612What to do if... (Troubleshooting)
CT200h_OM_OM76197U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, ne w genuine mechanical keys can be made
by your Lexus dealer. ( P. 1 0 2 )
●If you lose your electronic keys, the risk of vehicle theft increases significantly.
Contact your Lexus dealer immediately. ( P. 1 0 4 )
●Is the electronic key battery weak or depleted? ( P. 5 0 4 )
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( P. 1 5 7 )
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on your
person.
●The function may not operate properly du e to the condition of the radio wave.
( P. 1 1 5 )
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is set.
Open the rear door from outside and then unlock the child-protector lock.
( P. 1 0 8 )
If you have a problem, check the following before contacting your Lexus
dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

613What to do if... (Troubleshooting)
CT200h_OM_OM76197U_(U)
●Did you press the power switch while firmly depressing the brake pedal?
(P. 1 5 6 )
●Is the shift position in P? ( P. 1 5 6 )
●Is the electronic key anywhere detectable inside the vehicle? ( P. 1 1 4 )
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way. ( P. 5 6 1 )
●Is the 12-volt battery discharged? ( P. 5 6 2 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be operated
if the window lock switch is pressed. ( P. 1 3 7 )
●The auto power off function will be operated if the vehicle is left in
ACCESSORY or ON mode (the hybrid system is not operating) for a period
of time. ( P. 1 5 8 )
If you think something is wrong
The hybrid system does not start
The windows do not open or close by operating the power window
switches
The power switch is turned off automatically

614What to do if... (Troubleshooting)
CT200h_OM_OM76197U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 5 3 1 )
●The parking brake indicator is on
Is the parking brake released? ( P. 1 6 8 )
Depending on the situation, other type s of warning buzzer may also sound.
( P. 5 2 9 , 5 3 6 )
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 76 )
To stop the alarm, turn the power switch to ON mode or start the hybrid system.
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. ( P. 5 3 6 )
●When a warning light turns on or a warning message is displayed, refer to
P. 5 2 9 , 5 3 6 . A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

618Alphabetical index
CT200h_OM_OM76197U_(U)
Brake assist ............................................. 235
Break-in tips..............................................145
Brightness controlInstrument panel light control .................................................... 85
Card key ................................................... 100
Care Aluminum wheels ..............................463
Exterior....................................................462
Interior .................................................... 465
Seat belts ............................................... 465
Cargo capacity....................................... 153
Cargo hooks .......................................... 434
CD player ..................................... 265, 347
Chains ........................................................247
Child restraint system............................ 53 Booster seats definition ..................... 54
Booster seats installation...................60
Convertible seats definition ............. 54
Convertible seats installation .................................... 58, 59
Front passenger occupant classification system ......................... 47
Infant seats definition ........................... 54
Infant seats installation ....................... 58
Installing child restraint system with LATCH anchors ..................... 57
Installing child restraint system with seat belts ..................................... 58
Installing child restraint system with top tether strap ...........................61
LATCH anchors ...................................56 Child safety .................................................52
12-volt battery precautions .......................... 488, 565
Airbag precautions.............................. 40
Back door precautions.......................112
Child restraint system......................... 53
How your child should wear the seat belt .............................. 33
Installing child restraints .................... 56
Moon roof precautions .................... 142
Power window lock switch............. 137
Power window precautions ...........139
Rear door child-protectors ........... 108
Removed key battery precautions ...................................... 505
Seat belt extender precautions .......................................... 36
Seat belt precautions .......................... 36
Seat heater precautions ................. 425
Child-protectors ................................... 108
Cleaning ....................................... 462, 465 Aluminum wheels .............................. 463
Exterior ................................................... 462
Interior ..................................................... 465
Seat belts................................................ 465
Clock......................................................... 440
Compass ..................................................449
Condenser.............................................. 484
Console box ........................................... 430
Coolant Capacity................................................. 575
Checking ............................................... 482
Preparing and checking before winter .................................... 246
C

620Alphabetical index
CT200h_OM_OM76197U_(U)
ECO lamp .................................................. 86
EDR (Event data recorder) ................... 12
Electric motorLocation .....................................................65
Specification .........................................573
Electric Power Steering (EPS) Function ..................................................235
Warning light ...................................... 530
Electronic key If the electronic key does not operate properly............................ 560
Replacing the battery ...................... 504
Emergency flashers ............................. 522
Emergency, in case of If a warning buzzer sounds...........529
If a warning light turns on...............529
If a warning message is displayed............................................ 536
If the 12-volt battery is discharged .........................................562
If the electronic key does not operate properly............................ 560
If the hybrid system will not start ............................................... 558
If you have a flat tire ......................... 549
If you lose your keys ................102, 104
If you think something is wrong .................................................. 528
If your vehicle becomes stuck ..................................................... 570
If your vehicle has to be stopped in an emergency ..........523
If your vehicle needs to be towed....................................................524
If your vehicle overheats ............... 566 Energy monitor .......................................... 91
Engine
Accessory mode ................................. 157
Compartment ..................................... 478
Engine switch ........................................156
Hood........................................................ 475
How to start the hybrid system ....................................................156
Identification number....................... 573
If your vehicle has to be stopped in an emergency.......... 523
Ignition switch (power switch) ..................................156
Overheating.........................................566
Power switch .........................................156
Engine compartment cover..............479
Engine coolant Capacity................................................. 575
Checking ............................................... 482
Preparing and checking before winter .................................... 246
Engine oil Capacity................................................. 574
Checking ............................................... 479
Oil pressure warning light ............ 529
Engine oil maintenance data ........... 468
Engine switch ........................................... 156 Auto power off function .................. 158
Changing the power switch modes .................................................... 157
If your vehicle has to be stopped in an emergency.......... 523
Starting the hybrid system...............156
EPS (Electronic Power Steering) Function .................................................. 235
Warning light .......................................530
E

