2016 JEEP WRANGLER display

ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) — IF EQUIPPED
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver-interactive display that is located in the
instrument cluster.This system conveniently allows the driver to select a
variety of useful information by pushing the switches
mounted on the steering wheel. The EVIC consists of the
following:
•
Compass Heading (N, S, E, W, NE, NW, SE, SW)
• Outside Temperature (°F or °C)
• ECO Display
• Digital Speedometer
• Average Fuel Economy
• Distance To Empty
• Tire Pressure Monitor System — If Equipped
• Elapsed Time
• Vehicle Info
• EVIC Units Selection
Electronic Vehicle Information Center (EVIC)
344 UNDERSTANDING YOUR INSTRUMENT PANEL

•System Status and Warnings (Door Ajar, etc.)
• Personal Settings (Customer-Programmable Features)
The system allows the driver to select information by
pushing the following buttons mounted on the steering
wheel: •
MENU Button
Push and release the MENUbutton to advance
the display to each of the EVIC Main Menu
features or to return to the Main Menu from a
sub-menu. Upon reaching the last item in the
Main Menu the EVIC will advance to the first item in the
Main Menu with the next MENUbutton push and
release.
• COMPASS Button
Push and release the COMPASSbutton to
return to the Compass/Outside Temperature/
Audio Information/ECO screen whenever the
current display is not the Compass/Outside
Temperature/Audio Information/ECO screen.
EVIC Steering Wheel Buttons
4
UNDERSTANDING YOUR INSTRUMENT PANEL 345

•RIGHT Arrow Button
Push and release the RIGHTarrow button
when prompted by the EVIC to Reset Main
Menu features with a reset capability or to
change Personal Settings.
• DOWN Arrow Button
Push and release the DOWNarrow button
when prompted by the EVIC to step through
Vehicle Info submenu or stored system warn-
ing messages or Personal Settings features.
Electronic Vehicle Information Center (EVIC)
Displays
When the appropriate conditions exist, the EVIC displays
the following messages:
• Low Tire Pressure
• Low Fuel •
Service TPM System (refer to Tire Pressure Monitor-
ing System inStarting and Operating)
• Damaged Key
• Key in Ignition
• Turn Signal On (with a continuous warning chime)
• Left Front Turn Signal Lamp Out (with a single chime)
• Left Rear Turn Signal Lamp Out (with a single chime)
• Right Front Turn Signal Lamp Out (with a single
chime)
• Right Rear Turn Signal Lamp Out (with a single chime)
• Key Fob Battery Low (with a single chime)
• Personal Settings Not Avail. – Vehicle Not in Park —
automatic transmission
346 UNDERSTANDING YOUR INSTRUMENT PANEL

•Personal Settings Not Avail. – Vehicle in Motion —
manual transmission
• Door Open (with vehicle graphic showing which door
is open. A single chime sounds if the vehicle is in
motion).
• Gate Open (with vehicle graphic showing the
Liftgate/back door open and a single chime sounds if
the vehicle is in motion)
• Check Gascap (refer to “Adding Fuel” in “Starting
And Operating” for further information)
• Oil Change Required (with a single chime)
• ECO (Fuel Saver Indicator) — if equippedEVIC Main Menu
To step to each main menu feature push and release the
MENU button once for each step. A step from the last
item in the list will cause the first item in the feature list
to be displayed. The following features are in the Main
menu:
• Compass, Outside Temperature, and ECO display
• Digital Speedometer
• Average Fuel Economy
• Distance to Empty
• Tire Pressure — If Equipped
• Elapsed Time
• Vehicle Information
• Coolant Temp
• Oil Pressure
4
UNDERSTANDING YOUR INSTRUMENT PANEL 347

