(C) Injecting Tire Service Kit Sealant Into The
Deflated Tire:
•Always start the engine before turning ON the Tire
Service Kit.
NOTE: Manual transmission vehicles must have the
parking brake engaged and the shift lever in NEUTRAL.
• After pushing the Power Button (4), the sealant (white
fluid) will flow from the Sealant Bottle (1) through the
Sealant Hose (6) and into the tire.
NOTE: Sealant may leak out through the puncture in the
tire.
If the sealant (white fluid) does not flow within0–10
seconds through the Sealant Hose (6):
1. Push the Power Button (4) to turn Off the Tire Service Kit. Disconnect the Sealant Hose (6) from the valve
stem. Make sure the valve stem is free of debris. Reconnect the Sealant Hose (6) to the valve stem.
Check that the Mode Select Knob (5) is in the Sealant
Mode position and not Air Mode. Push the Power
Button (4) to turn On the Tire Service Kit.
2. Connect the Power Plug (8) to a different 12 Volt power outlet in your vehicle or another vehicle, if
available. Make sure the engine is running before
turning ON the Tire Service Kit.
3. The Sealant Bottle (1) may be empty due to previous use. Call for assistance.
NOTE: If the Mode Select Knob (5) is on Air Mode and
the pump is operating, air will dispense from the Air
Pump Hose (7) only, not the Sealant Hose (6).
6
WHAT TO DO IN EMERGENCIES 575

Besides those maintenance items specified in the fixed
“Maintenance Schedule”, there are other components
which may require servicing or replacement in the future.
CAUTION!
•Failure to properly maintain your vehicle or per-
form repairs and service when necessary could
result in more costly repairs, damage to other
components or negatively impact vehicle perfor-
mance. Immediately have potential malfunctions
examined by an authorized dealer or qualified
repair center.
• Your vehicle has been built with improved fluids
that protect the performance and durability of your
vehicle and also allow extended maintenance inter-
vals. Do not use chemical flushes in these compo-
nents as the chemicals can damage your engine,
(Continued)
CAUTION! (Continued)
transmission, power steering or air conditioning.
Such damage is not covered by the New Vehicle
Limited Warranty. If a flush is needed because of
component malfunction, use only the specified
fluid for the flushing procedure.
Engine Oil
Checking Oil Level
To assure proper engine lubrication, the engine oil must
be maintained at the correct level. Check the oil level at
regular intervals, such as every fuel stop. The best time to
check the engine oil level is about five minutes after a
fully warmed engine is shut OFF.
Checking the oil while the vehicle is on level ground will
improve the accuracy of the oil level readings. Maintain
the oil level between the MIN and MAX markings on the
618 MAINTAINING YOUR VEHICLE

CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New
Vehicle Limited Warranty.
Fluid Level Check
The fluid level is preset at the factory and does not
require adjustment under normal operating conditions.
Routine fluid level checks are not required, therefore the
transmission filler tube is capped and no dipstick is
provided. Your authorized dealer can check your trans-
mission fluid level using a special service dipstick. If you
notice fluid leakage or transmission malfunction, visit
your authorized dealer immediately to have the trans-
mission fluid level checked. Operating the vehicle with
an improper fluid level can cause severe transmission
damage.
CAUTION!
If a transmission fluid leak occurs, visit your autho-
rized dealer immediately. Severe transmission dam-
age may occur. Your authorized dealer has the proper
tools to adjust the fluid level accurately.
Fluid And Filter Changes
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
In addition, change the fluid and filter if the fluid
becomes contaminated (with water, etc.), or if the trans-
mission is disassembled for any reason.
7
MAINTAINING YOUR VEHICLE 639

Anti-Lock Warning Light....................331
Appearance Care ........................ .640
Ashtray ............................... .276
Assistance Towing ........................ .160
Assist, Hill Start ......................... .492
Auto Down Power Windows ..................41
Automatic Dimming Mirror ..................132
Automatic Door Locks ......................37
Automatic Headlights ..................... .223
Automatic Temperature Control (ATC) ..........448
Automatic Transmission ..............468, 638, 639
Adding Fluid ......................... .639
Fluid And Filter Changes ..................639
Fluid Change ......................... .639
Fluid Level Check ...................... .639
Fluid Type ........................ .638, 663
Gear Ranges .......................... .473
Special Additives ...................... .638
Torque Converter ...................... .480Auto Up Power Windows
....................41
Battery ............................ .319, 624
Charging System Light ...................319
Jump Starting ......................... .600
Keyless Transmitter Replacement (RKE) ........28
Saving Feature (Protection) ................229
Belts, Seat .............................. .120
Body Mechanism Lubrication .................627
B-Pillar Location ......................... .507
Brake Assist System ...................... .491
Brake Control System, Electronic ..............488
Brake Fluid ............................ .663
Brake System ........................ .488, 635
Anti-Lock (ABS) ....................... .488
Fluid Check .......................... .636
Parking ............................. .485
Warning Light ........................ .317
Brake/T
ransmission Interlock .................470
10
INDEX 685

Exterior Lights....................... .122, 655
Filters Air Cleaner .......................... .621
Air Conditioning ....................459, 626
Engine Oil ........................ .621, 661
Engine Oil Disposal .....................621
Flashers Hazard Warning ....................... .567
Turn Signal ..................122, 335, 657, 658
Flash-To-Pass ........................... .229
Flexible Fuel Vehicles Cruising Range ........................ .543
Engine Oil ........................... .542
Fuel Requirements ...................540, 541
Maintenance .......................... .543
Replacement Parts ...................... .543
Starting ............................. .542
Flooded Engine Starting ....................466 Floor Console
........................... .283
Fluid Capacities ......................... .660
Fluid Leaks ............................ .123
Fluid Level Checks Automatic Transmission ..................639
Brake ............................... .636
Cooling System ........................ .630
Power Steering ........................ .484
Fluids, Lubricants And Genuine Parts ...........661
Fog Lights .......................... .225, 658
Fog Light Service ........................ .658
Fold in Floor (Stow N Go) Seating.............197
Freeing A Stuck Vehicle .....................605
Fuel .................................. .536
Adding ............................. .543
Additives ............................ .538
Clean Air ............................ .536
Conserving ........................... .346
Economy

Mode ....................... .471
