2016 DODGE VIPER SRT remote start

11. Once the engine is started, remove the jumper cablesin the reverse sequence:
Disconnecting The Jumper Cables
1. Disconnect the negative (-)end of the jumper cable
from the remote negative (-)post of the vehicle with
the discharged battery.
2. Disconnect the opposite end of the negative (-)jumper
cable from the negative (-)post of the booster battery.
3. Disconnect the positive (+)end of the jumper cable
from the positive (+)post of the booster battery.
4. Disconnect the opposite end of the positive (+)jumper
cable from the remote positive (+)post of the vehicle
with the discharged battery.
If frequent jump-starting is required to start your vehicle
you should have the battery and charging system in-
spected at your authorized dealer.CAUTION!
Accessories plugged into the vehicle power outlets
draw power from the vehicle’s battery, even when not
in use (i.e., cellular devices, etc.). Eventually, if
plugged in long enough without engine operation,
the vehicle’s battery will discharge sufficiently to
degrade battery life and/or prevent the engine from
starting.
FREEING A STUCK VEHICLE
If your vehicle becomes stuck in mud, sand, or snow, it
can often be moved using a rocking motion. Turn your
steering wheel right and left to clear the area around the
front wheels. Then shift back and forth between 1st gear
and REVERSE, while gently pushing the accelerator. Use
the least amount of pressure to maintain the rocking
motion, without spinning the wheels, or racing the
engine.
6
WHAT TO DO IN EMERGENCIES 331

ENGINE COMPARTMENT — 8.4L
1 — Washer Fluid Reservoir6 — Brake/Clutch Fluid Reservoir
2 — Coolant Pressure Cap 7 — Engine Oil Fill
3 — Engine Oil Dipstick 8 — Power Steering Fluid Reservoir
4 — Power Distribution Center 9 — Air Cleaner Filter
5 — Remote Jump Start Positive Battery Post
7
MAINTAINING YOUR VEHICLE 335

Maintenance-Free Battery
The top of the maintenance-free battery is vented, and
must be replaced with a vented battery.
The battery is located underneath an access panel inside
the rear compartment on the left side of the vehicle. A
remote battery terminal is located in the engine compart-
ment for jump-starting. Refer to “Jump-Starting Proce-
dures” in “What To Do In Emergencies” for further
information.
To gain access to the battery, remove the floor portion of
the rear compartment carpet.
Battery Location
1 — Positive Battery Post
2 — Negative Battery Post
344 MAINTAINING YOUR VEHICLE

Anti-Lock Warning Light....................267
Appearance Care ........................ .362
Auto Down Power Windows ..................30
Automatic Door Locks ....................28, 29
Automatic Headlights ..................... .109
Auto Unlock, Doors ........................29
Auto Up Power Windows ....................31
Auxiliary Electrical Outlet (Power Outlet) ........135
Auxiliary Power Outlet .....................135
Battery ............................ .157, 344
Charging System Light ...................157
Emergency Starting ..................... .327
Jump Starting ......................... .327
Keyless Transmitter Replacement (RKE) ........24
Location ............................. .344
Remote Battery Replacement ................24
Saving Feature (Protection) ................345
Storing Vehicle ........................ .345Transmitter Battery Replacement
.............24
Belts, Seat ...............................88
Body Mechanism Lubrication .................348
B-Pillar Location ......................... .278
Brake Control System, Electronic ..............264
Brake, Parking .......................... .261
Brake System ........................ .263, 358
Anti-Lock (ABS) .....................263, 265
Fluid Check ....................... .358, 387
Master Cylinder ....................... .358
Warning Light ........................ .154
Break-In Recommendations, New Vehicle ........263
Brightness, Interior Lights ...................113
Bulb Replacement ........................ .383
Bulbs, Light .......................... .89, 382
Camera, Rear ........................... .124
Capacities, Antifreeze (Engine Coolant) ..........384
Capacities, Fluid ......................... .384
10
INDEX 409
