2015 VOLKSWAGEN TOUAREG homelink

Roof console overview

Fig. 12 Overview of the roof console.
Key to fig. 12:
(1) Buttons for HomeLink® Universal Transmitter 1 2 3
(2) 3 button module
– Voice operation 
– Information

HomeLink® Universal Transmitter

WARNING
Improper use of the HomeLink Universal Transmitter can cause serious or even fatal personal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink Universal Transmitter, you may be operating a garage door or estate gate. Always make sure that people and objects are out of the way to help prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will need to stand on a ladder or step stool. Always take extra precautions to prevent falls and serious injury.
x Never use the HomeLink Universal Transmitter with any garage door opener that does not have the safety stop-and-reverse feature, as required by federal safety standards. This in-cludes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using a garage door opener without these features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer when using the remote controlled garage door opener or electrical drive.
Programming the HomeLink® Universal Transmitter

Fig. 37 Roof keypad: Buttons for the HomeLink Universal Transmitter.

Fig. 38 Infotainment System: HomeLink Universal Transmitter menu.

Programming previously assigned buttons
x Complete the programming preparation steps described above ⇒ page 73, Getting ready to pro-gram.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
x Tap the Program button function key and follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3 times.
Repeat these steps with another previously assigned garage door opener button to use that button to control another device.
Deleting programming for all buttons
Be sure to delete the programming on all buttons on the sun visor keypad before selling the vehicle or turning it over to people you do not know.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
x Tap the delete button assignment function key and confirm.
The green LED in the keypad will light up to confirm that the programming has been successfully deleted.
After programming
Test the garage door opener
Operating the HomeLink® Universal Transmitter

Malfunction Possible cause Possible remedy
Garage door or elec-
trical drive not com-
patible.
May not comply with legal re-
quirements and may have to
be replaced.
Incorrect program-
ming.
Reprogram the garage door
opener.

DANGER
20 mm button cells and other lithium batteries will cause serious personal injury and even death within a short time if swallowed.
x Always keep hand-held remote control devices with batteries, spare batteries, as well as dead button cell and larger 20 mm batteries out of the reach of children.
x Get medical attention immediately if you suspect that a battery has been swallowed.
WARNING
Improper use of the HomeLink® Universal Transmitter can cause serious or even fatal per-sonal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink® Universal Transmitter, you may be operating a garage door or estate gate. Always make sure that people and objects are out of the way to help prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and serious injury.
x Never use the HomeLink® Universal Transmitter with any garage door opener that does not have the safety stop-and-reverse feature, as required by federal safety standards. This includes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using a garage door opener without these features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer when using the remote-controlled garage door opener or electrical drive.
NOTICE
The wrong batteries can damage the hand-held remote control. Replace a dead battery with one that has the same voltage, size, and specifications.
Please dispose of old batteries properly and in an environmentally responsible manner. Always keep them out of the reach of children.

Declaration of Compliance, Telecommunications and
Electronic Systems
Radio Frequency Devices and Radio communication Equipment User Manual Notice.
Radio-based equipment
x Mobile phone package.
x Electronic immobilizer.
x HomeLink Universal remote control.
x Remote control vehicle key.
x Tire Pressure Monitoring System (TPMS).
x Keyless Access locking and starting system.
x Park Distance Control (PDC) system.
These devices comply with:
FCC Part 15.19
These devices comply with Part 15 of the FCC Rules. Operation is subject to the following 2 condi-tions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Part 15.21
CAUTION:
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
These devices comply with RSS-210 of Industry Canada.
Operation is subject to the following 2 conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired opera-tion of the device.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifica-tions to this equipment.
