2016 DACIA DUSTER fog light bulb

JauneNoir Noir texte
5.1
ENG_UD39331_8
Sommaire 5 (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
Section 5: Practical advice
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.2
Puncture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.3
Tyre inflation kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5
Wheel trim/Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.9
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.10
Tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.12
Changing bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.16
Front lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.16
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.17
Rear lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.18
Side indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.23
Interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.24
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.28
Battery: troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.36
Radio frequency remote control: batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.38
Wiper blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.39
Towing: breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.40
Fitting a radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.43
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.44
Operating faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.45

JauneNoir Noir texte
5.17
ENG_UD38548_2
Projecteurs antibrouillard : remplacement des lampes (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
Additional lights
If you wish to fit fog lights to your ve-
hicle, please see an authorised dealer.
FOG LIGHTS: changing bulbs
Front fog lights 1
Consult an approved dealer.
Bulb type: H16
or depending on vehicle, H11.
Any operation on (or modi-
fication to) the electrical
system must be performed
by an approved Dealer
since an incorrect connection might
damage the electrical equipment
(harness, components and in partic-
ular the alternator). In addition, your
Dealer has all the parts required for
fitting these units.
The engine may be hot
during operations in close
proximity. In addition, the
engine cooling fan may
come on at any moment.
Risk of injury.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
1
To comply with local legislation, or
as a precaution, you can obtain an
emergency kit containing a set of
spare bulbs and fuses from an ap-
proved Dealer.
Rear fog lights 2(depending on vehicle)
Consult an approved dealer.
Bulb type: P21W.
2

JauneNoir Noir texte
5.20
ENG_UD39296_4
Feux arrière : remplacement des lampes (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
REAR LIGHTS: replacing the bulbs(3/5)
Open the luggage compartment lid and
unscrew the nuts 10, then release the
light unit 11 by pulling it out.
Unlock the clips 12 to remove the bulb
holders 13.
14 Side light and brake light
Pear-shaped, bayonet type bulb with
two P 21/5 W filaments.
15 Direction indicator lights
Pear-shaped, bayonet type P 21 W
or PY 21 W bulb (depending on ve-
hicle).16 Reversing light
Pear-shaped bayonet bulb P 21 W
or,
Rear fog light
(depending on vehicle)
Pear-shaped, bayonet type P 21 W
bulb.
Refitting
To refit, proceed in the reverse order,
taking care not to damage the wiring.
10
111212
13
14
15
16
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
13

JauneNoir Noir texte
7.2
FRA_UD39333_8
Index (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_7
ALPHABETICAL INDEX (2/5)
engine
technical specifications .................................................. 6.6
engine coolant ..................................................................... 4.9
engine immobiliser (switch) ................................................. 2.2
engine oil ............................................................................. 4.4
engine oil grade .........................................................4.5 → 4.7
engine oil level ...........................................................4.5 → 4.7
engine specifications ........................................................... 6.6
engine standby ..........................................................2.7 → 2.9
environment ....................................................................... 2.21
ESC: electronic stability control .............................2.34 → 2.37
F
4 wheel drive (4WD) ..............................................2.30 → 2.33
faults
operating faults ................................................5.45 → 5.49
filter .................................................................................... 4.11
air filter ......................................................................... 4.11
diesel filter ........................................................... 1.72, 4.11
passenger compartment filter ...................................... 4.11
fitting a radio ...................................................................... 5.43
fittings ....................................................................3.16 → 3.19
fog lights ............................................................................ 1.62
front passenger air bag deactivation ................................. 1.34
front seat adjustment .............................................. 1.12 – 1.13
front seats
adjustment ....................................................... 1.11 → 1.13
fuel
advice on fuel economy ...................................2.15 → 2.19
filling ............................................................................. 1.68
grade ..................................................................... 1.67, 6.6
fuel economy .........................................................2.15 → 2.19
fuel filler cap ...................................................................... 1.67
fuel grade........................................................................... 1.67
fuel priming bulb ................................................................ 1.72
fuel tank .................................................................1.67 → 1.72fuel tank capacity ............................................................... 1.67
fuses ......................................................................5.28 → 5.35
G
gear lever........................................................................... 2.29
glove box ........................................................................... 3.18
grab handle........................................................................ 3.13
H
handbrake.......................................................................... 2.29
hands-free telephone integrated control ............................ 3.29
hazard warning lights signal ................................... 1.59 – 1.60
headlight beam adjustment .................................... 1.63 – 1.64
headlight flashers ................................................... 1.59 – 1.60
headrest.................................................................... 1.11, 3.15
heating and air conditioning system ..........................3.2 → 3.7
heating system ..........................................................3.2 → 3.7
Hill Start Assist.......................................................2.34 → 2.37
horn ........................................................................ 1.59 – 1.60
hubcap tool .......................................................................... 5.2
I
ignition switch ...................................................................... 2.2
indicator lights.................................................................... 5.23
indicators ....................................................... 1.59 – 1.60, 5.16
indicators:
direction indicators ............................................ 1.59 – 1.60
instrument panel ...........................................1.42 → 1.50, 1.50
interior trim
maintenance ..................................................... 4.18 – 4.19
J
jack .................................................................. 5.2, 5.10 – 5.11
K
keys ............................................................................ 1.2 – 1.3
