GX460_OM_OM60M73U_(U)5-4. Using the other interior features
LEXUS Enform Safety Connect
Microphone
LED light indicators
“SOS” button
: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embe
dded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, wh ich operates 24 hours per day, 7 days
per week.
Safety Connect service is available by su bscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, yo u are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.
System components
1
2
3

434
GX460_OM_OM60M73U_(U)5-4. Using the other interior features
■Languages
The Safety Connect resp
onse center will offer support in multiple languages. The Safety
Connect system will offer voice prompts in English and Spanish. Please indicate your lan-
guage of choice when enrolling.
■When contacting the response center
You may be unable to contact the resp onse center if the network is busy.
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:
●Green indicator light on = Active service
●Green indicator light flashing = Safety Connect call in process
●Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)
●No indicator light (off) = Safety Connect service not active
■Automatic Collis ion Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be se nt to the location.
Safety Connect LED light Indicators
Safety Connect services

450
GX460_OM_OM60M73U_(U)6-2. Maintenance
Emission inspection and
maintenance (I/M) programs
The OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pa ss the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle.
●When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may not be com-
pletely set.
●When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehicle is driven
40 or more times.
Contact your Lexus dealer to prepare the vehicle for re-testing.
Some states have vehicle emission inspection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M test in the following situations:
When the malfunction indicator lamp s till remains on after several driv-
ing trips
If your vehicle does not pass the I/M test

GX460_OM_OM60M73U_(U)
5738-1. Specifications
8
Vehicle specifications
■Recommendation of the use of gasoline containing detergent additives
●Lexus recommends the use of gasoline that contains detergent additives to avoid the
build-up of engine deposits.
●All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or
keep clean intake systems, per EPA’s lowest additives concentration program.
●Lexus strongly recommends the use of Top Ti er Detergent Gasoline. For more informa-
tion on Top Tier Detergent Gasoline and a list of marketers, please go to the official
website www.toptiergas.com.
■Recommendation of the use of low emissions gasoline
Gasolines containing oxygenates such as et hers and ethanol, as well as reformulated
gasolines, are available in some cities. These fuels are typically acceptable for use, pro-
viding they meet other fuel requirements.
Lexus recommends these fuels, since the fo rmulations allow for reduced vehicle emis-
sions.
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your Lexus, be sure that it has an octane rating no lower than 87.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcy clopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasolin e that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instru ment cluster may come on. If this happens,
contact your Lexus dealer for service.
●Use only gasoline containing up to 15% etha-
nol.
DO NOT use any flex-fuel or gasoline that
could contain more than 15% ethanol, includ-
ing from any pump labeled E30, E50, E85
(which are only some examples of fuel con-
taining more than 15% ethanol).DO NOT use gasoline
containing more than 15%
ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

626Alphabetical index
GX460_OM_OM60M73U_(U)
Seat heaters ............................................ 394
Seat ventilators ...................................... 395
Seat position memory............................ 131
Seats....................................................118, 120Adjustment .................................... 118, 120
Adjustment precautions ......... 119, 130
Child seats/child restraint system installation.............................. 57
Cleaning .................................................. 441
Driving position memory .................. 131
Head restraint ....................................... 136
Properly sitting in the seat ................ 26
Seat position memory......................... 131
Ventilators ............................................ 395
Sensor Automatic headlight system .......... 198
Inside rear view mirror ......................142
Intuitive parking assist-sensor .................................... 238
Rain-sensing windshield wipers .................................................. 209
Service reminder indicators ................74
Shift lever Automatic transmission ................... 190
If the shift lever cannot be shifted from P .................................. 549
Shift lock system.................................... 549
Shopping bag hooks ........................... 407
Side airbags ............................................... 34
Side mirrors ..............................................143 Adjusting and folding........................ 143
Blind Spot Monitor............................. 351
Side turn signal lights ............................194 Replacing light bulbs ....................... 499
Turn signal lever .................................. 194 Smart access system with
push-button start.................................... 111Antenna location..................................... 111
Starting the engine ............................. 185
Snow tires .................................................373
Spare tire ................................................. 534 Inflation pressure................................ 570
Storage location .................................535
Spark plug ............................................... 566
Specifications......................................... 562
Speedometer ............................................. 79
Steering lock Column lock release ........................ 188
Steering wheel ........................................ 139 Adjustment..............................................139
Audio switches
*
Heated steering wheel ................... 393
Steering wheel position memory...................................................131
Stop/tail lights Replacing light bulbs ....................... 499
Storage feature ..................................... 399
Stuck If the vehicle becomes stuck........559
Sun shade Roof ........................................................... 150
Sun visors................................................... 415
Switch “2nd START” button ........................... 191
AVS switch ........................................... 335
BSM (Blind Spot Monitor) switch .....................................................351
Center differential lock/ unlock switch.................................... 337
Crawl Control switch......................340
Cruise control switch ..............218, 221
“DAC” switch ...................................... 343
