2016.5 VAUXHALL ADAM glove box

In brief111Power windows .....................29
2 Exterior mirrors .....................27
3 Cruise control .....................139
Speed limiter ....................... 141
4 Side air vents ...................... 121
5 Turn and lane-change
signals, headlight flash,
low beam and high beam ....108
Exit lighting ......................... 111
Parking lights ...................... 108
Buttons for Driver
Information Centre ................88
6 Instruments .......................... 78
7 Steering wheel controls .......70
8 Driver Information Centre ...... 88
9 Windscreen wiper,
windscreen washer
system, headlight washer
system, rear wiper, rear
washer system ......................71
10 Central locking system ..........22
City mode ............................ 138
Fuel selector ......................... 79Eco button for stop-start
system ................................. 126
Traction Control system .....136
Electronic Stability Control . 137
Parking assist ..................... 142
Seat heating .......................... 36
Heated steering wheel ..........70
11 Colour-Info-Display ..............93
Graphic-Info-Display .............94
12 Hazard warning flashers ....107
Control indicator for airbag
deactivation .......................... 84
Control indicator for front
passenger seat belt .............83
13 Anti-theft alarm system
status LED ........................... 25
14 Centre air vents .................. 121
15 Side air vents passenger
side ..................................... 121
16 Glovebox .............................. 51
Fuse box ............................ 180
17 Climate control system ........ 113
18 Power outlet .......................... 7619AUX input, USB input ...........10
20 Selector lever,
transmission ....................... 130
21 Parking brake ......................135
22 Ignition switch with
steering wheel lock ............124
23 Horn ..................................... 71
Driver airbag ........................ 42
24 Bonnet release lever ..........162
25 Steering wheel adjustment ..70
26 Light switch ........................ 105
Headlight range
adjustment ......................... 107
Rear fog light ...................... 108
Brightness of instrument
panel illumination ................109
Brightness of ambient light 109

Storage51StorageStorage compartments................51
Glovebox ................................... 51
Cupholders ................................ 51
Front storage ............................. 52
Rear carrier system ...................53
Load compartment .......................62
Rear storage .............................. 63
Load compartment cover ...........64
Rear floor storage cover ............64
Lashing eyes ............................. 66
Warning triangle ........................66
First aid kit ................................. 67
Roof rack system .........................67
Roof rack ................................... 67
Loading information .....................67Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Glovebox
Pull lever to open the glovebox cover.
The glovebox features a coin holder
and an adapter for the locking wheel
bolts.
The glovebox should be closed whilst
driving.
Cupholders
Cupholders are located in the console between the front seats. They are
designed for cups of different sizes.

Vehicle care177Electrical system
Fuses Data on the replacement fuse must
match the data on the defective fuse.
There are two fuse boxes in the
vehicle:
● in the front left of the engine compartment,
● in left-hand drive vehicles behind
the light switch, or, in right-hand
drive vehicles, behind the
glovebox.
Before replacing a fuse, turn off the
respective switch and the ignition.There are different kinds of fuses in
the vehicle.
Depending on the type of fuse, a
blown fuse can be recognized by its
melted wire. Do not replace the fuse until the cause of the fault has been
remedied.
Some functions are protected by
several fuses.
Fuses may also be inserted without existence of a function.
Fuse extractorA fuse extractor may be located in the
fuse box in the engine compartment.
Place the fuse extractor on the
various types of fuse from the top, and withdraw fuse.

180Vehicle careNo.Circuit1ABS pump2Front wiper3Blower4Instrument panel5–6–7Electrical vacuum pump8Cooling fan low9Cooling fan high10Cooling fan/Electrical vacuum
pump11Starter
After having changed defective fuses
close the fuse box cover and press
until it engages.
If the fuse box cover is not closed
correctly, malfunction may occur.
Instrument panel fuse box
The fuse box is located behind a
cover in the glovebox. Open the
glovebox, then open the cover and
fold it down.

Vehicle care195cap from the wheel. Vehicle tools
3 182.
2. Install the wheel wrench ensuring
that it locates securely and loosen
each wheel bolt by half a turn.
The wheels might be protected by
locking wheel bolts. To loosen
these specific bolts, first attach
the adapter for the locking wheel
bolts onto the head of the bolt
before installing the wheel
wrench. The adapter is located in
the glovebox.
3. Ensure the jack is correctly positioned under the relevant
vehicle jacking point.
Some versions have sill
panellings with covered vehicle
jacking points: first pull out the
cover at the respective jacking
point before positioning the jack.
4. Set the jack to the necessary height. Position it directly below
the jacking point in a manner that
prevents it from slipping.

233Convex shape .............................. 27
Coolant and antifreeze ...............210
Cruise control ...................... 88, 139
Cupholders .................................. 51
Curtain airbag system .................. 43
D
Danger, Warnings and Cautions ...4
Daytime running lights ...............107
Declaration of conformity ............225
Door open .................................... 88
Doors ............................................ 24
Driver assistance systems ..........139
Driver Information Centre .............88
Driving hints ................................ 123
E Electric adjustment ......................27
Electrical system......................... 177
Electronic climate control system 116
Electronic driving programmes ..133
Electronic Stability Control.......... 137
Electronic Stability Control and Traction Control system ............86
Electronic Stability Control off....... 86 End-of-life vehicle recovery .......161
Engine compartment fuse box ...178
Engine coolant ........................... 164
Engine coolant temperature gauge ....................................... 80
Engine data ............................... 217Engine exhaust .......................... 129
Engine identification ...................213
Engine oil ................... 163, 210, 214
Engine oil pressure ......................87
Entry lighting .............................. 111
Event data recorders ..................229
Exit lighting ................................ 111
Exterior care .............................. 205
Exterior light ................................. 88
Exterior lighting ....................12, 105
Exterior mirrors ............................. 27
F Fault ........................................... 133
First aid ......................................... 67
First aid kit ................................... 67
Fixed air vents ........................... 121
Flex-Fix system ............................ 53
Folding mirrors ............................. 27
Front airbag system .....................42
Front seats.................................... 33 Front storage ................................ 52
Front turn signal lights ...............170
Fuel............................................. 153
Fuel consumption - CO 2-
Emissions ............................... 158
Fuel for liquid gas operation .......153
Fuel for petrol engines ...............153
Fuel gauge ................................... 79Fuel selector ................................ 79
Fuses ......................................... 177
G Gauges ......................................... 78
Glass panel .................................. 31
Glovebox ..................................... 51
Graphic-Info-Display .....................94
H Halogen headlights ....................168
Hand brake ......................... 134, 135
Hazard warning flashers ............107
Headlight flash ........................... 106
Headlight range adjustment ......107
Headlights................................... 105
Headlights when driving abroad 107
Head restraint adjustment .............8
Head restraints ............................ 32
Heated mirrors ............................. 28
Heated rear window ..................... 30
Heated steering wheel .................70
Heating ........................................ 36
Heating and ventilation system . 113
High beam ........................... 88, 106
Hill start assist ........................... 135
Horn ....................................... 13, 71
I
Identification plate .....................213
Ignition switch positions .............124
