FUSE SPECIFICATION CHART
Power Distribution Box
WARNINGS
Always disconnect the battery beforeservicing high current fuses.
To reduce risk of electrical shock,always replace the cover to thepower distribution box beforereconnecting the battery or refilling fluidreservoirs.
The power distribution box is located inthe engine compartment. It hashigh-current fuses that protect yourvehicle's main electrical systems fromoverloads.
If you disconnect and reconnect thebattery, you will need to reset somefeatures. See Changing the 12V Battery(page 245).
Protected componentsFuse amp ratingFuse or relay number
Blower motorRelay1
Not used—2
Urea heaters (diesel engine)Relay3
Not used—4
Heated mirrorsRelay5Rear window defroster
Not used—6
Heated mirrors50A*7Rear window defroster
Passenger seat30A*8
Driver seat30A*9
223
Super Duty (TFA) Canada/United States of America, enUSA, First Printing
FusesE163101
Fuel Consumption........................................147Calculating Fuel Economy..............................148Filling the Tank.....................................................147Fuel Filter........................................................244Fuel Quality.....................................................145Choosing the Right Fuel...................................145Choosing the Right Fuel With a Flex FuelVehicle (If Equipped)...................................145Diesel Engine........................................................145Octane Recommendations............................145Fuel Shutoff....................................................213Fuses.................................................................223Fuse Specification Chart...........................223Passenger Compartment FusePanel..................................................................228Power Distribution Box....................................223
G
Garage Door OpenerSee: Universal Garage Door Opener............129Gauges...............................................................82Engine Coolant Temperature Gauge............83Engine Oil Pressure Gauge...............................83Fuel Gauge..............................................................83Information Display.............................................84Transmission Fluid TemperatureGauge..................................................................83General Information on RadioFrequencies...................................................47General Maintenance Information.......453Multi-point Inspection.....................................455Owner Checks and Services..........................454Protecting Your Investment...........................453Why Maintain Your Vehicle?.........................453Why Maintain Your Vehicle at YourDealership?.....................................................453Getting Assistance Outside the U.S. andCanada.........................................................220Getting the Services You Need................217Away From Home...............................................217Global Opening................................................77Opening the Windows........................................77
H
HandbrakeSee: Parking Brake..............................................170
Hazard Warning Flashers...........................213HDCSee: Using Hill Descent Control.....................177Head Restraints..............................................117Adjusting the Head Restraint..........................118Heated Seats..................................................124Rear Heated Seats ............................................124Heated Steering Wheel...............................68Heated Windows and Mirrors...................115Heated Exterior Mirror........................................115Heated Rear Window.........................................115HeatingSee: Climate Control..........................................110Hill Start Assist..............................................170Switching the System On and Off.................171Using Hill Start Assist........................................170Hints on Controlling the InteriorClimate...........................................................112Cooling the Interior Quickly..............................114General Hints.........................................................112Heating the Interior Quickly.............................113Recommended Settings for Cooling ...........114Recommended Settings for Heating...........114Side Window Defogging in ColdWeather..............................................................115Hints on Driving With Anti-LockBrakes............................................................169Hood LockSee: Opening and Closing the Hood...........232
I
Ignition Switch...............................................140In California (U.S. Only).............................218Information Display Control.......................67Type 1.........................................................................67Type 2.......................................................................68Information Displays....................................89General Information...........................................89Information.....................................................418911 Assist...............................................................425Alerts......................................................................424Calendar................................................................424Sirius Travel Link.................................................423SYNC Services (If Equipped, United StatesOnly)...................................................................419Vehicle Health Report (If Equipped, USOnly)..................................................................427
498
Super Duty (TFA) Canada/United States of America, enUSA, First Printing
Index
