212Vehicle careJump startingDo not start with quick charger.
A vehicle with a discharged vehicle
battery can be started using jump
leads and the vehicle battery of
another vehicle.9 Warning
Be extremely careful when starting
with jump leads. Any deviation
from the following instructions can
lead to injuries or damage caused
by vehicle battery explosion or
damage to the electrical systems
of both vehicles.
9 Warning
Avoid contact of the vehicle
battery with eyes, skin, fabrics and painted surfaces. The fluid
contains sulphuric acid which can
cause injuries and damage in the
event of direct contact.
● Never expose the vehicle battery
to naked flames or sparks.
● A discharged vehicle battery can already freeze at a temperature
of 0 °C. Defrost the frozen battery
before connecting jump leads.
● Wear eye protection and protective clothing when
handling a vehicle battery.
● Use a booster battery with the same voltage (12 volts). Its
capacity (Ah) must not be much less than that of the discharged
battery.
● Use jump leads with insulated terminals and a cross section of
at least 16 mm 2
(25 mm 2
for
diesel engines).
● Do not disconnect the discharged
battery from the vehicle.
● Switch off all unnecessary electrical consumers.
● Do not lean over the battery during jump starting.
● Do not allow the terminals of one
lead to touch those of the other
lead.
● The vehicles must not come into contact with each other during
the jump starting process.● Apply the parking brake, transmission in neutral,
automatic transmission in P.
● Open the positive terminal protection caps of both batteries.
Lead connection order:
1. Connect the red lead to the positive terminal of the booster
battery.
2. Connect the other end of the red lead to the positive terminal of the
discharged battery.

220Service and maintenanceConfirmations
Confirmation of service is recorded in the Service and warranty booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
warranty booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 90.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for
gasoline and diesel engines. If it is
unavailable, engine oils of other listed qualities have to be used.
Recommendations for gasoline
engines are also valid for
Compressed Natural Gas (CNG),
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 224.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 224.

245Cigarette lighter ........................... 87
Climate control ............................. 15
Climate control, service ..............136
Climate control systems .............128
Clock............................................. 85
Code ........................................... 105
Collision damage repair ..............239
Control indicators.......................... 91
Control of the vehicle .................138
Controls ........................................ 81
Controls in steering wheel ............81
Convex shape .............................. 29
Coolant ....................................... 174
Coolant and antifreeze ...............220
Coolant temperature gauge ..........89
Coupling ball bar ........................167
Cruise control ...................... 99, 153
Cupholders .................................. 60
Curtain airbag system .................. 52
Curve lighting.............................. 122
D Danger, Warnings and Cautions ...4
Dashboard .................................... 10
Daytime running light ..................120
Daytime running lights ...............122
Declaration of conformity ............237
Diesel fuel system bleeding .......178
Diesel particle filter ...............97, 144
Door open .................................... 99Doors............................................ 26
Driver assistance systems ..........153
Driver Information Centre ...........100
Driving characteristics and towing tips .............................. 166
Driving hints ................................ 138
E Electric adjustment ......................29
Electrical system......................... 188
Electric parking brake ...........96, 150
Electric parking brake fault ...........96
Electronic climate control system 131
Electronic driving programmes ..147
Electronic Stability Control.......... 152
Electronic Stability Control and Traction Control system ...........97
Electronic Stability Control off ...... 97
End-of-life vehicle recovery .......171
Engine compartment fuse box ...190
Engine coolant ........................... 174
Engine coolant temperature gauge ....................................... 89
Engine data ............................... 227
Engine exhaust .......................... 144
Engine identification ...................223
Engine oil ................... 173, 220, 224
Engine oil pressure ......................98
Entry lighting .............................. 126
Event data recorders ..................241Exhaust gases ............................ 144
Exit lighting ................................ 126
Exterior care .............................. 215
Exterior light ................................. 98
Exterior lighting ....................12, 119
Exterior mirrors ............................. 29
F Fault ........................................... 147
First aid ......................................... 77
First aid kit ................................... 77
Fixed air vents ........................... 136
Flex-Fix system ............................ 63
Fog light ....................................... 99
Fog lights .................... 123, 124, 183
Folding mirrors ............................. 29
Folding tray .................................. 77
Front airbag system .....................51
Front fog lights ........................... 123
Front seats.................................... 36
Front storage ............................... 62
Front turn signal light ..................179
Front turn signal lights ...............183
Fuel............................................. 159
Fuel consumption - CO 2-
Emissions ............................... 164
Fuel for diesel engines ..............159
Fuel for liquid gas operation .......159
Fuel for petrol engines ...............159
Fuel gauge ................................... 89

