2016 Citroen BERLINGO MULTISPACE ignition

62
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Screenwash and headlamp wash
Pull the stalk towards you, the wash-
wipe   is   accompanied   by   a   timed   sweep
of

  the   wipers.
The
  headlamp   wash   is   linked   with   the
wash-wipe, it is triggered if the dipped
headlamps

  are   on.
Turn
  the   ring   past   the   first
position:

  the   rear   screenwash
then the rear wiper operates
for

  a   fixed   time.
In winter, in the event of a
considerable
  amount   of   snow
or ice, switch on the heated
rear

  screen.   Once   the   screen   is
clear

,   remove   the   snow   or   ice   which
has

  accumulated   on   the   rear   wiper
blade.


Y
ou   can   then   operate   the   rear
windscreen

  wiper.
To top up the levels, refer to the
"Levels"
  section   of   chapter   7.
Special position of the
windscreen wipers
In the minute following switching off of the ignition, any action on the
stalk
  positions   the   wipers   against   the
windscreen

  uprights.
This action enables you to position
the
  wiper   blades   for   winter   parking,
cleaning

  or   replacement.
Refer to the "Changing a windscreen
wiper
  blade"   section   of   chapter   8.
To
  park   the   wipers   in   their   normal
position after this has been done,
switch

  on   the   ignition   and   move   the
stalk. T

urn   the   ring   to   the   first
position.
Rear wiperRear screenwash
Steering mounted controls

63
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
TRIP COMPUTER
A

few definitions
Range: displays the distance which
can  travelled   with   the   remaining   fuel
detected

  in   the   tank,   basd   on   the
average

  consumption   over   the   last   few
miles

  (kilometres).
This
  displayed   value   may   vary
significantly

  following   a   change   in   the
vehicle

  speed   or   the   relief   of   the   route.Current fuel consumption:
only
calculated and displayed above
20   mph   (30   km/h).
Average fuel consumption: this is the
average   fuel   consumption   since   the
last

  trip   computer   zero   reset.
Distance travelled: calculated since
the   last   trip   computer   zero   reset.
Distance remaining to the
destination: calculated with reference to
the   final   destination,   entered   by   the   user.
 If guidance is activated, the navigation


system   calculates   it   as   a   current   value.
Average speed: this is the average
speed calculated since the last trip
computer
  zero   reset   (ignition   on).
Each press of the button, located at
the

end

of

the

wiper

stalk,

displays

the

dif

ferent

trip

computer

information

in

turn,


depending

on

the

screen.
When the required trip is displayed,
press  the   control   for   more   than
two seconds. When
  the   range   falls   below   20   miles
(30

  km),   dashes   are   displayed.
After

fillin

g   with   at   least   10   litres   of   fuel,   the
range is recalculated and is displayed
when

  it   exceeds   60   miles   (100   km).
If, whilst driving, dashes are displayed
continuously in place of the digits,
contact   a   CITROËN   dealer.
The "vehicle" tab with the range,
current

fuel

consumption

and

the
 remaining

distance

to

run.
The "1" tab (trip 1) with the average
speed,

the

average

fuel

consumption

and the distance travelled in trip

"1".
The

"2"

tab

(trip

2)

with

the

same

information


for

a

2
nd trip.
Reset
Steering mounted controls
EaSE oF USE and CoMFoRT
4

66
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Changing the
programmed speedSwitching the system off
Operating fault Cancelling the programmed
speed setting
When the vehicle becomes stationary, after switching of
f the ignition, the
system
  no   longer   memorises   a   speed.
There

are

two

methods

of

memorising

a speed

higher

than

the

previous

one:
-
Place the dial in position
0 or switch
off the ignition to switch everything
off.
Good practice
Without using the accelerator
-

Press the
SET +   button.
A brief   press   increases   the   speed   by   1   mph   (km/h).
A maintained   press   increases   the   speed   in steps
  of   5   mph   (km/h).
Using the accelerator
-

Exceed
  the   memorised   speed   until
the speed required is reached,
-


Press the
SET + or SET -   button.
To
  memorise   a   speed   lower than the
previous
  one:
-

