Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
Vehicle Care 363
passenger side front tire, passenger
side rear tire, and driver side rear.
See your dealer for service or to
purchase a relearn tool. A TPMS
relearn tool can also be purchased.
See Tire Pressure Monitor Sensor
Activation Tool at
www.gmtoolsandequipment.com or
call 1-800-GM TOOLS
(1-800-468-6657).
There are two minutes to match the
first tire/wheel position, and
five minutes overall to match all four
tire/wheel positions. If it takes
longer, the matching process stops
and must be restarted.
The TPMS sensor matching
process is:1. Set the parking brake.
2. Turn the ignition to ON/RUN with the engine off or place the
vehicle power mode in ON/
RUN/START.
3. Uplevel DIC Only: Make sure the Tire Pressure info page
option is turned on. The info
pages on the DIC can be
turned on and off through the Settings menu. See
Driver
Information Center (DIC) (Base
Level) 0153 orDriver
Information Center (DIC)
(Uplevel) 0155.
4. If the vehicle has an uplevel DIC, use the DIC controls on
the right side of the steering
wheel to scroll to the Tire
Pressure screen under the DIC
info page.
If the vehicle has a base level
DIC, use the trip odometer
reset stem to scroll to the Tire
Pressure screen.
5. If the vehicle has an uplevel DIC, press and hold the
V
(Set/Reset) button located in
the center of the DIC controls.
If the vehicle has a base level
DIC, press and hold the trip
odometer reset stem for about
five seconds. A message
asking if the process should
begin should appear. Select
yes and press the trip
odometer reset stem to confirm
the selection. The horn sounds twice to
signal the receiver is in relearn
mode and the TIRE
LEARNING ACTIVE message
displays on the DIC screen.
6. Start with the driver side front tire.
7. Place the relearn tool against the tire sidewall, near the valve
stem. Then press the button to
activate the TPMS sensor.
A horn chirp confirms that the
sensor identification code has
been matched to this tire and
wheel position.
8. Proceed to the passenger side front tire, and repeat the
procedure in Step 7.
9. Proceed to the passenger side rear tire, and repeat the
procedure in Step 7.
10. Proceed to the driver side rear tire, and repeat the procedure
in Step 7. The horn sounds two
times to indicate the sensor
identification code has been
matched to the driver side rear
tire, and the TPMS sensor

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
OnStar 431
OnStar
OnStar Overview
OnStar Overview . . . . . . . . . . . . . 431
OnStar Services
Emergency . . . . . . . . . . . . . . . . . . . 432
Security . . . . . . . . . . . . . . . . . . . . . . 432
Navigation . . . . . . . . . . . . . . . . . . . . 432
Connections . . . . . . . . . . . . . . . . . . 433
Diagnostics . . . . . . . . . . . . . . . . . . . 435
OnStar Additional Information
OnStar AdditionalInformation . . . . . . . . . . . . . . . . . . 435
OnStar Overview
=Voice Command Button
QBlue OnStar Button
>Emergency Button
This vehicle may be equipped with a
comprehensive, in-vehicle system
that can connect to an OnStar
Advisor for Emergency, Security,
Navigation, Connections, and
Diagnostics Services. OnStar
services may require a paid
subscription. OnStar requires the
vehicle battery and electrical
system, cellular service, and GPS
satellite signals to be available and
operating. OnStar acts as a link to
existing emergency service
providers. OnStar may collect
information about you and your
vehicle, including location
information. See OnStar ’s Terms &Conditions and Privacy Statement
for more details including system
limitations at www.onstar.com (U.S.)
or www.onstar.ca (Canada).
The OnStar system status light is
next to the OnStar buttons. If the
status light is:
.
Solid Green: System is ready.
. Flashing Green: On a call.
. Red: Indicates a problem.
. Off: System is off. PressQ
twice to speak with an OnStar
Advisor.
Press
Qor call 1-888-4ONSTAR
(1-888-466-7827) to speak to an
Advisor.