246Fuel selector ................................ 89
Fuse box ..................................... 190
Fuses ......................................... 188
G Gauges ......................................... 88
General information ...................165
Glovebox ..................................... 60
Graphic-Info-Display, Colour- Info-Display ............................ 103
H Halogen headlights ....................179
Hand brake ......................... 149, 150
Hazard warning flashers ............123
Headlight flash ........................... 121
Headlight range adjustment ......121
Headlights .......................... 119, 121
Headlights when driving abroad 121
Head restraint adjustment .............8
Head restraints ............................ 34
Heated mirrors ............................. 29
Heated rear window ..................... 32
Heated steering wheel .................81
Heating ........................................ 40
Heating and ventilation system . 128
High beam ........................... 99, 121
Hill start assist ........................... 151
Horn ....................................... 13, 82I
Identification plate .....................223
Ignition switch positions .............139
Immobiliser ............................ 28, 98
Indicators ...................................... 88
Information displays.................... 100
Instrument cluster ........................88
Instrument panel fuse box .........192
Instrument panel illumination .....188
Instrument panel illumination control .................................... 125
Instrument panel overview ........... 10
Interior care ............................... 217
Interior lighting ............................ 125
Interior lights ...................... 125, 188
Interior mirrors .............................. 30
Interruption of power supply ......147
Introduction .................................... 3
ISOFIX child restraint systems ....59
J
Jump starting ............................. 212
K Keys ............................................. 19
Keys, locks ................................... 19
Keys, memorised settings ............21
L Lashing eyes ............................... 75
Light covers, misted.................... 124Lighting features .........................126
Light switch ................................ 119
Load compartment ................26, 72
Load compartment cover .............73
Load compartment fuse box ......193
Loading information .....................78
Low fuel ....................................... 98
M Malfunction indicator light ............95
Manual anti-dazzle ......................30
Manual mode ............................. 147
Manual transmission .................. 148
Manual windows ..........................31
Memorised settings ......................21
Midlevel-Display ......................... 100
Mirror adjustment ........................... 8
Misted light covers .....................124
Moonroof ..................................... 33
N New vehicle running-in ..............139
Number plate light .....................187
O
Object detection systems ...........155
Octane rating .............................. 227
Odometer ..................................... 88
Oil ............................................... 173
Oil, engine .......................... 220, 224
Oil pressure .................................. 98

248Top-tether fastening eyes ............59
Tow bar....................................... 165
Towing ................................ 165, 213
Towing another vehicle .............214
Towing a trailer ........................... 166
Towing equipment .....................167
Towing the vehicle .....................213
Traction Control system ............. 152
Traction Control system off .......... 97
Trailer coupling ........................... 165
Trailer towing ............................. 166
Transmission ............................... 16
Transmission display .................145
Tread depth ............................... 200
Trip computer ............................ 108
Trip odometer .............................. 88
Tunnel detection .........................120
Turn and lane-change signals ...123
Turn signal ................................... 93
Tyre chains ................................ 201
Tyre designations ......................195
Tyre pressure ............................ 196
Tyre pressure monitoring system ............................... 97, 197
Tyre pressures ........................... 234
Tyre repair kit ............................. 201
Tyres and wheel size, changing. 200U
Ultrasonic parking assist ...... 96, 155
Underseat storage .......................62
Upholstery .................................. 217
Uplevel-Combi-Display ...............100
Uplevel-Display........................... 100
Upshift .......................................... 96
Using this manual ..........................3
V
Variable effort steering .................96
Vehicle battery ........................... 176
Vehicle battery, jump starting .....212
Vehicle checks............................ 172
Vehicle data ................................ 224
Vehicle data recording and privacy ..................................... 241
Vehicle dimensions .................... 232
Vehicle Identification Number ....222
Vehicle jack ................................ 194
Vehicle messages .....................105
Vehicle personalisation .............111
Vehicle security ............................ 27
Vehicle specific data ......................3
Vehicle storage ........................... 171
Vehicle tools ............................... 194
Vehicle unlocking ........................... 6 Vehicle weight ........................... 231
Ventilation ................................... 128W
Warning chimes .........................107
Warning lights ............................... 88
Warning triangle .......................... 77
Washer and wiper systems .........14
Washer fluid ............................... 175
Welcome lighting ........................126
Wheel changing .........................206
Wheel covers ............................. 201
Wheels and tyres .......................195
Windows ....................................... 30
Windscreen................................... 30 Windscreen wiper/washer ...........82
Winter tyres ............................... 195
Wiper blade replacement ..........178