•Transmission Temp — Automatic Transmission Only
• Oil Life Remaining (Automatic Oil Change Indica-
tor)
• EVIC Units Selection
• System Status and Warnings
• Personal Settings
NOTE:
For features in the EVIC that can be reset (Average
Fuel Economy and Elapsed Time), the EVIC prompts a reset
with the RIGHT
arrow button graphic and the word
RESET next to it.
When the RIGHTarrow button is pushed, the
selected feature will reset and RESET ALL will display
next to the RIGHT
arrow button . Pushing the
RIGHT
arrow button a second time will reset both
Average Fuel Economy and Elapsed Time. After three seconds without pushing the
RIGHT
arrow but-
ton, RESET ALL will return to RESET and only the
selected feature will have been reset.
Compass, Outside Temperature Display / ECO
(Fuel Saver Mode) — If Equipped
The compass readings indicate the direction the vehicle is
facing. Push and release the COMPASSbutton to display
one of eight compass headings, the outside temperature/
ECO if the EVIC display is not already displaying this
screen.
NOTE: The system will display the last known outside
temperature when starting the vehicle and may need to
be driven several minutes before the updated tempera-
ture is displayed. Engine temperature can also affect the
displayed temperature; therefore, temperature readings
are not updated when the vehicle is not moving.
348 UNDERSTANDING YOUR INSTRUMENT PANEL

ECO (Fuel Saver Mode) — If Equipped
The ECO message will display below the outside tem-
perature in the EVIC display (if the audio system is on
the ECO indicator will override the audio information
display line if theDisplay Fuel Saver personal setting is
ON — see Personal Settings section). This message will
appear whenever you are driving in a fuel efficient
manner.
This feature allows you to monitor when you are driving
in a fuel efficient manner, and it can be used to modify
driving habits in order to increase fuel economy.
Automatic Compass Calibration
This compass is self-calibrating, which eliminates the
need to set the compass manually. When the vehicle is
new, the compass may appear erratic, and the EVIC will
display “CAL” until the compass is calibrated. You may
also calibrate the compass by completing one or more
360–degree turns (in an area free from large metal or metallic objects) until the “CAL” message displayed in
the EVIC turns off. The compass will now function
normally.
NOTE:
A good calibration requires a level surface and
an environment free from large metallic objects such as
buildings, bridges, underground cables, railroad tracks,
etc.
Manual Compass Calibration
If the compass appears erratic and the “CAL” indicator
does not appear in the EVIC display, you must put the
compass into the Calibration Mode manually as follows:
1. Start the engine. Leave the shift lever in PARK in order to enter the EVIC Programming Menus.
2. Push the MENU button until Personal Settings (Customer-Programmable Features) displays in the
EVIC.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 349

3. Push the DOWN button until “Calibrate Compass”displays in the EVIC.
4. Push and release the RIGHT button to start the calibration. The “CAL” indicator will display in the
EVIC.
5. Complete one or more 360–degree turns (in an area free from large metal or metallic objects) until the
“CAL” indicator turns off. The compass will now
function normally.
Compass Variance
Compass Variance is the difference between Magnetic
North and Geographic North. To compensate for the
differences, the variance should be set for the zone where
the vehicle is driven, per the zone map. Once properly
set, the compass will automatically compensate for the
differences and provide the most accurate compass head-
ing. NOTE:
Magnetic materials should be kept away from
the top of the instrument panel; this is where the compass
sensor is located.
Compass Variance Map
350 UNDERSTANDING YOUR INSTRUMENT PANEL

To Change The Compass Variance:
1. Turn the ignition switch RUN (it is not necessary tostart the engine).
2. Push the MENU button until Personal Settings (Customer-Programmable Features) displays in the
EVIC.
3. Push the DOWN button until “Compass Variance” message and the last variance zone number displays
in the EVIC.
4. Push and release the RIGHT button until the proper variance zone is selected according to the map.
5. Push and release the COMPASS button to exit.
Digital Speedometer
Shows the actual vehicle speed in mph or km/h.
Average Fuel Economy
Shows the average fuel economy since the last reset. Average
Fuel Economy can be reset by pushing and holding the
RIGHT
arrow button (as prompted in the EVIC
display). Upon reset, the history information will be
erased, and the averaging will continue from the last
fuel average reading before the reset.
Distance To Empty (DTE)
Shows the estimated distance that can be traveled with
the fuel remaining in the tank. This estimated distance is
determined by a weighted average of the instantaneous
and average fuel economy, according to the current fuel
tank level. DTE cannot be reset.
NOTE: Significant changes in driving style or vehicle
loading will greatly affect the actual drivable distance of
the vehicle, regardless of the DTE display value.
4
