Display, warning and indicator lights

Fig. 269 In the instrument cluster display: ACC is active and the maximum distance is set to the detected vehicle in front.

Fig. 270 In the instrument cluster display: ACC is not active but a vehicle was detected in front.

Lights
up Possible cause ⇒  Proper response
E
Adaptive Cruise Control
(ACC) is not active, the sys-
tem is on but not regulating
or holding speed.
-

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Radar sensors, ultrasonic sensors and Front Assist camera

Fig. 271 Vehicle front view: Sensors and camera

WARNING
Improper use of the Adaptive Cruise Control can cause collisions, other accidents and seri-ous personal injury.
x Always remember that the Adaptive Cruise Control has limits – it will not slow the vehicle down or maintain the set distance when you drive towards an obstacle or something on or near the road that is not moving, such as vehicles stopped in a traffic jam, a stalled or disa-bled vehicle.
x Always remember that the Adaptive Cruise Control cannot detect a vehicle that is driving towards you in your traffic lane and that it cannot detect narrow vehicles such as motorcy-cles and bicycles.
x Never drive at speeds that are too fast for traffic, road and weather conditions.
x Never follow a vehicle so closely that you cannot stop your vehicle safely. The Adaptive Cruise Control cannot slow or brake the vehicle safely when you follow another vehicle too closely. Always remember that the Adaptive Cruise Control has a braking power that is only about 30% of the vehicle's maximum braking ability, the automatic braking function cannot bring the vehicle to a stop.
x Never use Adaptive Cruise Control when you cannot drive safely at a steady speed, in-cluding on city streets, on winding roads or when road conditions are poor (for example, on ice, gravel, in fog, heavy rain or on wet roads that increase the risk of hydroplaning).
x The radar sensor's vision can be reduced by rain, snow and heavy road spray. These and similar conditions can prevent vehicles up ahead from being accurately detected and in some cases they may not be detected at all. Do not use ACC when the radar sensors cannot accu-rately detect vehicles moving ahead of you in traffic.
x Always turn off Adaptive Cruise Control when entering turn lanes, exit lanes and construc-tion zones or in similar situations because the vehicle will automatically accelerate to the stored speed when the road ahead is clear.
x Never rest your foot on the accelerator pedal, especially when the Adaptive Cruise Control is being used because doing so will override the braking function.
x Always pay attention to traffic, especially when Adaptive Cruise Control is switched on.
x Always maintain a safe speed and distance between your vehicle and other vehicles while considering the traffic situation. This is the duty of the driver. Adaptive Cruise Control is merely an aid to the driver.
x To prevent unintended operation, always switch ACC off when it is not being used.
x It is dangerous to use the “Resume” feature when the previously set speed is too high for existing road, traffic or weather conditions.
x Always select a speed and distance to traffic ahead that is safe and appropriate under the prevailing traffic, road, weather and lighting conditions.
x Never allow the closing speed between you and other vehicles to be so high that the Adaptive Cruise Control may not be able to slow your vehicle safely. If closing speed is too high, you must apply the brakes yourself to reduce the risk of a rear-end crash.
NOTICE
When the vehicle is driving at speeds lower than 20 mph (30 km/h) and the 3%4 button is pressed or the lever is moved to 2%35-%, the vehicle will be accelerated to the lowest possible speed that can be set in ACC of 20 mph (30 km/h)
The stored speed is canceled when the ignition or the ACC is switched off.

x If the radar sensor malfunctions.
x If external force has affected the radar sensor, for example, after a rear-end collision.
x If the radar sensor is covered (even temporarily) by any accessories or other equipment, for exam-ple, auxiliary headlights.
x If the vehicle is being loaded onto a truck, ferry, or train.
WARNING
Failure to switch off the Forward Collision Warning system in the situations mentioned can cause accidents and serious personal injury.
Forward Collision Warning system (Front Assist) system limits

