4006-4. Using the other interior features
IS350/300/200t_U (OM53D18U)
“SOS” button
LED light indicators
Microphone
LEXUS Enform Safety Connect 
: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embe dded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, wh ich operates 24 hours per day, 7 days
per week.
Safety Connect service is available by su bscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, yo u are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.
System components
1
2
3

4026-4. Using the other interior features
IS350/300/200t_U (OM53D18U)
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:
●Green indicator light on = Active service
●Green indicator light flashing = Safety Connect call in process
●Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)
●No indicator light (off) = Safety Connect service not active
■Automatic Collis ion Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be se nt to the location.
Safety Connect LED light Indicators
Safety Connect services

4187-2. Maintenance
IS350/300/200t_U (OM53D18U)
The OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pa ss the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle.
●When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may not be com-
pletely set.
●When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehicle is driven
40 or more times.
Contact your Lexus dealer to prepare the vehicle for re-testing.
Emission inspection an d maintenance (I/M)
programs
Some states have vehicle emission inspection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M test in the following situations:
When the malfunction indicator lamp s till remains on after several driv-
ing trips
If your vehicle does not pass the I/M test

5389-1. Specifications
IS350/300/200t_U (OM53D18U)
■Recommendation of the use of gasoli ne containing detergent additives
●Lexus recommends the use of gasoline that contains detergent additives to avoid the
build-up of engine deposits.
●All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or
keep clean intake systems, per EPA’s lowest additives concentration program.
●Lexus strongly recommends the use of Top Ti er Detergent Gasoline. For more informa-
tion on Top Tier Detergent Gasoline and a list of marketers, please go to the official
website www.toptiergas.com.
■Recommendation of the use of low emission gasoline
Gasolines containing oxygenates such as et hers and ethanol, as well as reformulated
gasolines, are available in some cities. These fuels are typically acceptable for use, pro-
viding they meet other fuel requirements.
Lexus recommends these fuels, since the fo rmulations allow for reduced vehicle emis-
sions.
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your vehicle, be sure th at it has an octane rating no lower than 87.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancin g additive called MMT (Methylcyclopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasolin e that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instru ment cluster may come on. If this happens,
contact your Lexus dealer for service.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking fo r a short time while accelerating or driv-
ing uphill. This is normal and there is no need for concern.
●Use only gasoline containing up to 15% etha-
nol.
DO NOT use any flex-fuel or gasoline that
could contain more than 15% ethanol, includ-
ing from any pump labeled E30, E50, E85
(which are only some examples of fuel con-
taining more than 15% ethanol).DO NOT use gasoline con-
taining more than 15% ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

590Alphabetical index
IS350/300/200t_U (OM53D18U)
MaintenanceDo-it-yourself maintenance........... 419
General maintenance ...................... 415
Maintenance data ..............................524
Maintenance requirements.............412
Maintenance system .............................. 89
Malfunction indicator lamp .............. 476
Master warning light ............................477
Meter Changing the display..........................83
Indicators................................................... 78
Instrument panel light control .........84
Meters.......................................................... 81
Multi-information display ..................86
Warning lights ........................................ 77
Micro dust and pollen filter ................ 371
Mirrors Inside rear view mirror ..................... 136
Outside rear view mirror defoggers ........................................... 372
Outside rear view mirrors .............. 138
Vanity mirrors ......................................387 MMS (Multimedia messaging
service).................................................. 338
Mobile Assistant ................................... 282
Moon roof ................................................. 144 Door lock linked moon roof operation......................145
Jam protection function....................145
Operation................................................ 144
MP3 disc ................................................. 306
Multi-information display..................... 86 Audio system-linked ........................... 86
Drive information .................................. 87
Dynamic radar cruise control ..... 202
LDA (Lane Departure Alert).........218
Navigation system-linked ................ 86
Settings ...................................................... 89
Switching the display .......................... 87
Warning message............................. 482
Navigation system
*
Needle ......................................................... 89
Noise from under vehicle ........................8
M
N

593Alphabetical index
IS350/300/200t_U (OM53D18U)
Seat belt reminder light.......................477
Seat belts..................................................... 30Adjusting the seat belt ..........................31
Automatic Locking Retractor......... 32
Child restraint system installation................................................61
Cleaning and maintaining the seat belt ........................................ 410
Emergency Locking Retractor ................................................ 32
How to wear your seat belt .............30
How your child should wear the seat belt .......................................... 32
Pregnant women, proper seat belt use.......................................... 33
Reminder light and buzzer ........... 477
Seat belt extender................................. 32
Seat belt pretensioners ........................31
SRS warning light ............................... 476
Seat heaters .............................................377
Seat position memory...........................126
Seat ventilators .......................................377
Seating capacity....................................... 161 Seats, Front ............................................... 123
Adjustment.............................................. 123
Adjustment precautions................... 123
Child seats/child restraint system installation ............................. 58
Cleaning.................................................409
Driving position memory................. 126
Head restraints .......................................131
Power easy access system ............. 126
Properly sitting in the seat ................ 28
Seat heaters ...........................................377
Seat position memory ....................... 126
Seat ventilators.....................................377
Seats, Rear ................................................ 124 Fold down the seatback................... 124
Luggage security system...................112
Sensor Automatic headlight system .......... 179
Automatic High Beam system .... 185
Inside rear view mirror...................... 137
Intuitive parking assist...................... 223
LDA (Lane Departure Alert)......... 217
Radar sensor................. 210, 256, 264
Rain-sensing windshield wipers.....................................................193
Service reminder indicators ................ 76
S
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

594Alphabetical index
IS350/300/200t_U (OM53D18U)
Shift lever ...................................................169Automatic transmission ................... 169
If the shift lever cannot be shifted from P ...........508
Shift lock system....................................508
Shift position and gear position ...........81
Side airbags ............................................... 37
Side marker lights...................................178 Light switch ............................................ 178
Replacing light bulbs ........................463
Side mirrors ............................................. 138 Adjusting and folding........................ 138
BSM (Blind Spot Monitor)............ 262
Linked mirror function when reversing ................................. 139
Mirror position memory .................. 126
Side turn signal lights ............................ 175 Replacing light bulbs ........................463
Turn signal lever .................................. 175
Side windows ............................................ 141
Slip indicator............................................477
Smart access system with push-button start ........................ 116Antenna location ................................... 116
Entry functions ............................... 105, 111
Starting the engine ............................. 164 SMS (Short message service) ........ 338
Snow mode ............................................... 170
Snow tires ................................................. 272
Spare tire ..................................................496
Inflation pressure................................ 534
Storage location ................................. 497
Spark plug ................................................. 531
Specifications..........................................524
Speedometer .............................................. 81
Speed indicator........................................ 89
Steering lock ............................................ 166 Column lock release .........................166
Steering wheel ........................................ 134 Adjustment.............................................. 134
Audio switches .....................................281
Heated steering wheel ................... 376
Power easy access system ............. 126
Steering wheel position memory .............................. 126
Stop lights Replacing light bulbs ....................... 463
Storage feature .......................................381
Stuck If the vehicle becomes stuck........520
Sun visors................................................. 387