Press
=to:
. Make a call, end a call,
or answer an incoming call.
. Give OnStar Hands-Free Calling
voice commands.
. Give OnStar Turn-by-Turn
Navigation voice commands.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
434 OnStar
(no Internet connection, 3G,
4G, 4G LTE), and signal quality
(poor, good, excellent).
3. To change the SSID or password, press
Qor call
1-888-4ONSTAR to connect
with an Advisor.
OnStar RemoteLink
®Mobile App
(If Equipped)
Download the OnStar RemoteLink
mobile app to select Apple
®,
Android™, BlackBerry®,
or Windows®mobile devices.
OnStar Subscribers can access the
following services from a mobile
device:
. Remotely start/stop the vehicle,
if factory-equipped.
. Lock/unlock doors, if equipped
with automatic locks.
. Activate the horn and lamps.
. Check the vehicle’s fuel level, oil
life, or tire pressure,
if factory-equipped with the Tire
Pressure Monitor System.
. Send directions to the vehicle. .
Locate the vehicle on a map
(U.S. market only).
. Turn the vehicle's Wi-Fi hotspot
on/off, manage settings, and
monitor data consumption,
if equipped.
For OnStar RemoteLink information
and compatibility, see
www.onstar.com (U.S.) or
www.onstar.ca (Canada).
Remote Services
Contact an OnStar Advisor to
unlock the doors or sound the horn
and flash the lamps.
OnStar AtYourService
OnStar Advisors can provide
savings offers from restaurants and
retailers on your route, help locate
hotels, or book a room.
OnStar Hands-Free Calling
Make and receive calls with the
built-in wireless calling service.
Make a Call
1. Press
=. System responds:
“OnStar ready.” 2. Say
“Call.”System responds:
“Call. Please say the name or
number to call.”
3. Say the entire number without pausing, including a “1”and the
area code. System responds:
“OK, calling.”
Calling 911 Emergency
1. Press=. System responds:
“OnStar ready.”
2. Say “Call.”System responds:
“Call. Please say the name or
number to call.”
3. Say “911”without pausing.
System responds: “911.”
4. Say “Call.”System responds:
“OK, dialing 911.”
Retrieve My Number
1. Press=. System responds:
“OnStar ready.”
2. Say “My number.” System
responds: “Your OnStar
Hands-Free Calling number is,”
then says the number.

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
436 OnStar
.PressQto speak with an
Advisor.
OnStar services cannot work unless
the vehicle is in a place where
OnStar has an agreement with a
wireless service provider for service
in that area. The wireless service
provider must also have coverage,
network capacity, reception, and
technology compatible with OnStar
services. Service involving location
information about the vehicle cannot
work unless GPS signals are
available, unobstructed, and
compatible with the OnStar
hardware. OnStar services may not
work if the OnStar equipment is not
properly installed or it has not been
properly maintained. If equipment or
software is added, connected,
or modified, OnStar services may
not work. Other problems beyond
the control of OnStar —such as
hills, tall buildings, tunnels, weather,
electrical system design and
architecture of the vehicle, damage
to the vehicle in a crash, or wireless
phone network congestion or
jamming —may prevent service. See
Radio Frequency Statement
0 427.
Services for People with
Disabilities
Advisors provide services to help
Subscribers with physical disabilities
and medical conditions.
Press
Qto help:
. Locate a gas station with an
attendant to pump gas.
. Find a hotel, restaurant, etc.,
that meets accessibility needs.
. Provide directions to the closest
hospital or pharmacy in urgent
situations.
TTY Users
OnStar has the ability to
communicate to deaf,
hard-of-hearing, or speech-impaired
customers while in the vehicle. The
available dealer-installed TTY
system can provide in-vehicle
access to all OnStar services,
except Virtual Advisor and OnStar
Turn-by-Turn Navigation.
OnStar Personal Identification
Number (PIN)
A PIN is needed to access some
OnStar services. The PIN will need
to be changed the first time when
speaking with an Advisor. To
change the OnStar PIN, contact an
OnStar Advisor by pressing
Qor
calling 1-888-4ONSTAR.
