CAUTION!
Towing this vehicle in violation of the above require-
ments can cause severe transmission damage. Dam-
age from improper towing is not covered under the
New Vehicle Limited Warranty.
If the key fob is unavailable, or the vehicle’s battery is
discharged, refer to “Manual Park Release” in this section
for instructions on shifting the automatic transmission
out of PARK for towing.
Manual Transmission
The manufacturer recommends towing your vehicle with
all four wheels OFF the ground using a flatbed.
If flatbed equipment is not available, and the transmis-
sion is operable, the vehicle may be flat towed (with all
four wheels on the ground) under the following condi-
tions: •
The transmission must be in NEUTRAL.
• The towing distance must not exceed 30 miles (48 km).
• The towing speed must not exceed 30 mph (48 km/h).
If the transmission is not operable, then the only accept-
able method of towing is with a flatbed truck.
CAUTION!
Towing this vehicle in violation of the above require-
ments can cause severe engine and/or transmission
damage. Damage from improper towing is not cov-
ered under the New Vehicle Limited Warranty.6
WHAT TO DO IN EMERGENCIES 503

NOTE:Your vehicles exhaust system may be equipped
with an Electronic Exhaust Valve (EEV) system, if the
exhaust system is replaced with aftermarket products a
Malfunction Indicator Lamp (MIL) will illuminate.
Cooling System
WARNING!
• When working near the radiator cooling fan, dis-
connect the fan motor lead or place the ignition in
the LOCK position (OFF position for Keyless
Enter-N-Go). The fan is temperature controlled and
can start at any time the ignition switch is in the
ON position (RUN position for Keyless Enter-N-
Go).
• You or others can be badly burned by hot engine
coolant (antifreeze) or steam from your radiator. If
you see or hear steam coming from under the hood,
(Continued)
WARNING! (Continued)
do not open the hood until the radiator has had
time to cool. Never try to open a cooling system
pressure cap when the radiator is hot.
Coolant Checks
Check the engine coolant (antifreeze) protection every 12
months (before the onset of freezing weather, where
applicable). If the engine coolant (antifreeze) is dirty, the
system should be drained, flushed, and refilled with
fresh OAT coolant (conforming to MS.90032) by an
authorized dealer. Check the front of the A/C condenser
for any accumulation of bugs, leaves, etc. If dirty, clean by
gently spraying water from a garden hose vertically
down the face of the condenser.
Check the coolant recovery bottle and/or the super-
charger coolant recovery bottle (if equipped with the 6.2L
Supercharged engine) tubing for brittle rubber, cracking,
7
MAINTAINING YOUR VEHICLE 529

Exterior Bulbs
Bulb Number
Headlamp – High Intensity Discharge (HID) D3S (Serviced at Authorized Dealer) *
Halogen Headlamp HIR2LL
Front Park/Turn Lamp LED (Serviced at Authorized Dealer)
Front Fog Lamp H11LL
Front Side Marker LED (Serviced at Authorized Dealer)
Tail Lamp LED (Serviced at Authorized Dealer)
Stop/Turn Lamp LED (Serviced at Authorized Dealer)
Rear Side Marker LED (Serviced at Authorized Dealer)
Backup Lamp LED (Serviced at Authorized Dealer)
Center High-Mount Stop Lamp (CHMSL) LED (Serviced at Authorized Dealer)
License LED (Serviced at Authorized Dealer)
* The headlamps are a type of high-voltage discharge
tube. High voltage can remain in the circuit even with the
headlamp switch off and the key removed. Because of this, you should not attempt to service a headlamp bulb
yourself. If a headlamp bulb fails, take your vehicle to an
authorized dealer for service.
7
MAINTAINING YOUR VEHICLE 561

3. Remove one fastener on the lower air box to removeand access the rear of the headlamp assembly.
4. Reach behind the passenger headlamp assembly.
5. Remove the headlamp cover.
6. Turn the headlamp access cap counterclockwise to remove.
7. Remove bulb by turn it counter clockwise and discon- nect.
8. Install new bulb by turning it clockwise and reconnect.
9. Reinstall headlamp access cap by turning it clockwise and then reinstall headlamp cover.
10. Reinstall engine air cleaner assembly.Low Beam Headlamp, High Beam Headlamp, and
Park/Turn Lamp — Models With High Intensity
Discharge (HID) Headlamps — If Equipped
HID Headlamps
The headlamps are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlamp switch off and the key removed. Because of
this, you should not attempt to service a headlamp bulb
yourself. If a headlamp bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high voltage occurs at the bulb sockets of
HID headlamps when the headlamp switch is turned
ON. It may cause serious electrical shock or electro-
cution if not serviced properly. See your authorized
dealer for service.
7
MAINTAINING YOUR VEHICLE 563

