2015 VOLKSWAGEN TOUAREG Camera

Front view

Fig. 2 Vehicle front overview.
Key to fig. 2:
(1) Power sunroof
(2) Windshield area with:
– Rain sensor on mirror base
– Low-light sensor on mirror base
– Dynamic high beam control on mirror base
– Windshield wipers
(3) Engine hood release
(4) Headlights (on both left and right) ,
(5) Headlight washers (on left and right)
(6) Threaded hole for the front towing eye (on both left and right) behind covers
(7) Sensors for front Park Distance Control (on both left and right)
(8) Fog lights/static cornering lights (on both left and right)
(9) Radar sensors for the adaptive cruise control (ACC) (on both left and right)
(10) Camera for Area View

Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Roof antenna for:
– Mobile phone
– Navigation
(2) High-mounted brake light
(3) Rear window with:
– Rear window defroster
– Rear window wiper
(4) Taillights (on both left and right)
(5) Area of:
– Button to open the rear hatch
– Rear Assist camera and the Area View camera
– License plate lighting
(6) Radar sensors for Side Assist
(7) Sensors for rear Park Distance Control
(8) Threaded hole for the rear towing eye (on both left and right) behind covers
(9) Trailer hitch/ball mount receiver

Upper center console

Fig. 7 Overview of upper center console.
Key to fig. 7:
(1) Air vent for indirect ventilation
(3) Air vents z
(2) Storage compartment
(4) Radio or Radio & Navigation system (factory installed)
(5) Controls for:
– Climatronic
– Seat heating switch button A
(6) Located here:
– Switch for emergency flashers
– PASSENGER AIR BAG /&&  light (front airbag for front seat passenger)
– Park Distance Control system button  or ∗
– Rear View camera ∗
– Heated steering wheel

Lights
up Possible cause ⇒  Proper response
E
Adaptive Cruise Control
(ACC) is not active, the sys-
tem is on but not regulating
or holding speed.
-

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Radar sensors, ultrasonic sensors and Front Assist camera

Fig. 271 Vehicle front view: Sensors and camera

There are 2 radar sensors next to the fog lights on the vehicle front (3). These can detect moving vehicles up to 590 ft (180 m) in front of your vehicle.
The areas of the sensors (2) and (3) and the camera (1) must not be spray painted on or covered by stickers or other objects, since this can lead to a malfunction of the Adaptive Cruise Control (ACC) and the Front Assist system.
NOTICE
If you notice that Adaptive Cruise Control (ACC) or Front Assist doesn't work properly or the sensors are damaged, switch off ACC immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the ACC system checked.
x The sensors can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors can cause ACC or Front Assist to malfunction.
x To help make sure that the system works properly, always keep the sensors clean, free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x For Declaration of Compliance to United States FCC and Industry Canada regulations
Always keep the area of the Front Assist camera clear of ice and snow.
Switching ACC on and off

Fig. 272 On the steering wheel column: Lever for Adaptive Cruise Control.

Fig. 273 Lever for Adaptive Cruise Control: Setting the distance (time intervals)

WARNING
If the view area of the camera is covered or dirty, Lane Assist may not work properly.
x Always make sure that the camera area is free of dirt or snow and not covered.
NOTICE
In order to help maintain the proper function of the Forward Collision Warning system (Front Assist):
x Always keep the camera area in the front windshield free of ice, dirt and snow.
x Never cover the camera area.
x Regularly check the windshield and especially the area of the camera for damages.
Lane Assist has been developed only for on-road driving.
If Lane Assist does not work properly and as described here, have the system checked by an authorized Volkswagen dealer or Volkswagen Service Facility.
Warning and Indicator lights

lights
up Possible cause Proper response
Minimum speed not yet reached.

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
How Lane Assist works

Fig. 279 In the front windshield: Area of the Lane Assist camera.

Before starting to drive, always make sure that the area of the camera ⇒ fig. 279 is not covered.
When to deactivate Lane Assist
