2016 DODGE DART jump start

CAUTION!
Failure to follow these procedures could result in
damage to the charging system of the booster vehicle
or the discharged vehicle.
Connecting The Jumper Cables
1. Connect the positive (+)end of the jumper cable to the
positive (+)post of the discharged vehicle.
2. Connect the opposite end of the positive (+)jumper
cable to the positive (+)post of the booster battery.
3. Connect the negative (-)end of the jumper cable to the
negative (-)post of the booster battery.
4. Connect the opposite end of the negative (-)jumper
cable to a good engine ground (exposed metal part of
the discharged vehicle’s engine) away from the battery
and the fuel injection system.
WARNING!
Do not connect the jumper cable to the negative (-) post
of the discharged battery. The resulting electrical spark
could cause the battery to explode and could result in
serious injury. Only use the specific ground point, do
not use any other exposed metal parts.
5. Start the engine in the vehicle that has the booster battery, let the engine idle a few minutes, and then
start the engine in the vehicle with the discharged
battery.
6. Once the engine is started, remove the jumper cables in the reverse sequence:
Disconnecting The Jumper Cables
1. Disconnect the negative (-)end of the jumper cable
from the engine ground of the vehicle with the dis-
charged battery.
558 WHAT TO DO IN EMERGENCIES

2. Disconnect the opposite end of the negative(-)jumper
cable from the negative (-)post of the booster battery.
3. Disconnect the positive (+)end of the jumper cable
from the positive (+)post of the booster battery.
4. Disconnect the opposite end of the positive (+)jumper
cable from the positive (+)post of the vehicle with the
discharged battery.
If frequent jump starting is required to start your vehicle
you should have the battery and charging system in-
spected at your authorized dealer.
CAUTION!
Accessories plugged into the vehicle power outlets
draw power from the vehicle’s battery, even when not
in use (i.e., cellular devices, etc.). Eventually, if
plugged in long enough without engine operation,
(Continued)
CAUTION! (Continued)
the vehicle’s battery will discharge sufficiently to
degrade battery life and/or prevent the engine from
starting.
FREEING A STUCK VEHICLE
If your vehicle becomes stuck in mud, sand, or snow, it can
often be moved by a rocking motion. Turn your steering
wheel right and left to clear the area around the front
wheels. Then shift back and forth between DRIVE and
REVERSE (with automatic transmission) or 2nd Gear and
REVERSE (with manual transmission) while gently press-
ing the accelerator. Use the least amount of accelerator
pedal pressure that will maintain the rocking motion,
without spinning the wheels or racing the engine.
6
WHAT TO DO IN EMERGENCIES 559

Tires
Checking For Tire Wear
Once a month, check the tire inflation pressures and look
for unusual wear or damage. Rotate at the first sign of
irregular wear, even if it occurs before the oil indicator
system turns on.
Maintenance-Free Battery
Your vehicle is equipped with a maintenance-free battery.
You will never have to add water, nor is periodic main-
tenance required.
WARNING!
•Battery fluid is a corrosive acid solution and can
burn or even blind you. Do not allow battery fluid
to contact your eyes, skin, or clothing. Do not lean
over a battery when attaching clamps. If acid
(Continued)
WARNING! (Continued)
splashes in eyes or on skin, flush the area imme-
diately with large amounts of water. Refer to
“Jump-Starting Procedures” in “What To Do In
Emergencies” for further information.
• Battery gas is flammable and explosive. Keep
flame or sparks away from the battery. Do not use
a booster battery or any other booster source with
an output greater than 12 Volts. Do not allow cable
clamps to touch each other.
• Battery posts, terminals, and related accessories
contain lead and lead compounds. Wash hands
after handling.
• The battery in this vehicle has a vent hose that
should not be disconnected and should only be
replaced with a battery of the same type (vented).
7
MAINTAINING YOUR VEHICLE 583

DrivingThrough Flowing, Rising, Or Shallow Standing
Water ............................... .449
Electrical Power Outlets .....................282
Electric Rear Window Defrost .................294
Electric Remote Mirrors .....................123
Electronic Brake Control System ...............456
Anti-Lock Brake System ..................456
Traction Control System ...................462
Electronic Speed Control (Cruise Control) ........250
Electronic Stability Control (ESC) ..............463
Electronic Throttle Control Warning Light ........314
Electronic Vehicle Information Center (EVIC) . .266, 329
Emergency Brake ........................ .451
Emergency Deck Lid Release ..................48
Emergency, In Case Of Freeing Vehicle When Stuck ................559
Hazard Warning Flasher ..................531 Jacking
.............................. .544
Jump Starting ......................... .555
Overheating .......................... .531
Towing ............................. .563
Emergency Trunk Release ....................48
Emission Control System Maintenance ..........575
Engine ............................. .572, 573
Air Cleaner .......................... .582
Block Heater ......................... .420
Break-In Recommendations ................107
Checking Oil Level ..................... .578
Compartment ......................... .571
Cooling ............................. .591
Exhaust Gas Caution .................109, 509
Fuel Requirements ..................... .504
Jump Starting ......................... .555
Oil .......................... .578, 622, 623
Oil Filler Cap ................572, 573, 580, 581
Oil Filter ............................ .581
10
INDEX 651

Jack Location........................... .544
Jack Operation ....................... .544, 547
Jump Starting ........................... .555
Key Fob Arm The Alarm .........................20
Keyless Entry ...........................37
Lock The Doors ...................... .25, 35
Panic Alarm ........................ .22, 26
Programming Additional Key Fobs ...........26
Programming Additional Transmitters .........26
Remote Keyless Entry (RKE) ................23
Unlatch The Trunk .......................26
Unlock The Doors .......................24
Key-In Reminder ..........................16
Keyless Enter-N-Go .....................37, 416
Enter The Trunk ..................... .26, 37
KeyFob...............................37
Lock The Vehicle’s Doors .............25, 35, 37 Passive Entry
...........................37
Passive Entry Programming .................37
Remote Control .........................37
Unlock From The Driver’s Side ............24, 37
Unlock From The Passenger Side ..........24, 37
Keyless Entry System .......................23
Keyless Go ...............................13
Key, Programming .........................19
Key, Replacement ..........................19
Keys ...................................12
Key, Sentry (Immobilizer) ....................18
Lane Change And Turn Signals ...............239
Lane Change Assist ....................... .240
Lap/Shoulder Belts .........................52
Latches ................................113
Lead Free Gasoline ....................... .504
Leaks, Fluid .............................113
Life Of Tires ............................ .491
10
INDEX 655