Alarm (Security Alarm)..................19, 235
Alarm System (Security Alarm) ................19
Alterations/Modifications, Vehicle ...............7
Antifreeze (Engine Coolant) ...........530, 565, 566
Disposal ............................. .533
Anti-Lock Brake System (ABS) ................422
Anti-Lock Warning Light ....................250
Appearance Care ........................ .540
Arming System (Security Alarm) ...............19
Assist, Hill Start ......................... .425
Auto Down Power Windows ..................40
Automatic Door Locks ......................33
Automatic Headlights ..................... .139
Automatic High Beams .....................140
Automatic Temperature Control (ATC) .......338, 345
Automatic Transmission ..............390, 538, 540
Adding Fluid ...................540, 567, 569
Autostick ............................ .397
Fluid And Filter Changes ..................540 Fluid Change
......................... .540
Fluid Level Check ...................... .539
Fluid Type ........................ .567, 569
Special Additives ...................... .539
Automatic Transmission Limp Home Mode .......396
Autostick .............................. .397
Auto Unlock, Doors ........................33
Axle Fluid .......................... .567, 569
Axle Lubrication ..................... .567, 569
Battery ............................ .237, 520
Charging System Light ...................237
Keyless Transmitter Replacement (RKE) ........25
Location ............................. .520
Belts, Seat ...............................96
Body Mechanism Lubrication .................525
B-Pillar Location ......................... .442
Brake Assist System ...................... .424
Brake Control System, Electronic ..............421
10
INDEX 593

Customer Programmable Features.............278
Data Recorder, Event .......................70
Daytime Brightness, Interior Lights .............146
Daytime Running Lights ....................142
Dealer Service ........................... .513
Deck Lid, Emergency Release .................42
Deck Lid, Power Release .....................41
Defroster, Rear Window .....................218
Defroster, Windshield .......................96
Delay (Intermittent) Wipers ..................147
Diagnostic System, Onboard .................510
Dimmer Switch, Headlight ...................144
Dipsticks Oil (Engine) .......................... .515
Disabled Vehicle Towing ..............501, 502, 503
Disposal Antifreeze (Engine Coolant) ................533
Door Ajar .............................. .241Door Ajar Light
......................... .241
Door Locks Door Locks ......................... .23, 31
KeyFob...............................31
Remote ...............................31
Remote Keyless Entry (RKE) ................31
Door Locks, Automatic ......................33
Door Opener, Garage ...................... .199
Drive Modes ........................... .400
Driver Information Display DID ............................ .259, 262
Instrument Cluster Display .............259, 262
Driving Through Flowing, Rising, Or Shallow Standing
Water ............................... .413
Electrical Power Outlets .....................211
Electric Remote Mirrors .....................113
Electronic Brake Control System ...............421
596 INDEX

Time Delay........................... .141
Washers ............................. .526
Headlight Washers ....................... .526
Head Restraints ......................... .133
Head Rests ............................. .133
Heated Mirrors ...........................113
Heater, Engine Block ...................... .382
High Beam/Low Beam Select (Dimmer) Switch . . . .144
Hill Start Assist .......................... .425
HomeLink (Garage Door Opener) ..............199
Hood Release ........................... .136
Ignition Key..................................12
Illuminated Entry ..........................21
Immobilizer (Sentry Key) ....................16
Information Center, Vehicle ..................257
Inside Rearview Mirror .....................105
Instrument Cluster ...........225, 228, 236, 238, 254 Instrument Panel And Controls
...............224
Instrument Panel Lens Cleaning ...............546
Interior Appearance Care ....................544
Interior Lights .......................... .144
Intermittent Wipers (Delay Wipers) .............147
Introduction ..............................4
iPod Control ............................ .333
iPod/USB/MP3 Control ....................333
Bluetooth Streaming Audio ................333
Jump Starting .....................492, 493, 494
Key Fob Arm The Alarm .........................19
Lock The Doors .........................23
Panic Alarm ............................24
Programming Additional Key Fobs .........18, 25
Programming Additional Transmitters .......18, 25
Remote Keyless Entry (RKE) ................22
600 INDEX

Unlatch The Trunk.......................24
Unlock The Doors .......................23
Key-In Reminder ..........................14
Keyless Enter-N-Go .....................34, 377
Enter The Trunk .........................24
Lock The Vehicle’s Doors ...............23, 289
Passive Entry Programming ................289
Unlock From The Driver’s Side ..............23
Unlock From The Passenger Side .............23
Keyless Entry System .......................22
Keyless Go ...............................12
Key, Replacement ..........................17
Keys ...................................12
Key, Sentry (Immobilizer) ....................16
Lane Change And Turn Signals ...............143
Lane Change Assist ....................... .143
Lap History ............................ .268
SRT ................................ .268Lap/Shoulder Belts
.........................47
Lap Timer ............................. .267
SRT ................................ .267
Latches .................................98
Hood ............................... .136
Lead Free Gasoline ....................... .465
Leaks, Fluid ..............................98
Life Of Tires ............................ .454
Light Bulbs .......................... .98, 560
Lights .............................. .98, 138
AirBag .........................67, 96, 232
Automatic Headlights ....................139
Brake Assist Warning ....................432
Brake Warning ..................... .233, 421
Bulb Replacement ...................... .562
Center Mounted Stop ....................564
Courtesy/Reading ...................144, 199
Cruise ........................... .255, 256
Daytime Running ...................... .142
10
INDEX 601
