2016 LEXUS IS250 stop start

51
1-3. Adjustable components (seats, mirrors, steering wheel)
1

Before driving
nCanceling the linked door unlock operation
Turn the “ENGINE START STOP” switch OFF and close the driver's door.
Using the wireless remote control: While pushing the “SET” button, press
on the wireless remote control until the signal beeps.
Using the door lock switch: While pressing the “SET” button, press the
lock or unlock side on the door lock switch until the signal beeps.
nOperating the driving position memory after turning the “ENGINE START
STOP” switch OFF
Memorized positions (except for the steering wheel positions) can be activated up
to 180 seconds after the driver's door is opened and another 60 seconds after it is
closed again, even after turning the “ENGINE START STOP” switch OFF.
nTo cancel seat position recall
Perform any of the following operations.
lPush the “SET” button.
lPush button “1”, “2” or “3”.
lAdjust the seat using the switches (only cancels seat position recall).
nIf the battery is disconnected
The memorized positions are erased when the battery is disconnected.
CAUTION
nSeat adjustment caution
Take care during seat adjustment that the seat does not strike the rear passenger or
squeeze your body against the steering wheel.
STEP1
STEP2

53
1-3. Adjustable components (seats, mirrors, steering wheel)
1

Before driving
nOperating the seat position memory after turning the “ENGINE START STOP”
switch OFF
Memorized position can be activated up to 180 seconds after the front passenger
door is opened, even after turning the “ENGINE START STOP” switch OFF.
nTo cancel seat position recall
Perform any of the following operations.
lPush the “SET” button.
lPush button “1”, “2” or “3”.
lAdjust the seat position using the switches.
nIf the battery is disconnected
The memorized positions are erased when the battery is disconnected.
CAUTION
nSeat adjustment caution
Take care during seat adjustment that the seat does not strike the rear passenger.

63
1
1-3. Adjustable components (seats, mirrors, steering wheel)

Before driving
Steering wheel (power-adjustable type)
Auto tilt away
When the “ENGINE START
STOP” switch is turned OFF, the
steering wheel returns to its
stowed position by moving up and
away to enable easier driver entry
and exit.
Switching to ACCESSORY or
IGNITION ON mode will return
the steering wheel to the original
position.
The steering wheel can be adjusted to a comfortable position.
Up
Down
Away from the driver
Toward the driver

64
1-3. Adjustable components (seats, mirrors, steering wheel)
nThe steering wheel can be adjusted when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
nAutomatic adjustment of the steering position (vehicles with driving position
memory)
A desired steering position can be entered to memory and recalled automatically
by the driving position memory. (→P. 4 8 )
nCustomization that can be configured at Lexus dealer
It is possible to deactivate the auto tilt-away function.
(Customizable features→P. 4 6 1 )
CAUTION
nCaution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and an accident, resulting in
death or serious injury.

65
1
1-3. Adjustable components (seats, mirrors, steering wheel)

Before driving
Anti-glare inside rear view mirror
nTo prevent sensor error
CAUTION
nCaution while driving
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and an accident, resulting in death
or serious injury.
In automatic mode, sensors are used to detect the headlights of vehicles
behind and automatically reduce the reflected light.
Turns automatic mode on/off
The indicator comes on when
automatic mode is turned on.
The anti-glare mirror default
mode is automatic. The anti-
glare mirror is automatically set
to automatic whenever the
“ENGINE START STOP” switch
is turned to IGNITION ON
mode.
To ensure that the sensors operate properly,
do not touch or cover them.

66
1-3. Adjustable components (seats, mirrors, steering wheel)
Outside rear view mirrors
nThe mirrors can be adjusted when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
nWhen the mirrors are fogged up
Turn on the mirror defoggers to defog the mirrors. (→P. 2 1 8 )
nFolding back the mirrors
nOne-touch adjustment of the mirror angle
(vehicles with driving position memory)
A desired mirror face angle can be entered to memory and adjusted with the touch
of a button. (→P. 4 8 )
Mirror angle can be adjusted using the switch.
Select a mirror to adjust
(“L”: left or “R”: right)
Adjust the mirror up, down,
in, or out using the switch
Push back in the direction of the vehicle's
rear.

70
1-4. Opening and closing the windows and moon roof
nThe power windows can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
nDoor lock linked window operation
lThe power windows can be opened and closed using the mechanical key.
(→P. 41 7 )
lThe power windows can be opened using the wireless remote control. (→P. 36 )
nOperating the power windows after turning the “ENGINE START STOP” switch
OFF
The power windows can be operated for approximately 45 seconds even after the
“ENGINE START STOP” switch is switched to ACCESSORY mode or turned
OFF. They cannot, however, be operated once either front door is opened.
nJam protection function
If an object becomes caught between the window and the window frame, window
travel is stopped and the window is opened slightly.
nCustomization that can be configured at Lexus dealer
Settings (e.g. linked door lock operation) can be changed.
(Customizable features →P. 4 6 1 )
CAUTION
nClosing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury.
lCheck to make sure that all passengers do not have any part of their body in a
position where it could be caught when a window is being operated.
lDo not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in some
instances, even death.
nJam protection function
lNever try jamming any part of your body to activate the jam protection function
intentionally.
lThe jam protection function may not work if something gets caught just before
the window fully closes.

72
1-4. Opening and closing the windows and moon roof
nThe moon roof can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
nMoon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the
instrument panel when the “ENGINE START STOP” switch is turned OFF and the
driver's door is opened with the moon roof open.
nLinked door lock moon roof operation
lThe moon roof can be opened and closed using the mechanical key. (→P. 41 7 )
lThe moon roof can be opened using the wireless remote control. (→P. 36 )
lThe moon roof can be closed using the entry function. (→P. 25 )
nOperating the moon roof after turning the “ENGINE START STOP” switch OFF
The moon roof can be operated for approximately 45 seconds even after the
“ENGINE START STOP” switch is switched to ACCESSORY mode or turned
OFF. It cannot, however, be operated once either front door is opened.
nJam protection function
If an object is detected between the moon roof and the frame while closing or tilting
down, travel is stopped and the moon roof opens slightly.
nWhen the moon roof does not close normally
Pressing and holding the “CLOSE” switch will close the moon roof.
nTo reduce moon roof wind noise
Drive with the moon roof opened to slightly before the fully open position as driving
with the moon roof opened fully will cause wind noise.
nSunshade
The sunshade can be opened and closed manually. However, the sunshade will
open automatically when the moon roof is opened.
nCustomization that can be configured at Lexus dealer
Settings (e.g. linked door lock operation) can be changed.
(Customizable features →P. 4 6 1 )
