GX460_OM_OM60M73U_(U)6-3. Do-it-yourself maintenance
6
Maintenance and care
Engine compartment
Power steering fluid reservoir
(P. 4 6 3 )
Engine oil level dipstick (P. 4 5 7 )
Engine oil filler cap ( P. 4 5 8 )
Brake fluid reservoir ( P. 4 6 1 )
Fuse box ( P. 4 8 6 ) Battery
( P. 464)
Radiator ( P. 4 6 1 )
Condenser ( P. 4 6 1 )
Cooling fans
Engine coolant reservoir (P. 4 5 9 )
Wa s h e r f l u i d t a n k ( P. 4 6 7 )1
2
3
4
5
6
7
8
9
10
11

486
GX460_OM_OM60M73U_(U)6-3. Do-it-yourself maintenance
Checking and replacing fuses
Turn the engine switch off.
Open the fuse box cover.
Remove the fuse with the pull-out tool.
Only type A fuse can be removed using
the pull-out tool.
If any of the electrical components do not operate, a fuse may have blown. If
this happens, check and replace the fuses as necessary.
1
2
Engine compartmentDriver’s side instrument panel
Push the tab in and lift the lid off. Remove the lid.
3

GX460_OM_OM60M73U_(U)
4876-3. Do-it-yourself maintenance
6
Maintenance and care
Check if the fuse is blown.Normal fuse
Blown fuse
Type A:
Replace the blown fuse with a new fuse of an appropriate amperage rating. The
amperage rating can be found on the fuse box lid.
Ty p e B , C a n d D :
Contact your Lexus dealer.
4
1
2
Ty p e ATy p e B
Ty p e CTy p e D

488
GX460_OM_OM60M73U_(U)6-3. Do-it-yourself maintenance
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (
P. 4 9 1 )
●If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer.
■If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
CAUTION
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or injury.
●Never use a fuse of a higher amperage rati ng than indicated, or use any other object
in place of a fuse.
●Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
●Do not modify the fuses or the fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your Lexus dealer,
as soon as possible.