Warranty
OnStar equipment may be
warranted as part of the vehicle
warranty.
Languages
The vehicle can be programmed to
respond in multiple languages.
Press
Qand ask for an Advisor.
Advisors are available in English,
Spanish, and French. Available
languages may vary by country.
Potential Issues
OnStar cannot perform Remote
Door Unlock or Stolen Vehicle
Assistance after the vehicle has
been off continuously for five days
without an ignition cycle. If the

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
OnStar 437
vehicle has not been started for
five days, OnStar can contact
Roadside Assistance or a locksmith
to help gain access to the vehicle.
Global Positioning
System (GPS)
.Obstruction of the GPS can
occur in a large city with tall
buildings; in parking garages;
around airports; in tunnels and
underpasses; or in an area with
very dense trees. If GPS signals
are not available, the OnStar
system should still operate to
call OnStar. However, OnStar
could have difficulty identifying
the exact location.
. In emergency situations, OnStar
can use the last stored GPS
location to send to emergency
responders.
A temporary loss of GPS can cause
loss of the ability to send a
Turn-by-Turn Navigation route. The
Advisor may give a verbal route or
may ask for a call back after the
vehicle is driven into an open area.
Cellular and GPS Antennas
Cellular reception is required for
OnStar to send remote signals to
the vehicle. Do not place items over
or near the antenna to prevent
blocking cellular and GPS signal
reception.
Unable to Connect to OnStar
Message
If there is limited cellular coverage
or the cellular network has reached
maximum capacity, this message
may come on. Press
Qto try the
call again or try again after driving a
few miles into another cellular area.
Vehicle and Power Issues
OnStar services require a vehicle
electrical system, wireless service,
and GPS satellite technologies to be
available and operating for features
to function properly. These systems
may not operate if the battery is
discharged or disconnected.
Add-on Electrical Equipment
The OnStar system is integrated
into the electrical architecture of the
vehicle. Do not add any electrical
equipment. See Add-On Electrical
Equipment 0309. Added electrical
equipment may interfere with the
operation of the OnStar system and
cause it to not operate.
Vehicle Software Updates
OnStar or GM may remotely deliver
software updates or changes to the
vehicle without further notice or
consent. These updates or changes
may enhance or maintain safety,
security, or the operation of the
vehicle or the vehicle systems.
Software updates or changes may
affect or erase data or settings that
are stored in the vehicle, such as
OnStar Hands-Free Calling name
tags, saved navigation destinations,
or pre-set radio stations. Neither
OnStar nor GM is responsible for
any affected or erased data or
settings. These updates or changes
may also collect personal
information. Such collection is
described in the OnStar privacy

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
442 Index
Appearance CareExterior . . . . . . . . . . . . . . . . . . . . . . . 391
Interior . . . . . . . . . . . . . . . . . . . . . . . . 395
Armrest Storage . . . . . . . . . . . . . . . . 123
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 421
Assistance Systems for
Driving . . . . . . . . . . . . . . . . . . . . . . . . 283
Assistance Systems for Parking and Backing . . . . . . . . . . 281
Audio
Theft-Deterrent Feature . . . . . . . 193
Audio Players CD . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . 45
Headlamp System . . . . . . . . . . . . 186
Level Control . . . . . . . . . . . . . . . . . 270
Transmission . . . . . . . . . . . . . . . . . 255
Transmission Fluid . . . . . . . . . . . 318
Automatic Transmission
Manual Mode . . . . . . . . . . . . . . . . . 257
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 334
Auxiliary Jack . . . . . . . . . . . . . . . . . . . 207
Axle, Front . . . . . . . . . . . . . . . . . . . . . . 332
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 332B
Battery
Load Management . . . . . . . . . . . . 190
Power Protection . . . . . . . . . . . . . 191
Voltage and ChargingMessages . . . . . . . . . . . . . . . . . . . 161
