wattage.................................................. 445
PCS ............................................................. 192
Personal lights
Switch ...................................................... 249
Power outlet............................................265
Power windows ........................................ 69
Pre-collision system.............................. 192
Radar cruise control ............................. 170
Radiator ..................................................... 319
Radio .......................................................... 222
RDS ............................................................ 223
Rear sunshade ....................................... 273
Rear turn signal lights
Replacing light bulbs........................ 363
Wattage.................................................. 445
Rear view mirror
Compass ............................................... 287
Rear window defogger........................ 218
Replacing
Electronic key battery...................... 345
Fuses ........................................................ 347
Light bulbs............................................. 363
Reporting safety defects for
U.S. owners .......................................... 470
Scuff lighting ............................................247
Seat belts
Adjusting the seat belt ........................ 57
Automatic locking retractor ........... 58
Child restraint system
installation ............................................ 104
Cleaning and maintaining
the seat belts .................................... 296
Emergency locking retractor......... 58
How to wear your seat belt ............ 56
How your child should wear
the seat belt.......................................... 59
Pregnant women,
proper seat belt use ........................ 58
Reminder light..................................... 385
Seat belt extenders.............................. 59
Seat belt pretensioners ...................... 57
Seat heaters ................................. 266, 269
Seat position memory............................ 52
Seat ventilators ...................................... 269
Seating capacity......................................199
Seats
Adjustment ...............................................46
Adjustment precautions .................... 47
Child seats/child restraint
system installation............................ 104
Cleaning ................................................ 295
Driver’s seat position memory ...... 48
Front passenger seat position
memory ..................................................52
Head restraint .........................................54
Properly sitting in the seat.................82
Seat heaters ............................. 266, 269
Ventilated seats.................................. 269
Service reminder indicators ............ 148
