2016 DODGE DART service indicator

persists, the message will appear the next time the
vehicle is started. This might indicate a damaged cap. If
the problem is detected twice in a row, the system will
turn on the MIL. Resolving the problem will turn the MIL
light off.
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.For states that require an Inspection and Mainte-
nance (I/M), this check verifies the “Malfunction
Indicator Light (MIL)” is functioning and is not
on when the engine is running, and that the OBD II
system is ready for testing. Normally, the OBD II system will be ready. The OBD II
system may
notbe ready if your vehicle was recently
serviced, recently had a dead battery or a battery replace-
ment. If the OBD II system should be determined not
ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition actuated test, which
you can use prior to going to the test station. To check if
your vehicle’s OBD II system is ready, you must do the
following:
1. Cycle the ignition switch to the ON position, but do not crank or start the engine.
NOTE: If you crank or start the engine, you will have to
start this test over.
2. As soon as you cycle the ignition switch to the ON position, you will see the Malfunction Indicator Light
(MIL) symbol come on as part of a normal bulb check.
7
MAINTAINING YOUR VEHICLE 575

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that ser-
vice is required for your vehicle. Operating conditions
such as frequent short-trips, trailer tow, extremely hot or
cold ambient temperatures, and E85 fuel usage will
influence when the “Change Oil” message is displayed.
Severe Operating Conditions can cause the change oil
message to illuminate as early as 3,500 miles (5,600 km)
since last reset. Have your vehicle serviced as soon as
possible, within the next 500 miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone otherthan your authorized dealer, the message can be reset by
referring to the steps described under “Electronic Vehicle
Information Center (EVIC)/Driver Information Display
(DID)” in “Understanding Your Instrument Panel” for
further information.
NOTE:
Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km), twelve months or
350 hours of engine run time, whichever comes first. The
350 hours of engine run or idle time is generally only a
concern for fleet customers
Severe Duty All Models
Change Engine Oil at 4,000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment or is
operated predominately at idle or only very low engine
RPM’s. This type of vehicle use is considered Severe Duty.
628 MAINTENANCE SCHEDULES

Light Bulbs..........................113,616
Lights ..............................113,234
AirBag ........................84, 110, 307
Automatic Headlights ....................235
Brake Assist Warning ....................466
Brake Warning ........................ .308
Bulb Replacement ...................... .618
Cruise .............................. .327
Daytime Running ...................... .237
Dimmer Switch, Headlight .............239, 240
Engine Temperature Warning ...............311
Exterior ..............................113
Fog ................................ .238
Hazard Warning Flasher ..................531
Headlights ........................... .234
Headlights On Reminder ..................238
Headlights On With Wipers .............235, 246
Headlight Switch ...................... .234
High Beam ........................... .240High Beam/Low Beam Select
...............240
Illuminated Entry ........................23
Instrument Cluster ..................... .234
Intensity Control ....................... .241
Interior ............................. .241
License ............................. .620
Lights On Reminder .....................238
Low Fuel ............................ .323
Malfunction Indicator (Check Engine) .........316
Parade Mode (Daytime Brightness) ...........243
Park ............................... .325
Passing ............................. .240
Reading .......................... .240, 269
Seat Belt Reminder ..................... .306
Security Alarm ........................ .310
Service .............................. .618
Tire Pressure Monitoring (TPMS) ............319
Traction Control ....................... .466
T
urn Signal .....................113, 239, 326
656 INDEX

Vanity Mirror......................... .124
Warning (Instrument Cluster Description) . . .311, 326
Loading Vehicle ...................... .512, 514
Capacities ........................... .514
Tires ............................... .476
Locks ..................................33
Automatic Door .........................35
Auto Unlock ...........................36
Child Protection .........................36
Door .................................33
Power Door ............................35
Lubrication, Body ........................ .587
Lug Nuts .............................. .532
Maintenance Free Battery ....................583
Maintenance Procedures ....................577
Maintenance Schedule ..................... .628
Malfunction Indicator Light (Check Engine) . . .316, 575
Manual, Service ......................... .642Manual Transmission
...................421, 601
Fluid Level Check ...................... .601
Frequency Of Fluid Change ................601
Lubricant Selection ..................... .601
Shift Speeds .......................... .422
Master Cylinder (Brakes) ....................597
Methanol .............................. .506
Mini-Trip Computer ...................... .334
Mirrors ............................... .121
Automatic Dimming .....................121
Electric Powered ....................... .123
Electric Remote ........................ .123
Exterior Folding ....................... .123
Heated .............................. .124
Outside ............................. .122
Rearview ............................ .121
Vanity .............................. .124
Modifications/Alterations, Vehicle ...............7
Monitor, Tire Pressure System ................495
10
INDEX 657

Pressure Warning Light...................319
Quality Grading ....................... .643
Radial .............................. .484
Replacement .......................... .491
Rotation ............................. .494
Safety ........................... .469, 481
Sizes ............................... .471
Snow Tires ........................... .486
Spare Tire ...................487, 488, 489, 544
Spinning ............................ .489
Tread Wear Indicators ....................490
Tire Safety Information .....................469
Tire Service Kit .......534, 535, 538, 539, 541, 542, 543
Tongue Weight/Trailer Weight ................518
To Open Hood .......................... .231
Towing ............................... .514
24-Hour Towing Assistance ................149
Disabled Vehicle ....................... .563
Guide .............................. .517Recreational
.......................... .527
Weight .............................. .517
Towing Assistance ........................ .149
Towing Vehicle Behind A Motorhome ...........527
Traction ............................... .448
Traction Control ......................... .462
Trailer Towing .......................... .514
Cooling System Tips .....................526
Hitches ............................. .517
Minimum Requirements ..................519
Trailer And Tongue Weight ................518
Wiring .............................. .523
Trailer Towing Guide ...................... .517
Trailer Weight ........................... .517
Transmission Automatic ........................ .425,
599
Filter ............................... .601
Fluid ............................... .625
Maintenance .......................... .599
664 INDEX

Manual............................. .421
Transmitter Battery Service (Remote Keyless Entry) ................................27
Transmitter, Garage Door Opener (HomeLink) .....270
Transmitter Programming (Remote Keyless Entry) . . .26
Transmitter, Remote Keyless Entry (RKE) .........23
Transporting Pets ........................ .107
Tread Wear Indicators ..................... .490
Trunk Lid (Deck Lid) .....................47, 48
Trunk Release, Emergency ....................48
Trunk Release Remote Control .................47
Turn Signals ......................... .239, 326
UCI Connector .......................... .385
Uconnect Advanced Phone Connectivity ...........153, 189
Operation ............................ .168
Phone Call Features .....................180
Phone Features .....................147, 185 Things You Should Know About Your Uconnect
Phone
.............................. .190
Uconnect Settings ........................25
Uconnect Settings ...................... .355
Uconnect 130 With Satellite Radio Playing MP3 Files ...................... .379
Uconnect (Hands-Free Phone) ................135
Uconnect Phone ....................165, 169, 170
Answer Or Ignore An Incoming Call — No Call
Currently In Progress ....................183
Bluetooth Communication Link .............195
Call By Saying A Phonebook Name ..........181
Call Continuation ...................... .185
Call Controls ......................... .181
Cancel Command ...................... .170
Connecting To A Particular Mobile Phone Or
Audio Device After Pairing ................174
Connect Or Disconnect Link Between The
Uconnect Phone And Mobile Phone ..........189
10
INDEX 665
