178Driving and operatingThe system cannot operate when no
lane marking is detected.Fuel
Fuel for petrol engines
Only use unleaded fuel that complies
with European standard EN 228 or
E DIN 51626-1 or equivalent.
The engine is capable of running with fuel that contains up to 10% ethanol(e.g. named E10).
Use fuel with the recommended
octane rating. The engine specific
requirements are given in the engine data overview 3 241. A country
specific label at the fuel filler flap can
supersede the requirement.Caution
Do not use fuel or fuel additives
that contain metallic compounds
such as manganese-based
additives. This may cause engine
damage.
Caution
Use of fuel that does not comply to EN 228 or E DIN 51626-1 or
equivalent can lead to deposits or
engine damage and may affect
your warranty.
Caution
Use of fuel with too low an octane
rating could lead to uncontrolled combustion and engine damage.
Fuel for diesel engines
Only use diesel fuel that complies
with EN 590.
In countries outside the European
Union use Euro-Diesel fuel with a
sulphur concentration below 50 ppm.
Technical data241Engine dataSales designation1.4 Turbo1.4 Turbo1.6 Turbo1.6 Turbo1.6 TurboEngine identifier codeB14NELB14NETA16XHTB16SHTB16SHLEngineering codeB14NETB14NETA16XHTB16SHTB16SHTPiston displacement [cm3
]13641364159815981598Engine power [kW]88103125147125at rpm4200-60004900-6000600055004750-6000Torque [Nm]200200260280260at rpm1850-42001850-49001650-32001650-50001650-4500Fuel typePetrolPetrolPetrolPetrolPetrolOctane rating RON 2)recommended9595989898possible9898959595possible91919191912)
A country specific label at the fuel filler flap can supersede the engine specific requirement.