Press the
SET -   button.
a brief press decreases the speed by


1
  mph   (km/h).
A


maintained   press   decreases   the
speed

  in   steps   of   5   mph   (km/h).The
  programmed   speed   setting   is
cleared

  and   replaced   by   three   dashes.
Contact a CITR

o Ë n dealer or a
qualified
  workshop   to   have   the   system
checked.When

  changing   the   programmed
speed

  setting   by   means   of   a
maintained

  press,   pay   attention   as
the speed can increase or decrease
rapidly

.
d

o not use the cruise control on
slippery   roads   or   in   heavy   traffic.
In the event of a steep slope, the cruise
control   cannot   prevent   the   vehicle   from
exceeding

  the   programmed   speed
setting.
In any event, the cruise control cannot
replace the need to observe the speed
limits

  and   the   need   for   vigilance   on   the
part

  of   the   driver.
It   is   advisable   to   keep   your   feet   near
the

  pedals.
To   avoid   any   jamming   under   the
pedals:
-


ensure
  that   the   mat   and   its   fixings
on

  the   floor   are   positioned   correctly,
-
never
  place   one   mat   on   top   of  another
.
Steering mounted controls

 69
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Exceeding the programmed
speedSwitching the function offOperating fault
The programmed speed is cleared then
  replaced   by   three   dashes.
Contact a CITR
o Ë n dealer or a
qualified
  workshop   to   have   the   system
checked.
Flashing of the speed setting
Good practice
In  any   event,   the   speed   limiter   cannot
replace the need to observe speed
limits,

  nor   can   it   replace   the   need   for
vigilance

  on   the   part   of   the   driver.
Always
  pay   attention   to   the   profile
of the road and sharp acceleration
and

  stay   in   complete   control   of   your
vehicle.
T

o   avoid   any   jamming   under   the
pedals:
-


ensure
  that   the   mat   and   its   fixings
on

  the   floor   are   positioned   correctly,
-

never
  place   one   mat   on   top   of
another

.
Pressing the accelerator pedal in order
to

exceed

the

programmed

speed

will have no ef

fect unless you press
the pedal firmly beyond the point of
resistance.
The

limiter

is

deactivated

temporarily

and


the

programmed

speed

flashes
 accompanied

by

an

audible

signal.
To

return

to

the

limiter

function,

reduce

your


speed

to

below

the

programmed

speed.
The


speed

setting

flashes:
-

following forcing of the accelerator
point of resistance,
-


when


the

limiter

cannot

prevent

an

increase in the vehicle speed due
to


the

profile

of

the

road

or

on

a

steep descent,
-


in


the

event

of

sharp

acceleration. -

Place the switch in position

0 or
switch off the ignition to switch the
system

off.
The

last

programmed

speed

remains

in

the


memory.
Steering mounted controls
EASE OF USE and COMFORT
4

72
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Good practice
For maximum cooling or heating of the passenger  compartment,   it   is   possible
to exceed the value 15 by turning until
LO

  is   displayed   or   the   value   27   by
turning

  until   HI   is   displayed.
o

n entering the vehicle, the inside
temperature
  may   be   much   colder
(or
  warmer)   than   is   comfortable.
There

is no advantage in changing the value
displayed

  in   order   to   quickly   reach   the
level

  of   comfort   required.
The
  system
will

  use   its   maximum   performance   to
reach

  the   comfort   value   set.
DIGITAL AIR CONDITIONING
Automatic operation
AUTO comfort programme
This
  is   the   normal   air   conditioning
system

  operating   mode. Driver or passenger side comfort
value
The value indicated in the screen
corresponds
  to   a   level   of   comfort   and
not

  a   temperature   in   degrees   Celsius
or

  Fahrenheit.
Turn this control to the left
or to the right to decrease or
increase   the   value.
A
setting
around the value 21 provides
optimum

  comfort.   However,
depending

  on   your   requirements,   a
setting

  between   18   and   24   is   usual.
d

o not cover the sunshine sensor
located
  on   the   dashboard.
Press this button, the AUTO
symbol
  is   displayed.
The
  system   controls   the
distribution,

  the   flow   and   the
intake

  of   air   to   guarantee
comfort

  and   a   sufficient   circulation
of

  air   in   the   passenger   compartment
according

  to   the   comfort   value   set.   No
further

  action   on   your   part   is   required.Air
  flow   will   increase   gradually   when
the

engine is cold, to prevent excessive
distribution   of   cold   air.
For   your   comfort,   the   settings   are
stored when the ignition is switched of