The Autonomous Emergency Braking function should be deactivated by switching off the Forward Collision Warning system (Front Assist) in following situations:
x When the vehicle is being towed.
x When the vehicle is on a roller test stand.
x When the vehicle is off road, like on construction sites or on race tracks.
x When one of the sensors is defect.
x When the sensors have been damaged, like after a frontal collision accident.
x After several false alarms in a row.
x If the sensors are covered by additional parts, like auxiliary headlights.
x If the vehicle is driving on steep terrain or on or across slopes.
WARNING
Always remember that the Autonomous Emergency Braking function has limits – it will not release you from the responsibility to control and slow down your vehicle.
x The Autonomous Emergency Braking function alone cannot avoid accidents and fatal injuries.
x Under certain circumstances and complex traffic situations the Autonomous Emergency Braking function can perform unwanted braking maneuvers, like in construction sites.
x Soiled or misaligned radar sensors can lead to unwanted braking maneuvers
x The Autonomous Emergency Braking function does not react to people, animals, crossing traffic or vehicles that are approaching you on the same lane.
x Always adjust your speed and the distance you keep between you and the vehicles ahead of you to the road, traffic, weather, and visibility conditions.
x Never follow a vehicle so closely that you cannot stop your vehicle safely, under certain circumstances the automatic braking function cannot bring the vehicle to a stop in time.
x Never allow the closing speed between you and other vehicles to be so high that the Au-tonomous Emergency Braking function may not be able to slow your vehicle safely. If closing speed is too high, you must apply the brakes yourself to reduce the risk of a rear-end crash.
x Always be prepared to takeover the control of the brake and the gas pedal in every situa-tion.
NOTICE
If you notice that the Autonomous Emergency Braking function doesn't work properly or the sensors are damaged, switch off the Forward Collision Warning system (Front Assist) and therefore the Autonomous Emergency Braking function immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the system checked.
If the Autonomous Emergency Braking function initiates a braking maneuver, the hydraulic brak-ing system is under pressure. In this case the braking pedal will feel “harder” and the brake pedal travel will be shorter.
Automatic braking maneuvers can be interrupted by depressing the gas pedal or moving the steering wheel.
The Autonomous Emergency Braking function can slow your vehicle down to a standstill, but not hold your vehicle permanently. When necessary, apply the vehicle brakes!

WARNING
If the view area of the camera is covered or dirty, Lane Assist may not work properly.
x Always make sure that the camera area is free of dirt or snow and not covered.
NOTICE
In order to help maintain the proper function of the Forward Collision Warning system (Front Assist):
x Always keep the camera area in the front windshield free of ice, dirt and snow.
x Never cover the camera area.
x Regularly check the windshield and especially the area of the camera for damages.
Lane Assist has been developed only for on-road driving.
If Lane Assist does not work properly and as described here, have the system checked by an authorized Volkswagen dealer or Volkswagen Service Facility.
Warning and Indicator lights

lights
up Possible cause Proper response
Minimum speed not yet reached.

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
How Lane Assist works

Fig. 279 In the front windshield: Area of the Lane Assist camera.

Lane Assist settings in the infotainment system
You can change some Lane Assist settings in the infotainment system
x Switch on the ignition.
x Push the infotainment button CAR.
x Tap on the Assistants button in the display.
x Select Front LaneAssist.

Function key
Warning time setting : After touching the Warning time setting or z func-
tion key, you can choose between early, medium and late.
Steering wheel vibration : After touching the Steering wheel vibration or z
function key, you can choose between low, medium and strong.

Setting the warning time

Menu option Meaning
Early The system has a low tolerance level and warns
you early if you come too close to a side marking.
Medium Original setting.
Late The system has a high tolerance level and warns
you late if you come too close to a side marking.

The warning time setting defines the distance from your vehicle to the side markings. An early warning time means that the distance to the side markings has to be high in order for Lane Assist not to trigger a warning.
The time of the warning is also dependent on the approach angle to the side marking and the driving speed. If, for example, you approach a road marking at a steeper angle, the steering wheel will start vibrating at a greater distance.
Setting the vibration level of the steering wheel

Menu option Meaning
Low Light vibration of the steering wheel.