623Alphabetical index
CT200h_OM_OM76197U_(U)
JackPositioning a floor jack .................... 477
Vehicle-equipped jack .................. 550
Jack handle .............................................550
Jam protection function Moon roof ................................................ 141
Power windows ................................... 138
Keyless entry Smart access system with push-button start ............................... 114
Wireless remote control .................100
Keys............................................................. 100 Electronic key .......................................100
Engine switch ........................................ 156
If the electronic key does not operate properly............................ 560
If you lose your keys ................102, 104
Key number plate ...............................100
Keyless entry .........................................100
Mechanical key ....................................100
Power switch......................................... 156
Replacing the battery ...................... 504
Warning buzzer .................................... 115
Wireless remote control key ........100
Knee airbags ............................................. 38 Language (multi-information
display) .................................................. 596
LATCH anchors .......................................56
Lever Auxiliary catch lever ......................... 475
Hood lock release lever................. 475
Shift lever ................................................. 162
Turn signal lever ................................... 167
Wiper lever............................................. 174
Lexus Display Audio controller ................91, 206, 412
Lexus parking assist monitor Display..................................................... 220
Function .................................................... 219
Precautions ........................................... 226
License plate lights Light switch.............................................169
Replacing light bulbs .........................519
Light Fog light switch ..................................... 172
Headlight switch ..................................169
Illuminated entry system................. 428
Interior lights ........................................ 428
Interior light list .....................................427
Luggage compartment light ............. 111
Personal lights ......................................427
Replacing light bulbs ...................... 509
Turn signal lever ................................... 167
Vanity lights .......................................... 439
Wattage ................................................. 579
Light bulbs Replacing .............................................. 509
Wattage ................................................. 579
Luggage cover ...................................... 436
J
K
L

626Alphabetical index
CT200h_OM_OM76197U_(U)
Rear turn signal lightsReplacing light bulbs ......................... 518
Turn signal lever ...................................167
Wattage ..................................................579
Rear view mirror Inside rear view mirror ......................132
Outside rear view mirrors .............. 135
Rear view monitor system ................ 209
Rear window defogger ............ 414, 420
Rear window wiper............................... 180
Refueling ................................................... 183 Capacity .................................................573
Fuel types ...............................................573
Opening the fuel tank cap.............. 183
When the fuel filler door cannot be opened .......................... 185
Regenerative braking .............................67
Remote Touch
*................... 91, 206, 412
Replacing Electronic key battery ..................... 504
Fuses........................................................ 506
Light bulbs ............................................ 509
Tires ......................................................... 549
Reporting safety defects for U.S. owners.......................................... 602
Resetting the message indicating maintenance is required ................ 468
Road accident cautions .........................72 Seat belts .....................................................32
Adjusting the seat belt.........................32
Automatic Locking Retractor................................................ 33
Child restraint system installation ............................................. 58
Cleaning and maintaining the seat belt ............................................... 465
Emergency Locking Retractor................................................ 33
How to wear your seat belt............. 30
How your child should wear the seat belt .............................. 33
Pre-collision seat belts ....................... 33
Pregnant women, proper seat belt use ................................................... 35
Reminder light and buzzer .............531
Seat belt extender ................................ 34
Seat belt instructions for Canadian owners ..........................603
Seat belt pretensioners...................... 33
SRS warning light ..............................530
Seat heaters.............................................425
Seat position memory .......................... 124
Seating capacity ..................................... 153
S

630Alphabetical index
CT200h_OM_OM76197U_(U)
Warning buzzersApproach warning ............................. 193
Intuitive parking assist ..................... 205
Open door ........................................... 530
Seat belt reminder .............................. 531
Warning lights ABS.......................................................... 530
Automatic headlight leveling system ................................................. 530
Brake system........................................529
Charging system................................529
Electric power steering.................. 530
High coolant temperature............ 530
Low engine oil pressure .................529
Low fuel level ........................................ 531
Malfunction indica tor lamp ...........529
Master warning light.......................... 531
Open door ........................................... 530
“PCS” ...................................................... 530
Seat belt reminder light.................... 531
Slip indicator ........................................ 530
SRS ........................................................... 530
Tire pressure ......................................... 531
Warning messages .............................. 536
Washer Checking............................................... 485
Low washer fluid warning message ..............................................542
Preparing and checking before winter ....................................246
Switch.........................................................174 Washing and waxing ...........................462
Weights
Cargo capacity.....................................153
Load limits ............................................. 572
Wheels ..................................................... 500 Replacing wheels .............................. 549
Size ........................................................... 577
Window glasses...................................... 137
Window lock switch.............................. 137
Windows Power windows.................................... 137
Rear window defogger ........414, 420
Washer ..................................................... 174
Windshield wiper de-icer ......... 415, 421
Windshield wipers Intermittent windshield wipers ...... 174
Rain-sensing windshield wipers..................................................... 176
Winter driving tips ................................246
Wireless communication ........ 316, 390
Wireless remote control key............ 100 Locking/Unlocking ........................... 100
Panic mode ............................................. 101
Replacing the battery ......................504
WMA disc.................................... 265, 347
XM
® Satellite Radio .................261, 342
W
X