Battery - North America . . . . 331, 382
Blade Replacement, Wiper . . . . . 335
Blind Spot Mirrors . . . . . . . . . . . . . . . 57
Bluetooth Overview . . . . . . . . . . . 208, 209, 213
Brake Pedal and AdjustableThrottle . . . . . . . . . . . . . . . . . . . . . . 244
System Warning Light . . . . . . . . 148
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 328 Antilock . . . . . . . . . . . . . . . . . . . . . . . 265
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 266
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Parking . . . . . . . . . . . . . . . . . . . . . . . 265
System Messages . . . . . . . . . . . . 162
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 229
Break-In, New Vehicle . . . . . . . . . . 244
Bulb Replacement . . . . . . . . . . . . . . 341 Fog Lamps . . . . . . . . . . . . . . 188, 338
Front Turn Signal Lamps . . . . . 339
Halogen Bulbs . . . . . . . . . . . . . . . . 337
Headlamp Aiming . . . . . . . . . . . . . 337 Bulb Replacement (cont'd)
Headlamps . . . . . . . . . . . . . . 337, 338
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 338
License Plate Lamps . . . . . . . . . 340
Taillamps, Turn Signal, Stoplamps, and Back-up
Lamps . . . . . . . . . . . . . . . . . . . . . . 339
Buying New Tires . . . . . . . . . . . . . . . 366
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 132
California Fuel Requirements . . . . . . . . . . . 292
Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 312
California Proposition
65 Warning . . . . . . . . . . 311, 331, 382
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 415
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 254
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 47
Winter Driving . . . . . . . . . . . . . . . . 237
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . 124
Caution, Danger, and Warning . . . . 2

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
Index 445
Folding Mirrors . . . . . . . . . . . . . . . . . . 56
Forward Collision Alert(FCA) System . . . . . . . . . . . . . . . . . 283
Four-Wheel Drive . . . . . . . . . . 260, 331
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 427
Front Automatic Braking
(FAB) System . . . . . . . . . . . . . . . . . 286
Front Axle . . . . . . . . . . . . . . . . . . . . . . 332
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 65
Heated and Cooled . . . . . . . . . . . . . 70
Front Turn Signal Lamps . . . . . . . 339
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291 Additives . . . . . . . . . . . . . . . . . . . . . 292
Economy Driving . . . . . . . . . . . . . . . 29
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 295
Filling the Tank . . . . . . . . . . . . . . . 293
Foreign Countries . . . . . . . . . . . . 292
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 140
Low Fuel Warning Light . . . . . . . 151
Management, Active . . . . . . . . . . 254
Requirements, California . . . . . 292
System Messages . . . . . . . . . . . . 165
Full-Size Spare Tire . . . . . . . . . . . . 381 Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . 342
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 342
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . 345, 348
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 350
G
Garage Door Opener . . . . . . . . . . . 179
Programming . . . . . . . . . . . . . . . . . 179
Gauges
Engine CoolantTemperature . . . . . . . . . . . . . . . . 142
Engine Oil Pressure . . . . . . . . . . 141
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Odometer . . . . . . . . . . . . . . . . . . . . . 140
Speedometer . . . . . . . . . . . . . . . . . 140
Tachometer . . . . . . . . . . . . . . . . . . . 140
Trip Odometer . . . . . . . . . . . . . . . . 140
Voltmeter . . . . . . . . . . . . . . . . . . . . . 143
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 136
General Information Service and Maintenance . . . . . 400
Towing . . . . . . . . . . . . . . . . . . . . . . . . 296
Vehicle Care . . . . . . . . . . . . . . . . . . .311
Glass Replacement . . . . . . . . . . . . . 336
Glove Box . . . . . . . . . . . . . . . . . . . . . . 122 GM Mobility Reimbursement
Program . . . . . . . . . . . . . . . . . . . . . . . 421
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 337
