Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Replacing light bulbs in the front bumper
Fig. 206 In right front bumper: Removing light assembly.
Fig. 207 Replacing light bulb in headlight.
Please carry out each step only in the order specified:
3. Remove the screw (1) using the flat blade of the screwdriver in the vehicle tool kit
4. Remove the headlight.
5. Release the connector ⇒ fig. 207 (1) and disconnect it.
6. Turn the bulb holder (2) counterclockwise in the direction of the arrow until it stops and remove it toward the rear with the bulb.
7. Replace the burned out light bulb with a new bulb of the same type.
8. Insert the bulb holder into the headlight assembly and turn it clockwise until it stops.
9. Connect the connector (1) on the bulb holder (2). You must hear the connector click into place.
10. Insert the headlight.
11. Tighten the screw ⇒ fig. 206 (1) with the screwdriver.
12. Install cover in the bumper ⇒ fig. 206.
Replacing light bulbs in the rear hatch
Fig. 208 In the rear hatch: Removing the cover and the bulb holder.