f
and   are   reinstated   the   next   time   the
vehicle

  is   started.
The   automatic   function   will   no   longer
be

  maintained   if   you   change   a   setting
manually

  (AUTO   is   cleared).
SEPARATE SETTINGS FOR DRIVER AND
PASSENGER
Ventilation

104
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Automatic switching on/off
The front courtesy lamp comes on when the  key   is   removed   from   the   ignition,   when the

  vehicle   is   unlocked,   when   one   of   the
 front doors is opened and for location of


the
  vehicle   using   the   remote   control.
It goes off gradually after the ignition is
switched on and when the vehicle is
locked.Front seats: comes on when one of the front doors is
opened. These are switched on and of
f by
means   of   a   manual   switch,   with
the

  ignition   on.
Rear
  seats:   comes   on   when
one of the rear doors is
opened.
If

  the   doors   remain   open   for
a

  few   minutes,   the   courtesy
lamps

  go   off.
Permanently
  off.
Permanently

on,

ignition

on.
Front courtesy lamp
COURTESY
LAMPS
Rear courtesy lamp Front individual reading lamps
Practical information

111
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Adjusting electric door mirrors
- Move the control to the right or to
the left to select the corresponding
mirror.
-

Move the control in all four
directions

  to   adjust.
-

Return the control to the central
position.
MIRRORS
Heated mirrors
Adjusting manual door mirrors
Forced folding
If the mirror casing has come out of its initial location, with the vehicle
stationary  reposition   the   mirror   casing
manually

  or   use   the   electric   folding
control.Press the heated rear screen
button.
Move the lever in all four directions to
adjust.
When


the

vehicle

is

parked,

the

door

mirrors


can

be

folded

back

manually.
The

mirrors

are

not

equipped

with

automatic


heating.
Electric folding / unfolding
The mirrors can be folded or unfolded electrically
  from   the   inside,   with   the
vehicle

  parked   and   the   ignition   on:
-

Place the control in the central
position.
-


T
urn   the   control   downwards. The
  mirrors   that   have   electric   folding/
unfolding   can   be   heated.
EaSE oF USE and CoMFoRT
4
Mirrors and windows

11 3
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
ELECTRIC WINDOWS
Lower the window fully, then raise it, it
will  rise   in   steps   of   a   few   centimetres
each

  time   the   control   is   pressed.
Repeat the operation until the window
is

  fully   closed.
Continue to press the control for at
least one second after the window
closed
  position   has   been   reached.
The safety anti-pinch does not operate
during
  these   operations.
Safety anti-pinch
When the window rises and meets an obstacle,  it   stops   and   partially   lowers.
Manual mode
This mode is available depending  on   equipment;   it   is
identified

  by   this   symbol   on   the
control

  in   question.
Good practice
If the electric windows meet an obstacle  during   operation,   you   must
reverse

  the   movement   of   the   window.
T

o
do

this,

press

the

control

concerned.
When the driver operates the
passenger electric window controls,
they

  must   ensure   that   no   one   is
preventing correct closing of the
windows.
The

  driver   must   ensure   that   the
passengers use the electric windows
correctly

.
Be aware of children when operating
the
  windows.
Following
  several   consecutive   closing/
opening operations of the electric
window
  control,   a   protection   system
is triggered which only allows closing
of

  the   window.
After
  closing,   wait
approximately

  40   minutes.   Once   this
time

  has   elapsed,   the   control   becomes
operational

  again.
1.
d
river's side
2.

Passenger's side
Reinitialisation
Following reconnection of the battery,
or   in   the   event   of   a   malfunction,   the
safety

  anti-pinch   function   must   be
reinitialised. The electrical functions of the electric
windows
  are   deactivated:
-
approximately
  45   seconds   after   the
ignition is switched of

f,
-
after one of the front doors is
opened,

  if   the   ignition   is   off.
There

are

two

operating

modes:
Press or pull the control, without
passing

the

point

of

resistance.
The window stops when you release
the

control.
One-touch mode
Press or pull the control, beyond the
point
  of   resistance.
The window opens or closes fully when
the
  control   is   released.
Pressing or pulling the control again
stops
  the   movement   of   the   window.
EaSE oF USE and CoMFoRT
4
Mirrors and windows
