2015 VOLKSWAGEN SCIROCCO buttons

– Rear window automatic wipe/wash \
– Lever with buttons for the Volkswagen Information System (Basic version) 42)0, /+

x Vehicles with a multi-function steering wheel: Use the arrow up and down buttons (* and +) on
the right side of the steering wheel ⇒ fig. 15.
Trip memories
The display has 3 automatic memories:
x Since start
x Since refuel
x Extend. period
The currently selected memory is shown in the display.
The trip memories are in addition to the trip odometer, which is displayed in the bottom part of the
instrument cluster and controlled using the /./ button ⇒ fig. 10 (4).

Press the /+

WARNING
Application software and Volkswagen Car-Net services that are unsuitable or improperly used can cause accidents, serious personal injury and vehicle damage.
x Volkswagen Car-Net services can be used only where adequate cellular and GPS signals are available
x Volkswagen recommends using only services and application software that are provided by Volkswagen or Verizon Telematics, Inc. (VzT) specifically for your vehicle.
x Protect the mobile device and its application software from misuse.
x Never modify application software and Volkswagen Car-Net services.
x Always read and heed the operating instructions for the mobile device.
WARNING
Driver distraction causes accidents, collisions and serious personal injury! Using application software and Volkswagen Car-Net services while driving can distract the driver from traffic.
x Always drive attentively and responsibly.
NOTICE
The system does not support simultaneous Volkswagen Car-Net and mobile phone calls via the mobile phone package.
x When a Volkswagen Car-Net service is accessed through the 3-button module call buttons any calls on a mobile device connected to the vehicle’s mobile phone package will be automat-ically disconnected.
x Initiating or accepting a call on a mobile device connected to the vehicle's mobile phone package could end any connection to the Volkswagen Car-Net Response Center made through the , >, or buttons.
x Calls on a mobile device connected to the vehicle's mobile phone package cannot be ac-cepted or initiated during an automated emergency connection to the Volkswagen Car-Net Response Center; for example, because an airbag has deployed.

Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage, moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-ters near the vehicle that use the same frequency range (such as radio equipment or mobile phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak battery can reduce the operating range.
If the remote control vehicle key buttons ⇒ Unlocking or locking the vehicle from the outside or
the power locking buttons ⇒ Unlocking or locking the vehicle from the inside are pushed repeatedly in quick succession, the power locking system is switched off for a brief period to help keep it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Indicator light in the remote control vehicle key

Fig. 20 Indicator light in the remote control vehicle key.

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
If the cruise control is switched on when the ignition is switched off, it may be switched on automatically the next time the ignition is switched on, depending on vehicle equipment. No speed is stored for the cruise control.
The displays may vary depending on vehicle equipment.
Cruise control operation

Fig. 139 On the turn signal lever: Cruise control buttons and switches.

Fig. 140 Left-hand side of the multi-function steering wheel (if equipped): Buttons for operating the cruise control .

Key for displays ⇒ fig. 142
Symbol Meaning
Setting display: brightness, contrast, color.
Depending on vehicle equipment: Display PDC.

Switching the Rear Assist camera on and off.
The Rear Assist rearview camera switches on and off automatically.

Function Action with the ignition on
Vehicles without Park Distance Control Vehicles with Park Distance Control
Switch on the display automatically: Shift into Reverse (R).
Switch off the display automatically: Switch off the ignition.
OR: Drive forward faster than 6 mph (10 km/h) or for longer than 10 seconds.
OR: Shift out of Reverse (R) and wait about 10 seconds. OR: Shift out of Reverse (R) (display switches off immediately).
Switch off the display manually: Press one of the Infotainment system buttons or tap the O function key on the screen.

OR: Tap the function key .
The PDC full screen mode is
displayed ⇒ page 264.
Show the display again:
Shift out of Reverse (R), then shift back into Reverse (R).
OR: Tap the function key Z.

Button/Knob More information: Manual air conditioning ⇒ fig. 149
= Rear window defroster: Works only when the engine is running and switches off automatically after 10 minutes or less.
3 Air recirculation mode ⇒ page 281.
A, [ Buttons for seat heating ⇒ page 88.
!