Hazard Warning Flashers . . . . . . . 187
Head Restraints . . . . . . . . . . . . . . . . . 64
Head-up Display . . . . . . . . . . . . . . . . 157
Headlamps . . . . . . . . . . . . . . . . . . . . . 338
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 337
Automatic . . . . . . . . . . . . . . . . . . . . . 186
Bulb Replacement . . . . . . . . . . . . 337
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 186
Flash-to-Pass . . . . . . . . . . . . . . . . . 185
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 338
High-Beam On Light . . . . . . . . . . 152
High/Low Beam Changer . . . . . 185
Lamps On Reminder . . . . . . . . . 152
Heated
Rear Seats . . . . . . . . . . . . . . . . . . . . . 71
Steering Wheel . . . . . . . . . . . . . . . 129
Heated and Cooled Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Heated Mirrors . . . . . . . . . . . . . . . . . . . 57
Heater
Engine . . . . . . . . . . . . . . . . . . . . . . . . 250
High-Beam On Light . . . . . . . . . . . . 152

Chevrolet Tahoe/Suburban Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-9159366) - 2016 - crc - 5/19/15
446 Index
High-Speed Operation . . . . . . . . . . 359
Hill and Mountain Roads . . . . . . . . 237
Hill Descent Control (HDC) . . . . . 269
Hill Start Assist (HSA) . . . . . . . . . . 266
Home Page . . . . . . . . . . . . . . . . . . . . . 196
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
How to Wear Safety BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . . 81
I
Ignition Positions . . . . . . . . . . 245, 247
Ignition Transmission LockCheck . . . . . . . . . . . . . . . . . . . . . . . . . 335
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 54
Indicator Vehicle Ahead . . . . . . . . . . . . . . . . 150
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . 103
Infotainment . . . . . . . . . . . . . . . . . . . . 192
Infotainment System . . . . . . . . . . . . 430
Instrument Cluster . . . . . . . . . . . . . . 137
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . 122
Instrument Panel Overview . . . . . . . 6
Interior Rearview Mirrors . . . . . . . . . 58
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jack Auxiliary . . . . . . . . . . . . . . . . . . . . . . 207
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 382
K
Key and Lock Messages . . . . . . . . 165
Keyless Entry
Remote (RKE) System . . . . . 35, 37
Keys . . . . . . . . . . . . . . . . . . . . . . . . . 31, 34
L
Labeling, Tire Sidewall . . . . . . . . . . 353
Lamps Daytime Running (DRL) . . . . . . 186
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 189
Exterior Controls . . . . . . . . . . . . . . 183
Exterior Lamps Off
Reminder . . . . . . . . . . . . . . . . . . . 185
Front Turn Signal . . . . . . . . . . . . . 339
License Plate . . . . . . . . . . . . . . . . . 340
Malfunction Indicator . . . . . . . . . 146
Messages . . . . . . . . . . . . . . . . . . . . 165
On Reminder . . . . . . . . . . . . . . . . . 152
Reading . . . . . . . . . . . . . . . . . . . . . . 189
Lane Change Alert (LCA) . . . . . . . 287
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 289 Lane Keep Assist (LKA) . . . . . . . . 289
Lane Keep Assist Light . . . . . . . . . 149
Lap Belt . . . . . . . . . . . . . . . . . . . . . . . . . 87
Lap-Shoulder Belt . . . . . . . . . . . . . . . 82
LATCH System
Replacing Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . .116
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . 109
LED Lighting . . . . . . . . . . . . . . . . . . . . 338
Level Control Automatic . . . . . . . . . . . . . . . . . . . . . 270
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . 190
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Illumination Control . . . . . . . . . . . 188
LED . . . . . . . . . . . . . . . . . . . . . . . . . . 338
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . 149 Airbag Readiness . . . . . . . . . . . . . 144
Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . 149
Brake System Warning . . . . . . . 148
Charging System . . . . . . . . . . . . . 146
Cruise Control . . . . . . . . . . . . . . . . 152
Flash-to-Pass . . . . . . . . . . . . . . . . . 185
Front Fog Lamp . . . . . . . . . . . . . . 152
High-Beam On . . . . . . . . . . . . . . . . 152
